Trail Kitchen Accessory:
Bolt-In KIt
I N S TA L L AT I O N I N S T R U C T I O N S
Step 1
Using a T45 socket, remove the (2)
factory D-rings closest to the back
seat and the next rear most D-ring on
the driver-side of the Jeep.
Step 2
Place (1) 3/4'' long spacer over
each factory rivnut where the
D-rings were previously located.
Step 3
Line up the holes of bolt-in
bracket with the (2) factory
rivnuts and 3/4" spacers located
behind the rear seat.
JP54-041
Heavy. D uty. Adventure.
www.MORryde.com • 574.293.1581
J K
YJ
Tools Needed:
• T45 Torx Wrench/Socket
• 1/2" Wrench
• 5mm Allen Wench
Step 4
Fasten bolt-in bracket into
rivnuts using (2) M6-1 x 30mm
socket head cap screws and
(2) supplied lock washers.
Step 5
Place plastic covers in the
clearance holes in the bolt-in
bracket to cover up the
hardware.
TJ
CJ
