Summary of Contents for HAMECO HV-48
- Page 1 Intelligent 4K All-in-one Video Bar HV-48 User Manual www.hameco.eu...
-
Page 2: Attentions
HV-48 user manual ATTENTION This manual introduces functions, installations and operations for this product in details. Please read this manual carefully before installation and use. Precautions This product can only be used in the specified conditions in order to avoid any damage to the camera: 1. -
Page 3: Table Of Contents
HV-48 user manual Table of contents Attentions 1.Quick Start 1.1 Interfaces..................4 1.2 Device startup................1.2.1 Power on................. 4 1.2.2 Statue Indicator Light............4 1.3 Video Output................5 1.4 Audio Input................... 5 1.5 Audio Output................5 2. Product Overview 2.1 Product Introduction.............. -
Page 4: Quick Start
HV-48 user manual 1. Quick Start 1.1 Interfaces Interfaces USB audio video in out, type C HDMI HDMI video output LINE IN Audio linear input LINE OUT 3.5mm linear output Extension Mic RJ45 extension mic Power jacket HEC3800 power socket(DC12V), input AC110V-AC220V, output DC12V/2A 1.2 Device Startup... -
Page 5: Video Output
HV-48 user manual 1.3 Video Output 1. USB Connect device to Pcs through USB cable, and open the video software to select device to output. 2. HDMI Connect device to monitor through HDMI cable, and then select the correct in- put source on the monitor to output. -
Page 6: Product Overview
HV-43 user manual 2. Product Overview 2.1 Product Introduction 2.1.1 Dimension 2-1 Dimension 2.1.2 Supplied Accessory • Items Quantity Supplied o Optional • All in one video bar • USB Cable • Remote control • Quick start guide •... -
Page 7: Product Features
HV-43 user manual 2.2 Product Features With all in one design, this device has 4K UHD camera, microphone array, high fidelity speaker and electric privacy cover. Boasting powerful functions like face recognition, voice localization, voice tracking, and intelligent noise reduction, this product could au- tomatically adjust the image size according to the number of participants to present the optimal frame. -
Page 8: Technical Specification
HV-43 user manual 2.3 Technical Specification Type Item Description 120°(D) /106°(H)/ 72°(V) Iris F2.0 Lens Focal Length 1.89mm Digital Zoom Sensor High quality CMOS sensor, effective pixel 8 million, 16:9 Focus Auto/Manual Minimum illumination 0.5Lux 2D&3D On/Off Parameter can be adjusted, and AE... - Page 9 HV-43 user manual Type Item Description Pickup 6 meters Distance Microphone Frequency 120 Hz–16 kHz Response Speaker Built in dual speaker Voltage 2*10W Audio Output Speaker 80±3 dB 1.0M/1.0W Voice Pressure Frequency 100 Hz-20 KHz Response Audio AEC, AGC , ANS...
- Page 10 HV-43 user manual Type Item Description Bar-shaped While displaying the working status, it can also be lit where Indicator Indicator the speaker's voice comes from. Can be connected to a mobile phone or other device via Bluetooth Bluetooth 5.0...
-
Page 11: How To Use
HV-43 user manual 3. How to Use 3.1 Remote Control Number Function Description Bluetooth Auto Framing & Voice Tracking Menu HOME Up, down, left, right Answer call Microphone muted www.hameco.eu... -
Page 12: Menu Setting
HV-43 user manual Number Function Description Reject the incoming call Volume up/down Set/call out preset #1 (Long press 3 sec to set preset, short press to call out preset) Set/call out preset #2 (Long press 3 sec to set... - Page 13 HV-43 user manual 1) Language ← → Move arrow to (Language), and press ( )to change the option 2) Setting Move arrow to (Setting), and press (HOME) to enter the exposure interface. Image Style: Default/standard/clear/bright/soft Auto Framing: On/off Auto Framing Sen: High/medium/low Max Framing: 3X/5X/10X www.hameco.eu...
- Page 14 HV-43 user manual Voice Tracking: On/off Voice Tracking Sen: High/medium/low Locate Mode: Smart mode/pan mode/movie mode/discussion mode Prompt Info: On/off Menu Mirror: On/off Transfers Mode: Bulk/synchronization 3) Exposure Move arrow to (exposure), press (HOME) to enter exposure interface. Exposure mode: Auto/manual/shutter priority/bright priority...
- Page 15 HV-43 user manual BLC: On/off ( only available in auto mode) Anti-Flicker: 50Hz, 60Hz, off (only available in auto, iris priority, bright priority mode) Gain Limit: 0-15(only available in auto, iris priority, bright priority mode) Dynamic Range: 1 8, off...
- Page 16 HV-43 user manual 5) Image Move arrow to (image), and press (HOME) to enter image page. Brightness: 0 Contrast: 0 Sharpness: 0 Flip-H: On/off FlipV: On/off B&W Mode: Color/B&W Gamma: Default , 0.34 , Low Light Mode: On/off 0.39 , 0.47 , 0.50...
- Page 17 HV-43 user manual 2D NR: Auto, manual 1 3D NR: Off, 1 7) Version Move arrow to (version). 8) Restore Default Move arrow to (restore default), and press (HOME) to enter RESTORE DEFAULT page. Restore default: Yes/no (color style and video format cannot be restored)
-
Page 18: Maintenance And Troubleshooting
HV-43 user manual 3. Maintenance and Troubleshooting 3.1 Camera Maintenance 1) Please disconnect the camera if it is not used for a long time. 2) Use soft cloth or tissue to clean the camera cover. 3) Wipe it with a soft, dry cloth when cleaning the camera lens. Wipe it gently with a mild detergent if needed. -
Page 19: Compliance Statement
HV-43 user manual 4. Compliance statement This device complies with the related CE standards. 5. Product disposal Safety For your own safety, this product should only be used with CE and RoHS approved equip- ment. Using this headset with non-approved equipment would void the warranty of this product.
