Triton Neptune TRI Series Installation & Operation Manual

U.v. disinfection
Hide thumbs
Table of Contents

Advertisement

Quick Links

Triton Series
U.V. Disinfection
INSTALLATION & OPERATION MANUAL
This manual covers installation, operation and maintenance
requirements for Neptune U.V. Disinfection Systems.
Model - TRI-8, TRI-12, TRI-20
It is important that those responsible for the installation of this
equipment, as well as the owner / operator, read this manual
and carefully follow the instructions and guidelines.
Water Treatment & Accessories, LLC
2045 Rockvale Road
Lancaster, PA 17062
ph: (717) 295 - 9339
fax: (717) 396 - 0364
Revised: 4/14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Neptune TRI Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Triton Neptune TRI Series

Summary of Contents for Triton Neptune TRI Series

  • Page 1 Triton Series U.V. Disinfection INSTALLATION & OPERATION MANUAL This manual covers installation, operation and maintenance requirements for Neptune U.V. Disinfection Systems. Model - TRI-8, TRI-12, TRI-20 It is important that those responsible for the installation of this equipment, as well as the owner / operator, read this manual and carefully follow the instructions and guidelines.
  • Page 2 SAFETY INSTRUCTIONS WARNING - to guard against injury, basic safety precautions should be observed, including the following: 1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS. 2. DANGER - To avoid possible electric shock, special care should be taken since water is present near electrical equipment.

  • Page 3: Description Of Equipment

    Flow rate must not exceed rated capacity of the unit. DESCRIPTION OF EQUIPMENT: The Triton series has an unique design with an ultraviolet germicidal lamp housed within a single quartz sleeve surrounded by a stainless steel pressure chamber. The chamber is fabricated out of 304 Stainless Steel.

  • Page 4: Installation

    U.V. disinfection units must always be properly grounded. INSTALLATION: The Triton series are always placed after the pressure tank and any other type of treatment devices (i.e. softeners, filters). These units are normally installed in a vertical position in an enclosed area with good ventilation. Allow clearance of at least the unit’s length at one end for quartz sleeve and bulb replacement.

  • Page 5: General Installation Diagram

    STEP BY STEP INSTALLATION: 1. Turn off the water before cutting into the water line. 2. Assess the installation (i.e. type of pipe, size of lines, etc.) and obtain necessary plumbing fittings for installation. Inlets and outlets on 8 gpm units are 3/4" MNPT. Use Teflon tape on all threaded connections and avoid over tightening.
  • Page 7 OPERATING INSTRUCTIONS Your UV System is equipped with the ATS-281-2 UV Lamp Detector and Timer circuit board which is designed to provide a continuous monitoring system of the UV lamp operational status. This is also equipped with an internal fused surge protection system. This solid state electronic circuit board provides the latest in UV lamp monitoring technology.

  • Page 9: Quartz Sleeve

    QUARTZ SLEEVE: Installation of the Quartz Sleeve: Always handle quartz sleeves carefully to prevent breaking or chipping. The quartz sleeves are to be clean and free of fingerprints before installing. Remove the compression nut. Install the quartz sleeve through the stainless steel threaded nipple allowing an equal amount to extend beyond each nipple.
  • Page 10 ELECTRICAL: The Triton series are furnished with 6' line cord that will plug into a 110V outlet. Electrical receptacles must be properly grounded for safe operation. Improper grounding will void any warranty. When possible use a separate breaker to minimize voltage fluctuations and avoid accidental shut off.

  • Page 11: Disinfection Procedure

    SANITATION PROCEDURE FOR INSTALLATION AND BULB REPLACEMENT: HOW TO DISINFECT A WATER SYSTEM: Every new well, or existing water supply system that has been disrupted for service or repair, should be disinfected before it is returned to use. Water in the well and storage tank should be treated with a strong chlorine solution to destroy disease organisms.
  • Page 12 LARGE DIAMETER WELLS: Dug or bored wells should be disinfected in the same way as a drilled one. Lower the water level as much as possible, remove the sand, silt and debris, and then treat with the chlorine solution. Mix thoroughly by circulating the water back into the well and use the hose to rinse the interior lining of the well.
  • Page 13 REMEMBER - To make your water supply safe: - Locate your well properly. - Protect it from surface contamination. - Test water periodically for coliform bacteria. (Home-yearly, Farm-2X yearly) - Chlorinate, or filter and disinfect the water if necessary. When installing an ultraviolet disinfection system, a prefilter with sump may serve as a source to sanitize the water lines only.
  • Page 14 DRILLED WELLS: 1. Remove the cap or seal from the casing and measure the depth of the water in the well, then refer to Table 1 to determine how many chlorine pellets should be used. In some instances removing the seal to measure the water can be a difficult task, and it is easier to estimate well and water depth from well log or other records.

  • Page 15: Troubleshooting Guide

    TROUBLESHOOTING GUIDE PROBLEM CAUSE CORRECTION U.V. lamp will not light Check input voltage if below Install a voltage regulator or above 120 volts Line cord disconnected Check, replace or outlet defective Defective U.V. lamp Replace Defective lamp ballast Check output voltage Replace ballast Loose open-circuit wire Trace out and repair...

  • Page 16: Limited Warranty

    The U.V. lamp is guaranteed for 1 year, prorated after 90 days. The stainless steel disinfection chamber on the Triton series is guaranteed for ten (10) years. Any component which fails to operate satisfactorily within their time period will be replaced...
  • Page 17 TRITON SPECIFICATIONS Model # Max. Flow No. Lamps KW @ AMP @ Pipe Size Overall Dimensions Shipping 120V 120V L x W x D Weight TRI-8 0.03 0.25 3/4'' MIP 21'' x 3.5'' x 3.5'' 9 Lbs. TRI-12 0.03 0.25 3/4'' MIP 32'' x 3.5'' x 3.5''...
  • Page 18 SUGGESTED PROCEDURE FOR OBTAINING STERILE WATER SAMPLES: Prior to taking the water sample, be sure to have on hand an adequate supply of sterile bottles. These sterile bottles should be obtained from a reputable laboratory and should have been autoclaved and contained within a plastic outer wrapping.

  • Page 19: Wiring Diagram

    WIRING DIAGRAM...
  • Page 21 DRAWING AND PART NUMBERS...
  • Page 22 TRI-8 Explosion CODE PART# DESCRIPTION QTY. WTA-5249 Chamber WTA-R01 ¾” Flo.-Et. Retainer 8 gpm WTA-F08 8 gpm Flo.-Et. WTA-5173 Site Port O-Ring WTA-5172 Site Port Lens WTA-5171 Site Port Nut WTA-268 Top Mounting Bracket WTA5-410 Lock Nut WTA8-544 End Nut O-Ring (seal quartz sleeve) WTA5-409 Brass End Nut WTA8-546...
  • Page 23 TRI-12 Explosion CODE PART# DESCRIPTION QTY. WTA-5249 Chamber WTA-R01 ¾” Flo.-Et. Retainer 8 gpm WTA-F08 8 gpm Flo.-Et. WTA-5173 Site Port O-Ring WTA-5172 Site Port Lens WTA-5171 Site Port Nut WTA-268 Top Mounting Bracket WTA5-410 Lock Nut WTA8-544 End Nut O-Ring (seal quartz sleeve) WTA5-409 Brass End Nut WTA8-546...
  • Page 24 TRI-20 Explosion CODE PART# DESCRIPTION QTY. WTA-5266 Chamber WTA-5173 Site Port O-Ring WTA-5172 Site Port Lens WTA-5171 Site Port Nut WTA-270 Top Mounting Bracket WTA5-410 Lock Nut WTA8-544 End Nut O-Ring (seal quartz sleeve) WTA5-409 Brass End Nut WTA8-546 O-Ring (for shroud on end nut) WTA-7091 Gaynor Connector HS4-075-BK...
  • Page 25 Control Box Explosion...
  • Page 26 NOTES:...
  • Page 27 NOTES:...
