CashConcepts CCE 380 User Manual

2-pocket counter for value mixed notes with sorting function

Advertisement

Quick Links

CashConcepts
CCE 380
2-Pocket Zähler für gemischte Wertigkeiten mit Sortierfunktion
2-pocket counter for value mixed notes with sorting function
Benutzerhandbuch
User Manual
CashConcepts Europe GmbH
Kemptener Straße 99 D – 88131 Lindau
Tel. +49 (0)8382 – 943150 - Fax. +49 (0)8382 - 9431520
Email sales@cashconcepts.cc – Web www.cashconcepts.cc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CCE 380 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CashConcepts CCE 380

  • Page 1 2-Pocket Zähler für gemischte Wertigkeiten mit Sortierfunktion 2-pocket counter for value mixed notes with sorting function Benutzerhandbuch User Manual CashConcepts Europe GmbH Kemptener Straße 99 D – 88131 Lindau Tel. +49 (0)8382 – 943150 - Fax. +49 (0)8382 - 9431520 Email sales@cashconcepts.cc – Web www.cashconcepts.cc...
  • Page 2: Electricity Supply

    The CCE 380 offers therefore in the office area for all supermarkets and retail dealers, and also in the foremost front of the counterfeit money protection, e.g., at banks, used car traders or all other companies where bigger cash amounts all at once change the owner.
  • Page 3 CashConcepts CCE 380 Representation of the machine Front view Banknote limitation / Feeder Hopper Display and panel (see below) Both sided buttons for opening the machine Reject pocket for seperated banknotes Stacker Rear view Adjustment wheel for banknote pressure Access flap to the back-sided sensor strip...
  • Page 4: Self-Diagnosis

     Connect the net plug with the outlet.  Connect now the net cable with the CCE 380 and switch on the machine.  Then the machine automatically begins the selfdiagnosis and checks all sensors. Please, wait for this process before you insert banknotes or try to setup the machine.
  • Page 5: Add Function

    Counterfeit dection By pressing the button „CF“ you can switch on and off the counterfeit detection of the CCE 380. When you turn off the detection you can count banknotes and all similar papers like vouchers and entrance cards. If you want to make a sensond count of already checked banknotes and only need the quantity of banknotes, this way may be the fastest.
  • Page 6 CCE 380 Setting of the counting mode The CCE 380 offers several different counting functions and can not only count the money but also sort according to denomination, direction and, depending on selected features, by the actual condition of the banknotes.
  • Page 7 CashConcepts CCE 380 Name of counting mode: VerN-SORT (OPTIONAL) Description: The banknotes are sorted by their actual condition. In this way old and heavily worn banknotes can be separated from new banknotes. This mode only for unsorted US-Dollar banknotes. Sorting: All suspect notes, banknotes of a different denomination compared with the first banknote or detected by the unit as being too old or too worn.
  • Page 8 CashConcepts CCE 380 Name of counting mode: FACE-DEN Alternatives: FACE, FACE-DEN, ORIENT, ORIENT-DEN Toggle between alternatives with the arrow button. Description: All banknotes lying on the same side (face or back) are counted on a value basis. The first banknote is deciding for all other banknotes for side sorting and denomination sorting.
  • Page 9 CashConcepts CCE 380 Name of counting mode: PRINT (OPTIONAL) Description: All banknotes of the set currency are counted in mixed mode, the serial numbers are read and printed on the optional printer. Printout starts automatically, as soon as the banknotes are removed from the stacker.
  • Page 10 CCE 380 Counting of other currencies CCE 380 is also available for other currencies and also for combinations, such as Euro and US Dollar. If you purchased a further currency with the unit, press CUR button to toggle between the currencies.
  • Page 11 Now you can clean the complete way the banknotes pass from dust and dirt, as well as jammed notes. Should you have questions to the right cleaning of the CCE 380, our service team is available to you of course with pleasure.
  • Page 12: Troubleshooting

    CashConcepts CCE 380 General Error Codes Error Display Message Cause Of Error Troubleshooting Code 1. Remove all banknotes from hopper, stacker and separator E001 Banknote got stuck inside the unit 2. Open front and rear of the unit and remove all banknotes 3.
  • Page 13 CashConcepts CCE 380 Value Error Codes Error Display Message Cause Of Error Troubleshooting Code Value Error ( E101 ) E101 Banknote skew retracted, sensor left Value Error ( E102 ) E102 Banknote skew retracted, sensor right Value Error ( E103 )
  • Page 14 CashConcepts CCE 380 MG Error Codes Error Display Message Cause Of Error Troubleshooting Code E-M1 (all currencies) E211 MG error Suspect note, start counting process E-M2 (all currencies) E212 MG information error 1 again E-M3 (all currencies) E213 MG information error 2 1.
  • Page 15 Contact If it should once have problems with your CCE 380 which you can solve with the help of this manual, then you please get in contact to us by email and describe the problem, we will get in contact to you as soon as possible with a proposal for solution for the problem.
