MORryde THE CHAIR BUDDY Instructions

THE CHAIR
Mounting
Plate
2
T-Handle
3
Strut
19.50"
Minimum from
floor to bottom
of mounting
bracket.
NOTES:
DIMENSIONS IN INCHES U.N.O.
ALL DIMENSIONS OD U.N.O.
TOLERANCE OF DIMENSIONS
DECIMAL
FRACTIONAL ± 1/8
DESCRIPTION
CONFIDENTIALITY: THIS DRAWING & THE INFORMATION CONTAINED HERE ON ARE THE EXCLUSIVE ANGULAR ± 1°
PROPERTY OF MOR/RYDE. THEY SHALL NOT BE COPIED OR DUPLICATED WITHOUT OUR CONSENT.
Chair Buddy
BUDDY
1. Remove Chair Buddy
from packaging. DO NOT
CUT ZIP TIE at this time.
1
2.56
3. Measure from the line
to the floor to ensure it is
a minimum of 19.5".
5. With a 7/64th drill
DRAWN: DATE:
MIKE CASTER 12/23/2014
X.XXXX ± 0.010
CUST PART ID:
X.XXX ± 0.030
X.XX ± 0.060
...Opportunity Driven...
MATERIAL:
bit drill a pilot hole
/
FINISH: SHEET:
1 1
approximately 1" deep for
all four screw locations.
(Must drill pilot holes or
table post may split).
7. Cut zip tie. (Do not cut
before Chair Buddy
secure to the post with
at least the bottom two
screws).
is a patent pending product made by MORryde International, Inc.
TM
INSTRUCTIONS
TM
TM
6.94
8.56
CONFIDENTIALITY: THIS DRAWING & THE INFORMATION CONTAINED HERE ON ARE THE EXCLUSIVE
PROPERTY OF MOR/RYDE. THEY SHALL NOT BE COPIED OR DUPLICATED WITHOUT OUR CONSENT.
is
TM
1966 Sterling Avenue
PO Box 579
Elkhart, Indiana 46515
2. Position Chair Buddy
against post where Chair
Buddy is as high as possible
TM
on the post. T-handle should be
touching the underside of table.
(Zip tie must still be uncut).
Mark with a pencil the bottom
of the mounting face.
4. With a pencil mark the
four screw locations using the
mounting plate as your guide.
DIMENSIONS IN INCHES U.N.O. CB56-001
6. Using the provided screws
ALL DIMENSIONS OD U.N.O.
TOLERANCE OF DIMENSIONS
DECIMAL
DRAWN: DATE:
apenner
secure the Chair Buddy 12/12/2014
X.XXXX ± 0.010
CUST PART ID:
X.XXX ± 0.030
X.XX ± 0.060
MATERIAL:
the post only screwing in the
FRACTIONAL ± 1/8
FINISH:
ANGULAR ± 1°
bottom two screws.
8. Carefully pull Chair
Buddy T-Handle down.
TM
Using the provided screws
secure the top mounting
holes.
TM
to
TM
...Opportunity Driven...
SHEET:
/
4 4
