- Page 1 HV-50 Video Conferencing Room Solution User Manual www.hameco-headset.com...
-
Page 2: Important
HV-50 Video Conferencing Room Solution User Manual IMPORTANT This manual introduces functions, installation and operations for HV- 50 video conferencing room solution in details. Please read this manual carefully before installation and use. How to Use To prevent damage to this product or any product connected to it, this product can only be used within the specified range. - Page 3 HV-50 Video Conferencing Room Solution User Manual Install with Caution 4.1. Do not rotate the camera head violently, otherwise it may cause me- chanical failure. 4.2. This product should be placed on a stable desktop or horizontal sur- face. Do not install the product obliquely, otherwise it may display in- clined image.
-
Page 4: Table Of Contents
CONTENT IMPORTANT ......................1 1. Packing Contents....................4 2. Product Overview ..................... 5 HV-50-A: Speakerphone ..............5 HV-50-V: HD PTZ Camera..............5 2.3. HV-50-H: Hub..................6 3. Connection Description ................... 7 4. Keys Description ....................8 Keys Description of Remote Control ..........8 Keys Description of Speakerphone .......... -
Page 5: Packing Contents
HV-50 Video Conferencing Room Solution User Manual PACKING CONTENTS Speakerphone HD PTZ Camera Remote Control 5m DIN6 Cable * 2 pcs 3m USB cable *1 pcs Power supply www.hameco-headset.com... -
Page 6: Product Overview
DIN6 cable port microphone port 1 IR remote control receiver Optional expansion Function keys microphone port 2 Status indicator 2.2. HV-50-V: HD PTZ Camera LAN Upgrade and Bracket mounting screw holes maintenance Bracket mounting DIN6 Cable port positioning hole Power and infrared receiving indicator www.hameco-headset.com... -
Page 7: Hv-50-H: Hub
HV-50 Video Conferencing Room Solution User Manual 2.3. HV-50-H: Hub DIN6 Cable port DIN6 Cable port Mini USB port Power port Power switch Power indicator Screw holes Wire slot www.hameco-headset.com... -
Page 8: Connection Description
HV-50 Video Conferencing Room Solution User Manual CONNECTION DESCRIPTION Connect camera and hub with original DIN6 data cable Connect the speakerphone and hub with original DIN6 data cable Connect the computer to the hub with the original USB cable Connect with the original power adapter and power supply Switch to power on www.hameco-headset.com... -
Page 9: Keys Description
HV-50 Video Conferencing Room Solution User Manual KEYS DESCRIPTION 4.1. Keys Description of Remote Control Device standby Zoom in Zoom out Volume up Volume down Pan / Tilt HOME Camera Zero position Mute microphone Pick up 10. Hang up 11. 0-9 Camera presets 12. -
Page 10: Keys Description Of Speakerphone
HV-50 Video Conferencing Room Solution User Manual 4.2. Keys Description of Remote Control 1-3 Presets Camera pan / tilt Zoom in / Zoom out Mute microphone Camera Zero position Pick up / Hang up Bluetooth pairing Volume up / volume down... -
Page 11: Work With Video Conferencing Software
Correctly connect HV-50. Login on your video conferencing software on the computer, and select the corresponding camera, microphone and speaker driver. The HV-50 and VC software will then serve your video conferencing needs perfectly. Refer to the image below (e.g.: ZOOM software) -
Page 12: Bluetooth Pairing
To pair your Bluetooth device with the speakerphone: Press and hold the Bluetooth pairing button until the status indicator flashes blue light. The speakerphone is under Bluetooth pairing mode. Search HV-50 with your Bluetooth device and connect. PRESET How to save preset: Adjust the camera to the position that needs to be preset. -
Page 13: Technical Specifications
HV-50 Video Conferencing Room Solution User Manual 8. TECHNICAL SPECIFICATIONS Model NO. HV-50-V Product Picture Sensor 1/2.8 inch high quality HD CMOS sensor Effective Pixels 2.07M,16:9 176x144/320x240/320x180/352x288/640x480/720x480/ Video Format 720x576/640x360/800X600/960X540/1024X576/ 1024X768/1280X720/1920X1080P30/25/20/15/10/5 Optical zoom lens 5x optical zoom, f=3.1~15.5mm View angle 20°... - Page 14 HV-50 Video Conferencing Room Solution User Manual >55dB Rotation angle Pan: -125°~+125°, Tilt:-30°~+30° Control speed Pan: 0.1 ~65°/sec, Tilt:0.1~35°/sec Preset speed Pan: 65°/sec, Tilt: 35°/sec Dimensions 151.64mm×131.25mm×154.5mm (L×W×H) Model NO. HV-50-A Product Picture Voice technical parameters Acoustic Echo cancellation (AEC): >65dB Echo length cancellation: ≥400ms...
- Page 15 HV-50 Video Conferencing Room Solution User Manual Model NO. HV-50-H Product Picture Interface Mini DIN6 ×2 Power interface × 1 Power switch × 1 Mini USB interface × 1 Power supply EC3800 plug (DC12V) Adapter input AC110V-AC220V, output DC12V/1.5A Connection Cable Mini DIN6 data line ×...
-
Page 16: Copyright Statement
HV-50 Video Conferencing Room Solution User Manual COPYRIGHT STATEMENT All the contents in this manual and its copyright are owned by the company. No one is allowed to imitate, copy, or translate this manual without the company’s permission. This manual contains no guarantee, standpoint ex- pression or other implicatiens in any form.
