USER MANUAL
PURE SINE WAVE
EXIDE INVERTERZ
For any service related issue
call our Toll Free No. 1800–103–5454
Exide Industries Ltd.
59E, Chowringhee Road, Kolkata – 700 020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Inverterz GQP 12V 7009VA and is the answer not in the manual?

Questions and answers

Summary of Contents for Exide Inverterz GQP 12V 7009VA

  • Page 1 USER MANUAL PURE SINE WAVE EXIDE INVERTERZ For any service related issue call our Toll Free No. 1800–103–5454 Exide Industries Ltd. 59E, Chowringhee Road, Kolkata – 700 020...
  • Page 2 This manual provides you through understanding of your Exide Inverterz and its optimum use. Please read installation and operating instructions in the manual carefully before installing and using you Exide Inverterz GQP Pure Sine. Pay special attention to the CAUTION and WARNING statements in this manual.
  • Page 3 About the EXIDE INVERTERZ GQP Exide Inverterz Exide Inverterz GQP Pure Sine Wave transforms Direct Current (DC) to Alternating Current (AC). The battery acts as a reservoir ensuring continuous supply when utility power is not available. Controls Front Panel - There is ON/OFF Switch and LCD & LED Display.
  • Page 4 Rear Panel Exide Inverterz GQP Pure Sine Wave has two battery wires coming out from the rear side, MCB of 6 Amp (for 700VA, 900VA & 1125VA) and 10Amp MCB (for 1625VA & 1425VA). AC output socket and a three pin top power cord to connect with mains supply.
  • Page 5: Important Precautions

    Some Safety Measures Important Precautions The output side of the AC wiring of Exide Inverterz should never be connected to utility power or a DG set. This condition is far worse than a short circuit. If the unit survives this condition, it will shut down until connections are made.
  • Page 6: Special Notices

    SPECIAL NOTICES: 1. The Exide Inverterz is for use with a nominal supply voltage of 12V/ 24V DC. 2. No AC or DC disconnects are provided as an integral part of this system. 3. No over current protection for the battery supply is proved as an integral part of this system.
  • Page 7: Charging Mode

    Battery Boost Voltage 14.4V ± 0.2V 28.8V ± 0.4V Battery Float Voltage 13.7V ± 0.2V 27.4V ± 0.4V Charging Technique Automatic Sense Intelligent Control (ASIC) LOAD CHART EXIDE INVERTERZ * Model 700VA 900VA 1125VA 1450VA 1625VA Options C D A B...
  • Page 8: Application Chart

    The system should be installed in a location that meets the following requirements: a) Dry – Do not allow to water to drip or splash on the Exide Inverterz b) Cool – The ambient air temperature around the system should be between...
  • Page 9: How To Install

    How to Install DC Cabling: 1. Ensure that the ON/OFF switch on the front panel of the Inverterz if OFF position before you begin the installation. 2. Connect the negative terminal of the battery to the thick black wire of system 3.
  • Page 10: Maintenance

    1. Check to see that the Exide Inverterz is turned off and then apply battery (DC) power to it. Ensure that all wiring has been installed properly. Next turn On the battery bank DC disconnects or connect the proper fuse in line to the battery to compete the battery circuit.
  • Page 11: Troubleshooting Guide

    No Display battery connection loose proper connections Reduce the excessive load No output voltage Excess Load Applied from the Exide Inverterz & Overload indication reset by ON/OFF Switch Call the service support. There No output voltage. Thermal shut down is overheat problem in the...
  • Page 12: Technical Specifications

    Specifications Technical Specifications Model with Rating Parameters 7009VA 900vA 1125VA 1450VA 1625VA No Load Output Voltage 220V ± 7V Output Frequency 50Hz ± 1Hz Output Wave Form Pure Sine Wave Nominal Battery Voltage 21.0V ± Battery Low Cut Off 10.5V ± 0.2V 0.4V Mains Input Voltage Range 100V - 280V ±...
