Coco - Assembly Instructions
List of parts:
- 5 caster wheels
-1 chair base
-1 pneumatic lift
- 1 backrest
- 1 seat
- 2 armrest
- 1 mechanism
- 6 M6x25 screws
- 3 M8x20 screws
- spring washers M8
- 1 hex key (L-shaped)
HOW TO USE THE COCO CHAIR
D
C
A
REMARKS!
The chair is approved by the PUR "Remodex" Department of Research and Implementation for the Furniture
Industry with the Certificate of Durability, Stability and Safety of Use
GROSPOL Sp z o.o.
Ostródzka 53
03-289 Warsaw
www.grospol.pl
A - Seat height adjustment - Pulling a lever up
causes seat lifting. Releasing a lever causes
blocking the seat on the chosen height.
B - The backrest lock lever - turning the lever
forward blocks the backrest in the position you
expect. If the lever is moved backward, the
backrest will constantly follow the user's back
movement.
C - Armrest height adjustment - the armrests
have a height adjustment, which is done by
B
pressing and holding the button located in the
upper vertical part of the armrest structure.
D - Lumbar support - the backrest of the chair
has a support for the lumbar part of the spine.
Its height is constant.
ASSEMBLY
1. Press the wheels to the chair base.
3. Screw the armrest using the three screws
M6x25 for each armrest.
4. Screw the backrest to the mechanism that is
already in the seat with three M8x20 screws and
three washers M8.
2. Insert pneumatic lift in the hole of the chair
base.
5. Put seat with screwed backrest and armrests
on the gaslift which is already in the base
equipped with wheels.
