- Page 1 CS705 Snowfall Adapter Revision: 11/15 C o p y r i g h t © 1 9 9 7 - 2 0 1 5 C a m p b e l l S c i e n t i f i c ,...
- Page 3 Limited Warranty “Products manufactured by CSI are warranted by CSI to be free from defects in materials and workmanship under normal use and service for twelve months from the date of shipment unless otherwise specified in the corresponding product manual. (Product manuals are available for review online at www.campbellsci.com.) Products not manufactured by CSI, but that are resold by CSI, are warranted only to the limits extended by the original manufacturer.
- Page 4 SCIENTIFIC, INC., phone (435) 227-9000. After an application engineer determines the nature of the problem, an RMA number will be issued. Please write this number clearly on the outside of the shipping container. Campbell Scientific’s shipping address is: CAMPBELL SCIENTIFIC, INC.
- Page 5 Periodically (at least yearly) check electrical ground connections. • WHILE EVERY ATTEMPT IS MADE TO EMBODY THE HIGHEST DEGREE OF SAFETY IN ALL CAMPBELL SCIENTIFIC PRODUCTS, THE CUSTOMER ASSUMES ALL RISK FROM ANY INJURY RESULTING FROM IMPROPER INSTALLATION, USE, OR MAINTENANCE OF TRIPODS, TOWERS, OR ATTACHMENTS TO TRIPODS AND TOWERS SUCH AS SENSORS, CROSSARMS, ENCLOSURES, ANTENNAS, ETC.
-
Page 7: Table Of Contents
Mounting CM270 to the rain gage ............9 6-7. CM270 pipe mounting (exploded view) ..........10 6-8. CS705 mounted to pole using the CM270 Mounting Kit ....11 6-9. CS705 exploded view ................ 12 7-1. Mix ratio versus precipitation received ..........13... -
Page 9: Introduction
• The CS705 should be removed and cleaned in the summer, and reinstalled before the winter season. Initial Inspection Upon receipt of the CS705, inspect the packaging and contents for •... -
Page 10: Ships With
(3) Screws (pn 30978) • Overview The CS705 is manufactured by Campbell Scientific and is based on the paper “Measuring Winter Precipitation with an Antifreeze-Based Tipping Bucket System” presented at the 1996 Western Snow Conference (McCaughey and Farnes, 1996). The design possesses inherent delays and is not suitable for real time precipitation measurements. -
Page 11: Antifreeze
Tipping Bucket Compatibility The CS705 is equipped with a specially sized cylinder that allows it to nest within the 8-inch orifice of the TE525WS Texas Electronic Rain Gage. The CS705 cannot be directly used with TE525, TE525MM, CS700, or TB4 rain gages. -
Page 12: Installation
FIGURE 6-1. Proper gage siting Mounting Pole A user-supplied mounting pole or Campbell Scientific CM300-series stainless- steel mounting pole can be used to mount the CS705 away from the tripod or tower. CM300-series poles can be embedded directly into a concrete foundation (FIGURE 6-2) or used with a pedestal kit. -
Page 13: Cm310 56-Inch Pole Embedded In A Concrete Foundation
CS705 Snowfall Adapter 61 cm (24 in) 20 cm (8 in) FIGURE 6-2. CM310 56-inch pole embedded in a concrete foundation... -
Page 14: Pedestal Kit Options
CS705 Snowfall Adapter 61 cm (24 in) 36 cm (14 in) FIGURE 6-3. Pedestal kit options... -
Page 15: Cm270 Installation
CS705 Snowfall Adapter CM270 Installation Tools needed: Open end wrench, 7/16 inch open-ended wrench, or 7/16 inch socket • wrench. • Long #2 Phillips Screwdriver Remove manufacturer’s mounting hardware: 1. Remove the three feet mounted on the bottom of the rain gage. -
Page 16: Exploded View Of The Cm270 Mounting Bracket Kit
CS705 Snowfall Adapter Bubble level V-shaped Bolt Bolt plate V-shaped V-shaped plate leg plate leg Bolt S-shaped Cylindrical plate Leveling Leveling spacer spring spring Grommet Grommet Bottom plate Grommet FIGURE 6-4. Exploded view of the CM270 Mounting Bracket Kit V-shaped plate... -
Page 17: Mounting Cm270 To The Rain Gage
CS705 Snowfall Adapter Do the following to mount the tipping bucket rain gage to the CM270 bracket (FIGURE 6-6): NOTE Follow this procedure to ensure that the tipping bucket is mounted correctly. The adjustment screws for the tipping mechanism will not be accessible if it is mounted incorrectly. -
Page 18: Cm270 Pipe Mounting (Exploded View)
CS705 Snowfall Adapter Attach the mounting bracket/tipping bucket assembly to the mounting pipe or mast: 1. Install and level the mounting pipe or mast. 2. Loosen the mounting bracket’s wingnuts and slide the assembly over the pipe. If necessary, the pole mounting hardware can be removed to get the bolts around the pipe. -
Page 19: Cs705-To-Tipping Bucket Installation Procedure
Band Clamp (pn 20606) • Storage Mount (pn 20636) • Band Clamp Band Clamp (pn 20605) (pn 20606) Catch Tube Storage Mount (pn 20636) Antifreeze Reservoir TE525WS (purchased separately) FIGURE 6-8. CS705 mounted to pole using the CM270 Mounting Kit... -
Page 20: Cs705 Exploded View
CS705 Snowfall Adapter 1. Take one of the black bands supplied with the CS705 and stretch over the TE525WS funnel (see FIGURE and FIGURE 6-9). Catch Tube (pn 13641) Band (pn 10786) Overflow Tube (pn 10750) Antifreeze Reservoir (pn 13645) -
Page 21: Datalogger Programming
8. Fasten the catch tube of the CS705 to the mounting pole using the band clamps and storage mount (see FIGURE 6-8). 9. Place the pail below the rain gage. -
Page 22: References
When recharging, the solution should be disposed of in accordance with local, state, and federal regulations. The CS705 is recommended only for use during winter. It should be removed, cleaned, and carefully stored after the last snowfall, then reinstalled prior to the first snowfall of the coming winter. -
Page 23: Msds For Campbell Scientific Cs705 Antifreeze
EMERGENCY TELEPHONE NUMBER: (412) 981-3771 CHEMTREC EMERGENCY TELEPHONE NUMBER: (800) 424-9300 ADDRESS (NUMBER, STREET, CITY, STATE, ZIP): 2797 Freedland Rd. Hermitage, Pa. 16148 CHEMICAL NAME AND SYNONYMS: CAMPBELL SCIENTIFIC CS705 ANTIFREEZE TRADE NAME AND SYNONYMS: Same as above. CHEMICAL FAMILY: Solvent blend. FORMULA: Mixture... - Page 24 Appendix A. MSDS for Campbell Scientific CS705 Antifreeze Date Printed: 09-26-1997 Page 2 Interstate Chemical Co. MSDS for CAMPBELL SCIENTIFIC CS705 ANTIFREEZE 1899-- 4 — Section III – Physical Data BOILING POINT (INDICATE IF “F” OR “C”): 174-212 F VAPOR PRESSURE (mm Hg): 23 @ R.T.
- Page 25 Appendix A. MSDS for Campbell Scientific CS705 Antifreeze Date Printed: 09-26-1997 Page 3 Interstate Chemical Co. MSDS for CAMPBELL SCIENTIFIC CS705 ANTIFREEZE 1899-- 6 — Section V – Fire and Explosion Hazard Data (continued) UNUSUAL FIRE AND EXPLOSION HAZARDS: Vapors form from this product and may travel or be moved by air currents and ignited by pilot lights or other ignition sources.
- Page 26 Appendix A. MSDS for Campbell Scientific CS705 Antifreeze Date Printed: 09-26-1997 Page 4 Interstate Chemical Co. MSDS for CAMPBELL SCIENTIFIC CS705 ANTIFREEZE 1899-- 7 — Section VI – Health Hazard Data (continued) EFFECTS OF REPEATED OVEREXPOSURE: Long-term repeated overexposure to methanol vapor concentrations of 3000 ppm or greater may •...
- Page 27 Appendix A. MSDS for Campbell Scientific CS705 Antifreeze Date Printed: 09-26-1997 Page 5 Interstate Chemical Co. MSDS for CAMPBELL SCIENTIFIC CS705 ANTIFREEZE 1899-- 8 — Section VII – Reactivity Data STABILITY (choose one): ( ) UNSTABLE ( x ) STABLE * CONDITIONS TO AVOID: None.
- Page 28 Appendix A. MSDS for Campbell Scientific CS705 Antifreeze Date Printed: 09-26-1997 Page 6 Interstate Chemical Co. MSDS for CAMPBELL SCIENTIFIC CS705 ANTIFREEZE 1899-- 11 — Section X – Shipping Data D.O.T. SHIPPING NAME: FLAMMABLE LIQUIDS, N.O.S. (contains Ethanol) PRODUCT NAME: CAMPBELL SCIENTIFIC CS705 ANTIFREEZE D.O.T.
- Page 29 Appendix A. MSDS for Campbell Scientific CS705 Antifreeze Date Printed: 09-26-1997 Page 7 Interstate Chemical Co. MSDS for CAMPBELL SCIENTIFIC CS705 ANTIFREEZE 1899-- 12 — Section XI – Special Precautions (continued) TRANSFER HAZARD – Vapors of this product may be ignited by static sparks.
- Page 30 Appendix A. MSDS for Campbell Scientific CS705 Antifreeze...
- Page 32 Santo Domingo, Heredia 40305 SOUTH AFRICA COSTA RICA • cleroux@csafrica.co.za • info@campbellsci.cc www.campbellsci.co.za www.campbellsci.cc Campbell Scientific Southeast Asia Co., Ltd. Campbell Scientific Ltd. 877/22 Nirvana@Work, Rama 9 Road Campbell Park Suan Luang Subdistrict, Suan Luang District 80 Hathern Road Bangkok 10250...
