- Page 1 USER MANUAL PURE SINE WAVE EXIDE INVERTERZ For any service related issue call our Toll Free No. 1800–103–5454 Exide Industries Ltd. 59E, Chowringhee Road, Kolkata – 700 020...
- Page 2 Dear Valued Customer, We congratulate you for your excellent choice of our Exide Inverterz Star Pure Sine Wave. Exide Inverterz Star Pure Sine Wave will provide you complete comfort during the absence of utility power and provide your appliances the exact replication of mains supply because of the latest Technology.
- Page 3 About the EXIDE INVERTERZ STAR Exide Inverterz Star Pure Sine Wave transforms Direct Current (DC) to Alternating Current (AC). The battery acts as a reservoir ensuring continuous supply when utility power is not available. Controls Front Panel Graphic Description Indication...
- Page 4 Rear Panel Exide Inverterz Star Pure Sine Wave has two battery wires coming out from the rear side, a Circuit Breaker 7/ 10 /12 Amp (7Amp for 700VA & 900VA,1125VA 1375VA and 10Amp for 1625VA & 12A 2550VA), output socket and a three pin top power cord to connect with mains supply.
-
Page 5: Important Precautions
Some Safety Measures Important Precautions The output side of the AC wiring of Exide Inverterz Star should never be connected to utility power or a DG set. This condition is far worse than a short circuit. If the unit survives this condition, it will shut down until connections are made. -
Page 6: Personal Precautions
SPECIAL NOTICES: 1. The Exide Inverterz charge is for use with a nominal supply voltage of 12V/ 24V DC. 2. No AC or DC disconnects are provided as an integral part of this system. 3. No over current protection for the battery supply is proved as an integral part of this system. - Page 7 2550VA Fast Charging Current (±1A) Normal Charging Current (±1A) Battery Boost Voltage 14.4V ± 0.2V 28.8V ± 0.4V Battery Float Voltage 13.7V ± 0.2V 27.4V ± 0.4V LOAD CHART EXIDE INVERTERZ * RATING 700VA 900VA 1125VA 1375VA 1625VA 2550VA Options...
-
Page 8: Where To Install
The system should be installed in a location that meets the following requirements a) Dry – Do not allow to water to drip or splash on the Exide Inverterz b) Cool – The ambient air temperature around the system should be between... -
Page 9: How To Install
How to Install DC Cabling: 1. Ensure that the ON/OFF switch on the front panel of the Inverterz if OFF position before you begin the installation. 2. Connect the negative terminal of the battery to the thick black wire of system 3. -
Page 10: Maintenance
1. Check to see that the Exide Inverterz is turned off and then apply battery (DC) power to it. Ensure that all wiring has been installed properly. Next turn On the battery bank DC disconnects or connect the proper fuse in line to the battery to compete the battery circuit. -
Page 11: Troubleshooting Guide
No Indication battery connection loose proper connections Reduce the excessive load No output voltage Excess Load Applied from the Exide Inverterz & Overload indication reset by ON/OFF Switch Call the service support. There No output voltage Thermal shut down is overheat problem in the... -
Page 12: Technical Specifications
Specifications Technical Specifications Model with Rating STAR STAR STAR STAR STAR STAR STAR Parameters 700VA 900VA 1125VA 1375VA 1625VA 1625VA 2550VA No Load Output Voltage 220V ± 7V Output Frequency 50Hz ± 1Hz Output Wave Form Pure Sine Wave Nominal Battery Voltage Battery Low Cut Off 10.5V ±...
