- Page 1 Positioner and 3-position control unit -positrol -positurn2 Sicher und flexibel – die neue Antriebsgeneration actubar ATTENTION! New circuit board with new functions since 01.07.2014! Assembly, Mounting and Operating Instructions...
- Page 2 Operating Instructions bar-positurn2 and bar-positrol Read these instructions care- fully and keep them near to the device. Read, understand and follow the safety instructions. In General: These operating instructions are an inte- gral part of the device. The operating in- structions have to be kept with the device for the whole of its service life.
- Page 3 Earlier instructions a better understanding of in- lose their validity. The General Terms and structions or a better handling Conditions for Sales and Delivery as prescri- of the unit. bed by bar GmbH are to be adhered to.
- Page 4 Valid here are the Terms of Warranty from tems and equipment in whatever form in bar GmbH, which we will send to you upon the surrounding environment around the request. product, which result from a fault of the pro- duct or in this documentation.
- Page 5 GmbH. Please get in contact with our indicator without any activation. customer service department before sen- ding the goods.
-
Page 6: Functional Description
The pneumatic connection of the positrol is made at the housing. Functional Description: In its standard form, the bar-positurn2 / The bar-positurn2 is mounted positrol is designed and manufactured for • with a bracket onto actuators with inter- actuators with a closing direction for valves face acc. -
Page 7: Technical Data
Operating Instructions bar-positurn2 and bar-positrol Technical data: Device Type positurn positrol Materials Housing GD-AlSi 10Mg (Aluminiumdruckguss) Screws A2-70 (Edelstahl) Viewing glass PMMA Optical fibre Cable connection Pivoting angle 10° to 190° Protection Type IP65 IP67 Mounting position random Ambient temperatur -10°C to + 50°C... - Page 8 (RoHS). The directive of conformity will be turn are complying with the directives send on request. 2014/30/EU (EMC) and 2011/65/EU Pneumatic Scheme: positurn Pneumatic scheme for PN2-E (single-acting) PN2-S (double-acting) bar-positurn2 PN2-D Pneumatic schemes for the safety-orientated bar-positurn2 Please note the unit-specific safety descriptions.
- Page 9 (e.g. Controlling the Delivery: with photographs and a written report), The unit is dispatched from bar GmbH and before you unpack the unit. bar GmbH is transported by selected transport compa- not responsible in any way for transport da- nies i.e.
- Page 10 GmbH. Later complaints about be accepted. Mounting: Mounting positurn WARNING! • Open the bar-positurn2 and set it onto the actuator. Mounting may only be carried • Take special care to avoid the entry of out by suitably trained skilled dust, dirt and moisture getting into the persons.
-
Page 11: Installation
Operating Instructions bar-positurn2 and bar-positrol • Fix in position the bar-positurn2 and • Take care to ensure the correct direction solenoid valves by making use of the when assembling the housing cover. mounting materials supplied. The flexible fibre-optic light guides must •... - Page 12 80 x 30 vacotrol-air ducts drill template 130 x 30 • Open the bar-positrol and set it onto the • Place the position indicator on top and actuator. take care to see that the symbol position • Take special care to avoid the entry of coincides with the valve function.
- Page 13 Operating Instructions bar-positurn2 and bar-positrol positrol on actuator type according to VDI/ Air supply VDE 3845: Air supply positrol G-1/8“ Throttle Connect working channels according to connection designation (2→2; 4→4) Electric connection / Functional scheme: WARNING! Otherwise there is a real dan- ger of electric shocks.
-
Page 14: Elektrischer Anschluss
Operating Instructions bar-positurn2 and bar-positrol Elektrischer Anschluss: Positioner Electric Connections: model positurn: PN2-D; PN2-E und PN2-S model positrol: PL-D; PL-E und PL-S Refeeding of clamps Activate magnet A (counter-clockwise rotation) Digital Activate magnet B (clockwise rotation) 1, 2, 3 and 8 results Inputs a ccross clamp 14. - Page 15 Operating Instructions bar-positurn2 and bar-positrol Einstellmöglichkeiten: ATTENTION! Do not damage switches! Operating Potentiometer Program switch: analog = Positioner mode = 3-Position mode LED indication Current / Voltage switches Initialising switch Button for automatic initialisation Set current / voltage switches according to the signal type for the unit.
- Page 16 Operating Instructions bar-positurn2 and bar-positrol Individual Settings: Set operating direction switch according to the direction of actuation for the valve actuator. Left-rotating actuator in switch position ccw (L) Input and Output signal ccw increasing Right-rotating actuator in switch position cw (R)
- Page 17 Operating Instructions bar-positurn2 and bar-positrol 6. Establish power supply. 9. Start up by switching back the Initialisation switch from „Init“ to „Run“. Press the red button for the automa- tic initialisation longer than 2 seconds. Chaser light during the initialisation ...
- Page 18 Operating Instructions bar-positurn2 and bar-positrol Manual initialisation of Positioner mode (learning the positions and other specific values): 1. Check whether the operating direction power for more than 10 seconds after switch has been set in accordance with the end positions are reached.
- Page 19 Operating Instructions bar-positurn2 and bar-positrol ATTENTION! • Please note that all safety functions are immediately available when switching the initialisation switch from „Init“ to „Run“. This can cause an immediate swit- ching of the actuator! • In case of every (even accidental) switching to “Init“, the whole initialisation process must be carried out anew, because the previously learned values will have been lost.
- Page 20 Operating Instructions bar-positurn2 and bar-positrol Manual Initialisation of 3-Position mode (learning end positions and other specific values): 9. Start up by switching back initialisa- tion switch from „Init“ to „Run“. 10. Set the middle position by terminal 3 (24 VDC) and adjust via the Potentiometer.
- Page 21 Operating Instructions bar-positurn2 and bar-positrol ATTENTION! • Please note that all safety functions are immediately available when switching the initialisation switch from „Init“ to „Run“. This can cause an immediate swit- ching of the actuator! • In case of every (even accidental) switching to „Init“, the whole initialisation pro- cess must be carried out anew, because the previously learned values will have been lost.
- Page 22 Operating Instructions bar-positurn2 and bar-positrol Description of Safety Functions: Positioner mode 4–20 mA: Unit type: PN2-D / PL-D Valve persists in last position • Current supply Terminal 13 + 14 missing Valve persists in last position • Analog input Terminal 8 missing ...
- Page 23 Operating Instructions bar-positurn2 and bar-positrol Description of Safety Functions: Positioner mode 0–20 mA: Unit type: PN2-D / PL-D • Current supply Terminal 13 + 14 missing Valve persists in last position • Analog input Terminal 8 missing Valve moves to 0 Volt-position Unit type: PN2-S / PL-S •...
- Page 24 Operating Instructions bar-positurn2 and bar-positrol Description of Safety Functions: 3-Positions mode: Unit type: PN2-3P-D / PL-3P-D Armatur verharrt • Digital input Terminal 1, 2 and 3 missing Armatur verharrt • Current supply Terminal 13 + 14 missing Unit type: PN2-3P-S / PL-3P-S ...
- Page 25 Operating Instructions bar-positurn2 and bar-positrol Setting the End Positions and the Actuating Speed: positurn: ATTENTION! • When using manual operation at the pneumatic valves you have to return them to the in- itial position afterwards. • After every change in the end...
- Page 26 Operating Instructions bar-positurn2 and bar-positrol Changing the safety position: positurn: positrol: Only unit type Only unit type PN2-S-S or PN2-S-M! PL-S! ACHTUNG! ACHTUNG! • Before loosening any screws, • Before loosening any screws, make sure there is no more make sure there is no more...
- Page 27 Operating Instructions bar-positurn2 and bar-positrol Faults and their Correction: Description Possible Cause Correction Actuator does not move. 1. Air supply not correctly 1. Check air pressure and connected supply line 2. Solenoid valves not 2. Check valve connections. correctly connected 3.
- Page 28 • bar-positurn2 / bar-positrol works main- • Clean the housing of the bar-positurn2 tenance-free. with a clean, slightly moistened cloth. • In case of defects, which take place in- •...
- Page 29 Operating Instructions bar-positurn2 and bar-positrol Guarantee: We guarantee the fault-free function of our are the Terms of Warranty from bar GmbH, product according to our advertising, the which we will send to you upon request. product information and this documentation issued by us.
- Page 30 Operating Instructions bar-positurn2 and bar-positrol bar pneumatische Steuerungssysteme GmbH Auf der Hohl 1 53547 Dattenberg Tel. +49 (0) 2644 - 96070 Fax +49 (0) 2644 - 960735 www.bar-gmbh.de www.bar-gmbh.de vertrieb@bar-gmbh.de...
