Systembuild Evolution 4847015COM Instruction Booklet page 18

16" cabinet

Advertisement

Available languages

Available languages

STEP 11
11
8
(x1)
(x2)
NOTE: The door can be mounted on either the left
panel or right panel, depending on which way you want
the door to open (right or left).
Shown is for the door to be mounted on the left panel.
Attach the door as shown by screwing the screws from
the hinge plate onto the side panel.
11
G
A
8
8
18
systembuild.com
