Thank you for purchasing our Calico Designs
Gracias por comprar nuestro mueble Calico Designs
Merci d'avoir acheté un meuble Calico Designs
L CART
Model #50100 Black / Clear Glass
Model #50101 Silver / Clear Glass
Model #50105 Pink / White Glass
Product Support Line:
866.942.0492
Rev. 5.1.2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CALICO DESIGNS 50100
Summary of Contents for CALICO DESIGNS 50100
- Page 1 Thank you for purchasing our Calico Designs Gracias por comprar nuestro mueble Calico Designs Merci d’avoir acheté un meuble Calico Designs L CART Model #50100 Black / Clear Glass Model #50101 Silver / Clear Glass Model #50105 Pink / White Glass Product Support Line: 866.942.0492...
- Page 2 ASSEMBLY INSTRUCTIONS - IMPORTANT: CAREFULLY UNPACK & IDENTIFY EACH COMPONENT BEFORE ATTEMPTING TO ASSEMBLE. REFER TO PARTS LIST. PLEASE TAKE CARE WHEN ASSEMBLING THE UNIT AND ALWAYS SET THE PARTS ON A CLEAN, SOFT SURFA IF YOU REQUIRE ANY ASSISTANCE WITH ASSEMBLY, PARTS, OR INFORMATION ON OTHER PRODUCTS, PLEASE VISIT OUR WEBSITE: WWW.CALICO-DESIGNS.COM WARNING! GLASS TOP MAXIMUM WEIGHT CAPACITY LIMIT: 50 LBS/22,72 kg.
-
Page 3: Parts List
PARTS LIST PIECE LEG - 1 LEFT AND 1 RIGHT REAR STABILIZER TOP TUBE BOTTOM TUBE GLASS TOP KEYBOARD SHELF BOTTOM SHELF KEYBOARD SLIDERS - 1 LEFT AND 1 RIGHT P. 3... - Page 4 PARTS LIST PIECE LOCKING CASTER NON-LOCKING CASTER GLASS SPACER 12. ALLEN BOLT - 1/4” X 5/8” 13. NUT 14. PHILLIPS SCREW HEX WRENCH ALLEN WRENCH P. 4...
- Page 5 • ATTACH TOP TUBES (3) TO LEFT AND RIGHT LEGS (1) USING ALLEN BOLTS (12) AND ALLEN WRENCH (16) (**HOLES FACE UP, SEE ARROWS) (DO NOT TIGHTEN ANY NUTS OR BOLTS UNTIL LAST STEP). • ATTACH BOTTOM TUBES (4) TO LEGS (1) USING ALLEN BOLTS (12), AND ALLEN WRENCH (16). P.
- Page 6 • SCREW LOCKING AND NON-LOCKING CASTERS (9 AND 10) INTO BOTTOM OF LEGS (1) USIN HEX WRENCH (15). • PULL KEYBOARD SLIDERS (8) APART AND ATTACH USING PHILLIPS SCREWS (14). P. 6...
- Page 7 • CONNECT REAR STABILIZERS (2) AT CENTER USING ALLEN BOLT (12) AND NUT (13). • ATTACH ENDS OF REAR STABILIZERS (2) TO LEGS (1) USING ALLEN BOLTS (12). • ATTACH KEYBOARD SHELF (6) TO KEYBOARD SLIDERS USING PHILLIPS SCREWS (14). P.
- Page 8 • INSERT GLASS SPACERS (11) INTO HOLES IN TOP TUBES (3). • CAREFULLY PLACE GLASS TOP (5) ONTO SPACERS (11). • PLACE BOTTOM SHELF (7) ONTO BOTTOM TUBES (4) (IT SHOULD SNAP INTO PLACE). (TIGHTEN ALL NUTS AND BOLTS) P. 8...
-
Page 9: Limited Warranty
GARANTIE LIMITÉE Calico Designs (la « Compagnie ») garantit à l’acheteur original que ce produit sera exempt de tout défaut de fabrication et matériel s’il est utilisé à la maison et dans des conditions d’exploitation normales, tel que décrit à la présente. La Compagnie réparera ou remplacera, à...
Need help?
Do you have a question about the 50100 and is the answer not in the manual?
Questions and answers
The keyboard sliders holes does not match up with the holes on the bar
If the keyboard slider holes do not match with the bar on CALICO DESIGNS part number 50100, try the following steps:
1. Check Alignment – Ensure that the keyboard sliders (8) are properly pulled apart before attaching them.
2. Verify Parts – Confirm that you are using the correct Phillips screws (14) and the correct components as listed in the manual.
3. Loosen and Adjust – Loosen the screws slightly and align the sliders with the holes before fully tightening.
4. Reposition Components – Make sure the rear stabilizers (2) and legs (1) are correctly assembled, as misalignment in these parts may affect the keyboard slider placement.
5. Double-Check Orientation – Ensure that the holes are facing in the correct direction as indicated in the assembly instructions.
If the issue persists, check if any parts are defective or improperly manufactured, and contact product support for replacement parts or further assistance.
This answer is automatically generated
Which are the back stabilizer bars the one on top or the bottom? And where does the top and bottom tubes go?
The back stabilizer bars on the CALICO DESIGNS 50100 are the rear stabilizers, which are attached at the center and to the legs. The top tubes attach to the left and right legs with Allen bolts, ensuring the holes face up. The bottom tubes also attach to the legs using Allen bolts.
This answer is automatically generated
