SCA3000 DEMO KIT User Manual TABLE OF CONTENTS 1 Introduction .........................3 2 Quick start for using the CMA3000 DEMO KIT ..............3 3 Hardware..........................4 4 GUI software ........................4 Resetting GUI and µC ......................10 Uninstalling the GUI and USB driver..................10 5 Advanced data logging.....................10 6 CMA3000 current consumption measurement with DEMO KIT ........12...
Demo is powered from USB port. The current GUI software does not support Windows Vista. The CMA3000 demo is based on the same USB hardware PCB as the SCA3000 DEMO KIT, also the same driver can be used with all demo kits provided by VTI Technologies.
SCA3000 DEMO KIT User Manual Hardware The CMA3000 DEMO KIT USB interface board (black PWB) and CMA3000 PWB (green PWB) are shown in Figure 1. The USB interface card converts the USB interface to SPI or I C interface. CMA3000 sensor is soldered on PWB which is connected to interface board.
Page 5
Selected sensor type and GUI software version number. Averaging ON / OFF, number of samples for averaging. Measuring range (G_RANGE bit setting). Pull down menu for CMA3000 operation mode & operation mode configuration. Pull down menu for GUI display mode.
Page 6
Figure 3. USB serial port selection pop-up window. User needs to select the correct product type from PRODUCT SELECTION pop-up window (Figure 4). CMA3000-D01 is selected by default. Figure 4. Product selection pop-up window. SCROLL, continuously scrolling X, Y, Z and resultant accelerations, see Figure 5.
Page 7
CMA3000 acceleration output is band pass filtered in motion detection mode. The transition from motion detection mode normal measurement is presented in Figure When motion is detected,...
Page 8
Averaging can be adjusted to smoothen the demo model movements. Figure 8. 3D demo display. REGISTER CONFIG display offers user access in to CMA3000 sensor internal registers. Registers can be read and written. The written data format can be changed between binary and hexadecimal by pressing the "Bits / Hex"...
Page 9
The used virtual serial COM port number can be viewed from "Serial port" display. This information is needed if the CMA3000 DEMO KIT is used without the GUI software, see further details from section In this example the CMA3000 DEMO KIT uses COM39 serial port.
“Transfer” pull down menu → “Capture Text…” → “Stop” Macro language is used to control the CMA3000 DEMO KIT. It can be also used to configure the CMA3000 sensor. For more detailed information of macro language, please refer to “SCA3000 DEMO KIT macro language description 8259200”.
Page 11
Connection properties 2. Connect 1. Select COM port Figure 12. Windows HyperTerminal with CMA3000 demo info text. If the pre-configured HyperTerminal connection is not available (the CD-ROM), the HyperTerminal connection can be opened also from: → Start → Programs → Accessories → Communications → HyperTerminal The communication settings are presented in Table 2 below Table 2.
The offset current consumption can also be measured by measuring the voltage drop over the resistor R34 (TP5 and TP6, see Figure 16) when CMA3000 PWB is not connected to USB interface board. SCA3000 current consumption can be calculated −...
DELL laptops (Latitude D600, D610, D410) and desktop PCs with Win2000 and WinXP operating system. If the CMA3000 DEMO KIT does not work properly or its operation is limited, the following items may help to sort the problems out: 1.
Checking and setting correct USB driver Latency timer value The FTDI USB Virtual Serial Com Port driver is delivered with the CMA3000 demo kit and the same driver version can be also downloaded from VTI's website. This driver is a slightly modified version of the original FTDI's driver: the driver used with VTI's demos must have a modified Latency timer setting.
Page 19
SCA3000 DEMO KIT User Manual VTI Technologies Oy 19/21 www.vti.fi Doc.Nr. 8288400.02 Rev.0.2 Downloaded from Elcodis.com electronic components distributor...
COM port numbers Figure 19. PC has assigned duplicate COM port numbers for two devices (LEFT), after changing the USB port there are no duplicate COM port numbers (RIGHT). VTI Technologies Oy 20/21 www.vti.fi Doc.Nr. 8288400.02 Rev.0.2 Downloaded from Elcodis.com...
The MCU needs to be reset (by pressing the reset button, see Figure 1) when changing between the two available serial bus types (SPI & I C). This thing can happen when user communicates with CMA3000 with macros that utilize different serial bus types. 10 Document Revision History Version...
