- Page 1 EX600T/1000T EX600/1000 Owners Manual w w w . g r o w o n i x . c o m www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com...
- Page 2 EX600 EX1000 EX600T EX1000T EX 600/1000 SERIES FEATURES The strategy behind the EX Series is simply to 600 TO 1000 GALLONS PER DAY make the highest quality, most efficient water 25 TO 42 GALLONS PER HOUR filter, tuned specifically to meet the rigors of the industry.
-
Page 3: System Specifications
Maximum Hardness : 15 gpg increase GPD output. Test Conditions: Permeate flow and salt rejection based on 550 ppm, 80 psi, 77°F (25°C), pH 7, and 50% recovery. www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com... - Page 4 FLOW RATES 100GPD — 400GPD FILTER FLOW RATES EX/GX400-HF, 77ºF EX/GX400-HF, 60ºF EX/GX400-HF, 50ºF EX/GX200-HF, 77ºF EX/GX200-HF, 60ºF EX/GX200-HF, 50ºF EX100-HF, 77ºF EX100-HF, 60ºF EX100-HF, 50ºF WATER PRESSURE (PSI) WITH OR WITHOUT PUMP 600GPD — 1000GPD FILTER FLOW RATES 2800 2600 EX/GX1000-HF, 77ºF 2400...
- Page 5 EX400-tall, Slim Scrub 71.00 Must for well water and chloramine removal 5,700 Gallons RO Water 34,000 Gallons Total CF-4520-KDF Premium Carbon EX600/1000-Tall, XL Scrub 127.00 Must for well water and chloramine removal 17,000 Gallons RO www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com...
- Page 6 Integral as EX1000, EX1000T a feed pump and return pump for UV STERILIZATION GrowoniX smaller nutrient top feed systems, the DDP-6 can withstand Stainless steel ultraviolet filtration to the most rigorous of duties. Built in remove 99.9% of micro- organisms in...
-
Page 7: Table Of Contents
INFORMATION ON QUICK CONNECT FITTINGS COMPONENT DIAGRAM SETUP INSTRUCTIONS FLUSHING THE KDF85 CARBON FILTER FLUSHING THE MEMBRANE ELEMENT REPLACING SEDIMENT AND CARBON PRE-FILTERS REPLACING MEMBRANE ELEMENT SPECIFICATIONS CHARTS RO SYSTEM WARRANTY / RETURN POLICY REPLACEMENT PARTS www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com... -
Page 8: Introduction
Traditional RO systems have waste ratios of approximately 4:1, which means there are 4 gallons of waste water produced for every 1 gallon of purified water. GrowoniX line of water filters achieve waste ratios of 2:1 with the EX100 through GX400 and an astounding 1:1 ratio with the GX600 and GX1000. -
Page 9: Precautions
Do not install in places where a leak can cause damage. • GrowoniX EX Series RO water filters are rated using supply water that is 77°F, 475ppm, at 70psi. • Slower performance may be noted in areas with colder temperatures, higher water salinity, or lower inlet water pressure. -
Page 10: Information On Quick Connect Fittings
INFORMATION ON QUICK CONNECT FITTINGS GROWONIX WATER FILTERS USE QUICK CONNECT FITTINGS THAT ALLOW FOR EASY MAINTENANCE. MAKE A CLEAN TUBE CUT Cut the tube squarely and if using plastic tubing, ensure that the cut has not made the tube out of round. -
Page 11: Component Diagram
14. AUTO-SHUTOFF VALVE 6. RO MEMBRANE HOUSING 15. RO WATER OUT 7. RO MEMBRANE 16. DRAIN SADDLE CLAMP 8. O-RING 17. IN-LINE SHUTOFF VALVE 9. END CAP 18. FILTER WRENCH 19. RO AND DRAIN TUBING www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com... -
Page 12: Setup Instructions
Always turn incoming water pressure on slowly, allowing all air to be discharged from • the system before full water pressure is restored. GrowoniX GX600 and GX1000 water filters are designed to be used with between 40- • 80 psi of incoming water pressure. Do not exceed 80 psi of incoming water pressure If incoming water pressure is too high, install pressure regulator before unit. -
Page 13: Flushing The Kdf85 Carbon Filter
FLUSHING THE KDF85 CARBON FILTER Growonix EX600 and EX1000 water filters can be upgraded with a KDF85 Catalytic Carbon Pre-Filter. The "KDF" carbon filter is a superior blend of highly reactive catalytic carbon and KDF85 process media used to remove/reduce iron, hydrogen sulfide, chlorine, chloramine, bacteria, scale, and algae. -
Page 14: Flushing The Membrane Element
FLUSHING THE MEMBRANE ELEMENT Growonix GX600 and GX1000 water filters come with a manual flush valve. Flushing the membrane element after each use for approximately 3-5 minutes will remove standing salts from the membrane, significantly extending membrane life. Even weekly flushes will improve membrane life and system performance. -
Page 15: Replacing Sediment And Carbon Pre-Filters
REPLACING SEDIMENT AND CARBON PRE-FILTERS GrowoniX EX600 and EX1000 pre-filters should be changed regularly to ensure maximum membrane element life and system performance. When a 30% — 40% differential between the gauges is reached and output water pressure gauges is reached, pre-filters should be changed (i.e., when input gauge reads 80 psi and output gauge reads approximately 50 psi, you have a 30% differential—time to change pre-filters). - Page 16 REPLACING SEDIMENT AND CARBON PRE-FILTERS flush position loosen Turn off incoming water supply. Loosen pre-filter housings using supplied Open flush valve to relieve filter wrench. Empty standing water and system pressure. remove old pre-filters. Clean interior of housings to remove standing sediment and debris.
-
Page 17: Replacing Membrane Element
Make sure to depress collet while pulling open flush valve to depressurize the stem outward. system. Remove stem elbow from input side of On the input side of the membrane membrane housing. housing, remove the end-cap retaining bolts. www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com... - Page 18 REPLACING MEMBRANE ELEMENT INPUT SIDE Remove end clamp. Remove the end-cap and slide membrane out. brine seal Pull used membrane element out towards Clean inside of membrane housing the input side of membrane housing. to remove buildup or debris. Brine Seal Brine Seal Prepare new membrane element by Insert membrane element into...
- Page 19 Turn incoming water supply ON slowly, allowing air to be discharged, before full water pressure is restored. Let system run in “Flush Mode” for 30 minutes to clear new membrane element. After 30 minutes, close flush valve and begin normal usage. Enjoy. www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com...
-
Page 20: Specifications Charts
ADDITIONAL SPECIFICATIONS CHARTS Pleated Sediment Filter 4.5 “ Diameter Materials of Construction: Filter Media • End Caps • Core • Temperature Rating • Non-woven Polyester • Vinyl Plastisol • Polypropylene • 40˚F to 125˚F (4.4˚C to 51.7˚C) • Size Description: 4.5”... - Page 21 Initial AP (PSI) @ Flow Rate (GPM): 0.90 PSI @ 4 GPM (.06 bar @ 15.1 L/m) • Chlorine, Taste, Odor Reduction Capacity Flow >70,000 gallons @ 4 GPM (265,000L @ 15.1 • LPM) Flow Rate - gpm (Lpm) www.growonix.com toll free 888.406.8521, office 818.510.0264, sales@growonix.com...
- Page 22 GROWONIX REVERSE OSMOSIS SYSTEM WARRANTY For a period of one year from the date of original purchase, we will replace or repair any part of the GrowoniX reverse osmosis water system that we find to be defective in operation du e to faulty materials or workmanship with the EXception of the replaceable filters and membranes.
