Model IS201 User Guide
Universal Dock

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IS201 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Marantz IS201

Summary of Contents for Marantz IS201

  • Page 1 Model IS201 User Guide Universal Dock...

  • Page 2: Risk Of Electric Shock

    CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ BEFORE OPERATING EQUIPMENT This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of. 1. Read these instructions. 2. Keep these instructions. 3.
  • Page 4 Este recibo deberá guardarlo en un lugar seguro y utilizarlo como referencia cuando tenga que hacer uso del seguro o se ponga en contacto con Marantz. IMPORTANTE Cuando solicite el servicio otorgado por la garantia el usuario tiene la responsabilidad de demonstrar cuándo efectuó...
  • Page 5 The IS201 is in conformity with the EMC directive and low-voltage directive. Français Le IS201 est conforme à la directive EMC et à la directive sur les basses tensions. Deutsch Das Modell IS201 entspricht den EMC-Richtlinien und den Richtlinien für Niederspannungsgeräte.
  • Page 6 A NOTE ABOUT RECYCLING This product’s packaging materials are recyclable and can be reused. This product and the accessories packed together are the applicable product to the WEEE directive except batteries. Please dispose of any materials in accordance with your local recycling regulations. When discarding the unit, comply with your local rules or regulations.
  • Page 7 この 「安全上のご注意」 は、製品を安全に正しくお使いいただき、あなたや他の人々への危害や財産への損害 を未然に防止するため、いろいろな絵表示をしています。内容をよく理解してから本文をお読みください。 この表示を無視して、誤った取り扱いをすると、人が死亡または重傷を負 警告 う可能性が想定される内容を示しています。 この表示を無視して、誤った取り扱いをすると、人が傷害を負う可能性が想 注意 定される内容および物的損害のみの発生が想定される内容を示しています。 記号は禁止の行為であることを告げるものです。 図の中や近傍に具体的な禁止内容 （左図の場合は分解禁止） が描かれています。 ● 記号は行為を強制したり指示したりする内容を告げるものです。 図の中に具体的な指示内容 （左図の場合は電源プラグをコンセントから抜く） が描か れています。 △ 記号は注意を促す内容があることを告げるものです。 図の中に具体的な注意内容 （左図の場合は指をはさまれないように注意） が描かれて います。 ● 万一、煙が出ている、変なにおいや音がするなどの異常状態のまま使用すると火 ● 万一、内部に水などが入った場合は、まずACアダプターをコンセントから抜いて ● 万一、機器の内部に異物が入った場合は、まずACアダプターをコンセントから抜 ● 万一、この機器を落したり、キャビネットを破損した場合は、ACアダプターをコ 電源プラグを コンセントから抜く ● 風呂場では使用しないでください。火災・感電の原因となります。 警 告 水場での使用禁止...
  • Page 8 ● 雷が鳴り出したら、ACアダプターには触れないでください。感電の原因となりま 接触禁止 ● この機器に水が入ったり、ぬらさないようにご注意ください。火災・感電の原因 警 告 ● この機器の裏ぶた、キャビネット、カバーは絶対外さないでください。内部には ● この機器を改造しないでください。火災・感電の原因となります。 分解禁止 ● オーディオ機器を接続する場合は、各々の機器の取扱説明書をよく読み、ACアダ ● 製品に同梱しているＡＣアダプターのみ使用してください。製品に同梱していな ● 旅行などで長期間、この機器をご使用にならないときは安全のため必ずACアダプ ● お手入れの際は安全のためACアダプターをコンセントから抜いて行ってくださ ● 移動させる場合は、ACアダプターをコンセントから抜き、機器間の接続コードな 電源プラグを コンセントから抜く ● 調理台や加湿器のそばなど油煙や湯気が当たるような場所に置かないでくださ ● ぐらついた台の上や傾いた所など不安定な場所に置かないでください。落ちたり、 注 意 ● ACアダプターを熱器具に近づけないでください。コードの被ふくが溶けて、火 ● 窓を閉めきった自動車の中や直射日光が当たる場所など異常に温度が高くなる場 ● 湿気やほこりの多い場所に置かないでください。火災・感電の原因となることが ● 濡れた手でACアダプターを抜き差ししないでください。感電の原因となることが ● 5年に一度くらいは機器内部の掃除を販売店などにご相談ください。機器の内部 す。...

  • Page 9: Table Of Contents

    REMOTE CONTROLLER (RC201IS) ...4 OPERATION OF REMOTE CONTROLLER ...5 CONNECTION ...7 CONNECTING TO OUTLET ...7 WALL SETTING ...8 PUTTING YOUR iPod IN IS201 DOCK CONNECTOR ...9 HOOKING UP THE DOCK CONNECTOR ...12 SETTING ...14 MODE SETTING ...14 VIDEO OUTPUT MODE SWITCH ...14 TROUBLESHOOTING...15...

  • Page 10: Features

    FEATURES With this dock connector, you can connect your iPod with Marantz products or mini system components. • Easily attach and detach your iPod • Two types of set-up available (desktop type and on wall type) • With your iPod docked, you can control your iPod with the supplied remote controller •...

  • Page 11: Part Names

    PART NAMES UPPER SIDE Desktop type REAR SIDE q Dock connector Connects to your iPod’s dock connector. w iPod slot Insert the appropriate type of adapter to put your iPod. • Be sure to use the appropriate adapter e Red indicator Lights up when connected to AC power On Wall type source and blinks when receiving IR...

  • Page 12: Connector Part

    S-VIDEO OUT jack Connect to your AV amp’s/TV monitor’s video input jack. REMOTE CONTROLLER (RC201IS) c REMOTE jack Connect to your Marantz product with remote control jack (RC-5). v RS-232C jack Used to connect to an external control system.

  • Page 13: Operation Of Remote Controller

    Switches the input of connected your Marantz amp/receiver (some models are not operative). !5 VOLUME +-button Please to adjust the volume control of your marantz amplifier / AV receiver. OPERATION OF REMOTE CONTROLLER Please make sure the below instructions are followed when operating your remote controller.

  • Page 14: Battery Replacement

    The distance between the transmitter of the remote control and the IR SENSOR of the IS201 should be less than 5 meters. If the remote control is pointed in a direction other than the IR SENSOR or if there is an obstacle between them, use of the remote control may not be possible.

  • Page 15: Connection

    CONNECTION CONNECTING TO OUTLET Fit the appropriate AC plug adapter to the AC adaptor as shown below. • For UK Connect the AC adapter to the IS201’s DC IN jack. • For Europe • For U.S.A./Japan Plug the AC adapter into a suitable wall...

  • Page 16: Wall Setting

    WALL SETTING • Please note that supplied wall setting screws are used for wooden wall. • Make sure that screws are firmly secured to the wall (poll). • Make sure that there is no electric wiring or piping inside the wall. Note •...

  • Page 17: Putting Your Ipod In Is201 Dock Connector

    PUTTING YOUR iPod IN IS201 DOCK CONNECTOR Make sure that IS201 Dock Connector is plugged into a wall outlet. Depending on the type of iPod, insert the applicable iPod adapter into the dock connector slot, as shown below. • There are four types of iPod adapters; Types A, B, C & D.
  • Page 18 ¶ iPod (U2 Edition) ¶ iPod mini ¶ iPod Photo (4th Generation) ¶ iPod (4th Generation) ¶ iPod (3rd Generation) 20GB Type B 4GB / New 4GB / 6GB Type B 30GB Type B 20GB Type B 10GB / 15GB / 20GB Type B 60GB Type C...
  • Page 19 • If your iPod is inserted into the IS201 with the power off, or if you plugged the AC adapter into a wall outlet with your iPod inserted in the IS201, it may take some time for your iPod power to switch on and become operable.

  • Page 20: Hooking Up The Dock Connector

    HOOKING UP THE DOCK CONNECTOR Connecting to AV receiver Left TV Monitor speaker Connecting to Amp, Monitor S-VIDEO Left speaker Right speaker TV Monitor To Analog Audio output To S-video (red) (white) output AV SURROUND RECEIVER SR4600 INPUT SELECTOR SURROUND MODE 7.1CH INPUT S.
  • Page 21 Marantz product. In order to do this, set the dock connector’s switch to “INT.”, and set the remote jack on the connected Marantz product to “EXT.”.

  • Page 22: Setting

    OSD mode(default setting). OSD Mode (On Screen Display Mode) Only remote controller can control your iPod. “marantz” is shown on your iPod’s display. The connected TV’s screen shows the Control Menu to control your iPod. Notes • Depending on the type of iPod, some settings are not supported.

  • Page 23: Troubleshooting

    Check your IS201 dock connector • Make sure the iPod is inserted properly in the dock connector. • Make sure there is nothing to block the infrared radiation between IS201 dock connector and remote controller. • Make sure you’ve selected the right mode for the remote mode switch on the rear of IS201 dock connector.

  • Page 24: Others

    In the event of difficulty, refer to your dealer or write directly to the nearest location to you that is listed on the Marantz Authorized Service Station list. If writing, please include the model and serial number of the...
  • Page 25 DIMENSIONS 84.0 1300.0 102.0 ( 3 3/8 ) ( 51 ) ( 4 1/16 ) Unit: mm (inch)
