Summary of Contents for Sonos Move
- Page 1 Move Guides Move...
- Page 2 Freedom of control using the Sonos S2 or Sonos S1 app, the touch controls on the speaker, or your voice. Compatible with all your other Sonos speakers for multi- room listening. See Setup when you're ready to add Move to your Sonos System.
-
Page 3: Controls And Lights
Volume down (left) Touch and hold to quickly Volume control change the volume. Note: You can also use the Sonos app and voice control to adjust volume. Press once to play or pause music. Press and hold to add Play/Pause the music that’s... - Page 4 Tap to turn the microphone on or off: When the microphone light is on, voice control and microphone-dependent features like auto Trueplay are available. When the light is off, voice control and microphone-dependent features like auto Microphone Trueplay are unavailable. Note: If you’ve installed a voice service and the microphone is off, you can...
- Page 5 Battery light Battery Saver: To save battery life, you can set Move to power off automatically instead of going to sleep. Go to > System, and select Move. It won't appear in the Sonos app until it’s...
-
Page 6: Connector Panel
Press to power on, short press to put to sleep, long press (5 seconds) to power off. If Move is off the charging base, it goes to sleep to save battery when you’re not using it. Just press the power button to wake it up. -
Page 7: Select A Location
You can put your speaker just about anywhere. For maximum performance, here's a few guidelines: Move sounds great even when placed next to a wall or on a shelf. For best performance, leave at least 1" (2.5cm) space around the back of the speaker. -
Page 8: Bluetooth Pairing
Move to Bluetooth. Switch modes Set Move up on your WiFi, then use the mode switch on the back of Move to switch between Bluetooth and WiFi. When you use Bluetooth for the first time, you’ll need to pair Move with your device. - Page 9 Charging Just set Move on its charging base for easy recharging—no extra wires or cables needed. Make sure the speaker is seated properly in the base and the charging contacts are Charging base touching. Charging base is for indoor use only—be sure to keep it dry.
-
Page 10: Microphone On/Off
Sonos Voice Control comes ready to use—it only takes a few seconds to add when you set up your speakers. More information Amazon Alexa: you’ll need the Sonos app and the Alexa app with the Sonos skill enabled. You’ll make some changes in both apps during setup. Learn more Google Assistant: you’ll need the Sonos app and the Google Assistant app. - Page 11 Trueplay™ Every room is different. Trueplay tuning measures how sound reflects off walls, furnishings, and other surfaces in a room, then fine tunes your Sonos speaker to make sure it sounds great no matter where you've placed it. Trueplay works on iOS mobile devices running iOS 8 or later. During tuning, you'll move around the room holding your mobile device.
-
Page 12: Product Settings
Product settings You can customize Sonos products for your surroundings. Go to > System and select a product. If you move your speaker to a new room, Room Name you can change its name in Settings. You can turn off your speaker’s WiFi when it’s connected to your network with an... - Page 13 Battery Saver automatically instead of going to sleep. It (portable products) won't appear in the Sonos app until it’s powered back on. Connect an audio device like a turntable or stereo to an Amp, Port, or Five. Go to Line-In Browse >...
-
Page 14: Specifications
Specifications Feature Description Audio Amplifier Two Class-D digital amplifiers. One tweeter creates a crisp and accurate Tweeter high frequency response. One mid-woofer ensures the faithful Mid-woofer playback of mid-range vocal frequencies plus deep, rich bass. Far-field microphone array. Microphone LED, hard-wired to the Microphones voice microphones for extra privacy control so you’re always aware when... - Page 15 ° ° ° Storage temperature -13 to 158 F (-25 to 70 C) Move meets IP56 water and dust resistance levels. Just don’t leave it out in a soaking rainstorm. Humidity resistant Note: The charging base included with Move is for indoor use only.
- Page 16 Feature Description Black with black grille, white with white Product finish grille Sonos Move, charging base, and Package contents Quickstart guide. * Specifications subject to change without notice.
-
Page 17: Important Safety Information
5. Clean only with a dry soft cloth. Household cleaners or solvents can damage the finish on your Sonos products. Sonos products with rubber rings on the bottom, such as Move, One, and One SL, may leave a faint ring on some surfaces treated with polyurethane. This ring can be easily removed by wiping with a damp cloth. - Page 18 Warning: Sonos Move meets IP56 water resistance levels. To reduce the risk of fire or electric shock, don’t expose this apparatus to a soaking rainstorm.
