HOMCOM 370-242V70 Assembly Instruction Manual page 8

Attach the Steering Wheel
Faceguard support Faceguard support
Turn the vehicle body upright. Remove the M5x32 machine screw and nut from the
faceguard support.
1. Lift up the faceguard.
2. Lift the faceguard support until it is aligned with any of the four adjustment holes on
the faceguard.
TIP: The faceguard is adjustable and have four positions. Please choose the
suitable position as your child grows up.
3. Insert a M5X32 machine screw, and tighten a M5 nut on the opposite side.
1
2
The four adjustment holes
1 2 3 4
7
