- Page 1 EX1000-T/EX1000 Owners Manual EX1000 EX1000-T w w w . g r o w o n i x . c o m Built in the U.S.A. www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com...
- Page 2 Traditional RO systems have waste ratios of approximately 4:1, which means there are 4 gallons of waste water produced for every 1 gallon of purified water. GrowoniX line of water filters achieve waste ratios of 2:1 with all 200-400 GPD systems, and an astounding 1:1 ratio with the 600-1000 GPD systems.
- Page 3 Brackets. Membrane Flush Kit. EX1000 2.5” Stainless Steel Liquid Filled Gauges. EX1000-T Carbon Filter Rated For 34,000 Total Gals, Or 17,000 Gals Of Purified Water. EX1000 Carbon Filter Rated For 17,000 Total Gals, Or 8500 Gals Of Purified Water. High Flow Pleated Sediment Filter, Completely Washable And Reusable.
- Page 4 HF FLOW RATES 2600 77ºF 2400 2200 2000 60ºF 1800 1600 1400 50ºF 1200 1000 9 0 100 110 120 130 140 150 160 170 180 MEMBRANE PRESSURE (PSI) WITH OR WITHOUT PUMP Test Conditions: Permeate flow and salt rejection based on 550 ppm, 80 psi, 77°F (25°C), pH 7, and 50% recovery. SYSTEM SPECIFICATIONS Recovery (System Ratio) 50% (1:1)
- Page 5 • Solenoid valve with manual override for failsafe water-making. • FlowBox-1000 Adjustable System Ratios GrowoniX FlowBox is a componential add-on to any EX/GX1000 • that utilizes a BP Series booster pump. Equipped with highly accurate liquid flow-meters, the FlowBox •...
- Page 6 *Chloramine removal requires the KDF85 carbon filter. *EX1000 CARBON FILTER RATED AT 17,000 GALS TOTAL CAPACITY, OR 8,500 GALS OF FILTERD WATER AT 2:1 RATIO. *EX1000-T CARBON FILTER RATED AT 34,000 GALS TOTAL CAPACITY, OR 1,700 GALS OF FILTERD WATER AT 2:1 RATIO FILTER INDEX GXM HIGH FLOW COLD WATER MEMBRANES Highest flowing ultra-low-energy membranes on the planet—with the...
- Page 7 Pressure regulators are available at GrowoniX.com or your local plumbing supply. A minimum of 40psi is recommended to operate GrowoniX water filters. If your inlet water pressure is too low, a booster pump can be used to increase pressure.
-
Page 8: Component Diagram
COMPONENT DIAGRAM 1. SUPPLY WATER IN 10. SS CLAMP RING 2. INPUT PRESSURE GAUGE 11. FLUSH VALVE 3. OUTPUT PRESSURE GAUGE 12. FLOW RESTRICTOR 4. SEDIMENT FILTER 13. DRAIN/WASTE WATER OUT 5. CARBON FILTER 14. AUTO-SHUTOFF VALVE 6. RO MEMBRANE HOUSING 15. -
Page 9: Setup Instructions
Always turn incoming water pressure on slowly, allowing all air to be discharged from the system before full water pressure is restored. GrowoniX EX1000 water filters are designed to be used with between 40-80 psi of incoming water pressure. Do not exceed 80 psi of incoming water pressure. -
Page 10: Flushing The Kdf85 Carbon Filter
40 GALS FOR CF-4520-KDF *EX1000 CARBON FILTER RATED AT 17,000 GALS TOTAL CAPACITY, OR 8,500 GALS OF FILTERD WATER AT 1:1 RATIO. *EX1000-T CARBON FILTER RATED AT 34,000 GALS TOTAL CAPACITY, OR 17,000 GALS OF FILTERD WATER AT 1:1 RATIO. -
Page 11: Flushing The Membrane Element
FLUSHING THE MEMBRANE ELEMENT Growonix EX1000 water filters come with a manual flush valve. Flushing the membrane element after each use for approximately 3-5 minutes will remove standing salts from the membrane, significantly extending membrane life. Even weekly flushes will improve membrane life and system performance. - Page 12 *EX1000 CARBON FILTER RATED AT 17,000 GALS TOTAL CAPACITY, OR 8,500 GALS OF FILTERD WATER AT 1:1 RATIO. *EX1000-T CARBON FILTER RATED AT 34,000 GALS TOTAL CAPACITY, OR 17,000 GALS OF FILTERD WATER AT 1:1 RATIO. DETERMINING PRESSURE DROP VIA DUAL GAUGES...
- Page 13 If a KDF85 carbon filter is being used, make sure to flush the KDF carbon filter before connecting to the membrane input. (see section: Flushing The KDF85 Carbon FIlter) Built in the U.S.A. www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com...
- Page 14 REPLACING THE MEMBRANE ELEMENT Before servicing membrane element system must be de-pressurized. To de-pressurize the EX1000, turn incoming water supply completely OFF and open the flush valve. It is suggested that you replace sediment and carbon pre-filters as well when replacing membrane element.
- Page 15 Built in the U.S.A. www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com...
- Page 16 REPLACING THE MEMBRANE ELEMENT Newly seated membrane element. Grease the brine seal and end-cap center hole with food grade silicone grease. Seat the end-cap back into the input side Replace the stainless clamp on the of the membrane housing. input side of membrane housing. Tighten the stainless clamp retaining bolts evenly.
-
Page 17: Specifications Chart
Materials: Maximum Operating Pressure: 150 PSI NSF Stainless Steel • • NSF Approved EPR O-Rings Maximum Operating Temperature: 110˚F • • 1/2” Ports Minimum Operating Temperature: 35˚F • • Built in the U.S.A. www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com... - Page 18 Temperature Rating: 40 - 125˚F (4.4 - 51.7˚C) • Maximum Dimensions: EX1000 4 1/2" X 10” • EX1000-T 4 1/2" X 20" • Initial AP (PSI) @ Flow Rate (GPM): 0.90 PSI @ 4 GPM (.06 bar @ 15.1 L/m) •...
-
Page 19: Reverse Osmosis System Warranty
REVERSE OSMOSIS SYSTEM WARRANTY For a period of one year from the date of original purchase, we will replace or repair any part of the GrowoniX reverse osmosis water system that we find to be defective in operation du e to faulty materials or workmanship with the exception of the replaceable filters and membranes. - Page 20 EX1000-T/EX1000 Owners Manual EX1000 EX1000-T w w w . g r o w o n i x . c o m Built in the U.S.A.
