ASSEMBLY INSTRUCTIONS
BOX #1
A. TABLE TOP 1 PC
HARDWARE ENCLOSED IN BOX #2
No
Description
FLAT WASHER (5/16 " )
1
1
2
SPRING WASHER(5/16 " )
3
ALLEN BOLT ( 5/16" X 1
4
ALLEN KEY
SPANNER
5
REMARK 1:
IF THE TABLE TOP HALVES ARE NOT LEVEL AGAINST EACH
OTHER, ADJUST AS FOLLOWS.
Adjuster A
Adjuster B
Use for adjusting the Table Top
Use for adjusting the Table Top
extension up or down.
extension left or right
LUCIA DINING TABLE
PARTS PACKING CONFIGURATION
A
Quantity
16 PCS
16 PCS
" )
16 PCS
3/16
1 PC
1 PC
5
BOX #2
B 2 PCS
B. LEG
C 2 PCS
C. LEG
LUCIA DINING TABLE
X2
00:20
IF THE DINING TABLE WOBBLES DUE TO
UNEVEN FLOORING,THE LEVELERS UNDER
THE LEGS CAN BE ADJUSTED TO ENSURE
STABILITY.
REMARK 2:
PRESS THE LOCK BELOW SO THAT
IT WILL NOT STRETCH AT WILL
LOCK
C
B
Advertisement
Table of Contents
Related Manuals for Modus Furniture LUCIA LELB60
Summary of Contents for Modus Furniture LUCIA LELB60
- Page 1 LUCIA DINING TABLE ASSEMBLY INSTRUCTIONS PARTS PACKING CONFIGURATION BOX #2 BOX #1 B 2 PCS A. TABLE TOP 1 PC B. LEG C 2 PCS C. LEG HARDWARE ENCLOSED IN BOX #2 LUCIA DINING TABLE Description Photo Quantity FLAT WASHER (5/16 " ) 16 PCS SPRING WASHER(5/16 "...
- Page 2 LUCIA DINING TABLE ASSEMBLY INSTRUCTIONS PARTS PACKING CONFIGURATION HOW TO EXTEND THE DINING TABLE STEP 1: PULL TOP HALVES IN OPPOSITE DIRECTION STEP 2: PUSH TOP HALVES INWARD TO SECURE ASSEMBLY COMPLETE...
