CHINT NXR-12 User Instruction page 5

Setting current
Model
range A
5.5~8
NXR-12
NXR-25 7~10
9~12
NXR-12
9~13
12~18
NXR-25
17~25
23~32
NXR-38
30~38
23~32
30~40
37~50
48~65
NXR-100
55~70
63~80
80~93
80~100
Specification of matching fuse
gG (Recommend RT16) A
20
20
25
25
35
50
63
80
63
100
100
100
125
125
160
160
03
Table 3 (continued)
Sectional area of
connecting wire mm²
1
1.5
2.5
2.5
2.5
4
6
10
6
10
10
16
25
25
35
35
