Alotcer AD2066L User Manual

Support 2g/3g/4g data transfer unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
m User Manual
AD2066L IP Modem User Manual
Support 2G/3G/4G Data Transfer Unit
Tel:+86 592-6195619 Fax:+86 592-6195629
Web:en.alotcer.com
Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
Xiamen Alotcer Communication Technology Co., Ltd.
Tel:+86 592-6195619
Fax:+86 592-6195629
Web:en.alotcer.com
E-mail:anne@alotcer.com
Add:NO.146-148, 2nd XingBei Road, JiMei District,
XiaMen,China.
E-mail:anne@alotcer.com
AD2066L IP Mode
Page 1 of 56

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AD2066L and is the answer not in the manual?

Questions and answers

Related Manuals for Alotcer AD2066L

Summary of Contents for Alotcer AD2066L

  • Page 1 AD2066L IP Mode m User Manual AD2066L IP Modem User Manual Support 2G/3G/4G Data Transfer Unit Xiamen Alotcer Communication Technology Co., Ltd. Tel:+86 592-6195619 Fax:+86 592-6195629 Web:en.alotcer.com E-mail:anne@alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen,China. Tel:+86 592-6195619 Fax:+86 592-6195629 E-mail:anne@alotcer.com Page 1 of 56 Web:en.alotcer.com...
  • Page 2 AD2066L IP Mode m User Manual Applicable Models: Product Type Model Product Name AD2066L-G GPRS IP MODEM AD2066L-C CDMA IP MODEM AD2066L-W WCDMA IP MODEM AD2066L-E EVDO IP MODEM AD2066L-F FDD-LTE IP MODEM AD2066L-D TDD/FDD-LTE IP MODEM Standard AD2066L-GP GPS+GPRS IP MODEM...

  • Page 3: Table Of Contents

    AD2066L IP Mode m User Manual Contents Contents Chapter 1 Brief Introduction of Product ..................4 1.1 General ..........................4 1.2 Product Feature .......................4 1.3 Block Diagram........................5 1.4 Product Spec........................6 1.5 Ordering Information .......................8 Chapter 2 Installation Introduction....................9 2.1 General ..........................9 2.2 Encasement List ......................9 2.3 Installation and Cable Connection ................9...

  • Page 4: Chapter 1 Brief Introduction Of Product

    Chapter 1 Brief Introduction of Product General AD2066L IP MODEM is a kind of cellular terminal device that developed based on 2G/3G/4G technology.It adopts high-powered industrial 32 bits CPU and embedded real time operating system. It supports RS232 and RS485 (or RS422) port that can conveniently and transparently connect one device to a cellular network, allowing you to connect to your existing serial devices with only basic configuration.

  • Page 5: Block Diagram

    AD2066L IP Mode m User Manual modes Housing: iron, providing IP30 protection Power range: DC 5~35V Support hardware and software WDT Support auto recovery mechanism, including online detect, auto redial when offline to make it always online High RS232/RS485/RS422 ports:15KV ESD protection...

  • Page 6: Product Spec

    AD2066L IP Mode m User Manual 1.4 Product Spec Items Contents Industrial 32 bits CPU Hardware FLASH System SDRAM 256KB(Extendable to 1MB) 2 RS232 port and 1 RS485(or RS422) port, 15KV ESD protection Data bits: 5, 6 ,7, 8 Serial Stop bits: 1, 1.5(optional), 2...
  • Page 7 AD2066L IP Mode m User Manual GSM/GPRS/EDGE: 850/900/1800/1900MHz CDMA: 800/1900MHz WCDMA/HSUPA/HSPA+: 850/900/1900/2100MHz Wireless CDMA2000 1x/ EVDO Rev. A: 800/1900MHz Network TD-SCDMA: 1880-1920/2010-2025MHz(A/F) TDD-LTE: Band 38/39/40/41& Band 61/62 FDD-LTE: Band 1/2/3/4/5/7/8/13/17/20/25/28 Network PPP Protocol Support PPP Protocol Maintaining links with the cellular network to prevent PPP Heartbeat forced sleep, to ensure the stability of dial-up link.

  • Page 8: Ordering Information

    -G: GPRS P: GPS -C: CDMA B: BeiDou -W: WCDMA AD2066L -E: EVDO -F: FDD-LTE -D: TDD/FDD-LTE Example AD2066L-GP: AD2066L GPRS IP MODEM Tel:+86 592-6195619 Fax:+86 592-6195629 E-mail:anne@alotcer.com Page 8 of 56 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 9: Chapter 2 Installation Introduction

    AD2066L IP Mode m User Manual Chapter 2 Installation Introduction 2.1 General The IP MODEM should be installed correctly to make it work properly. Warning: Forbid to install the IP MODEM when powered! 2.2 Encasement List Please take care of you when opening the packing material for future use.
  • Page 10 AD2066L IP Mode m User Manual Tel:+86 592-6195619 Fax:+86 592-6195629 E-mail:anne@alotcer.com Page 10 of 56 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 11 AD2066L IP Mode m User Manual Installation of antenna: Cellular antenna (Standard) GPS antenna (Optional) Screw the SMA male pin of the cellular antenna to the female SMA interface of the modem with sign “ANT”. Screw the SMA male pin of the GPS antenna to the female SMA interface of the modem with sign “GPS”.
  • Page 12 AD2066L IP Mode m User Manual Signal Default Extensible Function Number Name Function Power input anode Power Ground RS232 RX 1 RS232 TX 1 Power Ground RS485 anode RS422 R+/RS485 A RS485 cathode RS422 R-/RS485 B Power Ground GPIO,dry contact signal and 3.3V switch quantity signal detecting , 3.3V...
  • Page 13 AD2066L IP Mode m User Manual RS232 cable（standard） RS485 cable（optional） Ip Modem adopts industrial terminal block interface. Recommend cable is 28-16AWG. The detail description of standard layout adapter and communication cables as is following. Adapter（Rating Output 12VDC/0.5A）: Cable Color Power Output Polarity Black &White Alternate...

  • Page 14: Power

    AD2066L IP Mode m User Manual 2.4 Power Power adapter (Standard) The power range of the IP MODEM is DC 5 Warning: When we use other power, please ensure the stability of the power supply Tel:+86 592-6195619 Fax:+86 592-6195629 E-mail:anne@alotcer.com Page 14 of 56 Web:en.alotcer.com...

  • Page 15: Indicator Lights Introduction

    AD2066L IP Mode m User Manual (ripple less than 300mV, and the instantaneous voltage does not exceed 35V), and power supply is above 4W. We recommend user to use the standard DC 12V/0.5A power adaptor. Indicator Lights Introduction There are three indicator lights: “Power”, “RUN”, “Online”,”GPS”(Optional).

  • Page 16: Chapter 3 Configuration

    AD2066L IP Mode m User Manual Chapter 3 Configuration 3.1 Configuration Connection Before configuration, please connect the IP MODEM with the configure PC by the supplied RS232 or RS232-485 conversion cable as following. 3.2 Configuration Introduction There are two ways to configure the IP MODEM: Configuration software tool: All the settings are configured by the configure tool running on PC.
  • Page 17 AD2066L IP Mode m User Manual After the device is connected to the computer,Run the configuration tool to select the corresponding COM,Select 115200 baud calibration and check bit as N(Other Settings invalid),Click on the open button. A prompt message will be given in the output message bar: Wait for the device to be powered on and enter the config mode...
  • Page 18 AD2066L IP Mode m User Manual When the device is powered on, the current configuration parameters in the device are automatically loaded and displayed in the information output box on the left,At this point, you can configure the parameters. Extended AT command: In this configuration, the user only need to have a serial communication program can configure all the parameters of the digital terminal, such as WINDOWS HyperTerminal, LINUX minicom, putty, etc., or directly by the user's micro...

  • Page 19: Control Command

    AD2066L IP Mode m User Manual OUTOFF RANGE Configuration values are not within the prescribed range UNKNOWN Unknown instructions 3.2.1 Control Command Control Command：Used for users to perform some operations on devices. Control command query instruction：The AT+SHOWCOMMAND command allows the user to see which operating commands are currently in the device. The following are...
  • Page 20 AD2066L IP Mode m User Manual 3.2.1.2 Shows how many control commands are currently available: which control commands are available for display devices. AT+SHOWCOMMAND 3.2.1.3 Save configuration: This instruction is used to save the configuration when the configuration is set.
  • Page 21 AD2066L IP Mode m User Manual 3.2.1.7 Up and down the device: You can manually control the device to online and offline. AT+DIALOP=? Query the control command to operate. 0: OFF Manually offline 1: ON Manually online AT+DIALOP=1 Manually online...

  • Page 22: Configuration Command

    AD2066L IP Mode m User Manual 3.2.2 Configuration command View the current configuration: Users can view the current configuration information and configuration list of the specified configuration through instructions. The general AT command is: AT+XXX=? XXX Represents the configuration to be viewed. There are three types of content returned by the AT instruction.
  • Page 23 AD2066L IP Mode m User Manual configurable range, which is configurable in <>, and configurations beyond that range are invalid. Type three： at+NETADDR1=? server.alotcer.com <32> Note: The output result is the current configuration information and the length of its configurable ASCALL code. The length of the configurable ASCALL code in <> is 32 in this example.

  • Page 24: Status Command

    AD2066L IP Mode m User Manual AT+CTRLGAP=100 Type three： AT+XXX=abcdefg XXX Represents the configuration to be configured, and ABCDEFG represents the specific content to be configured, ASCALL For example, to configure the IP address of Center 1 to 192.168.1.1, the AT command is: AT+NETADDR1=192.168.1.1...
  • Page 25 AD2066L IP Mode m User Manual (D)IRQ rcv 0, max 0, drop 0 DATA IRQ (D)THD rcv 0, cur 0/0, drop 0, net 0 DATA Thread -----MOD Module information MO: Q20(Low) [IMEI:868704047246101] Module model, IMEI information SIM: READY [ICCID:89860317245925529596] SIM status SIM ICCID NO.
  • Page 26 AD2066L IP Mode m User Manual OSUsed OSFree Event -----PPP SIO read/call: 2/1 SIO write/call: 2/0 ---------- Tel:+86 592-6195619 Fax:+86 592-6195629 E-mail:anne@alotcer.com Page 26 of 56 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 27: Express Configuration

    AD2066L IP Mode m User Manual 3.3 Express Configuration Series rate：Set serial port baud rate as same as terminal device. Serial data bit：Set Serial data bit as same as terminal device. Serial check bit：Set Serial check bit as same as terminal device.

  • Page 28: Parameter Configuration

    AD2066L IP Mode m User Manual Time config：Update device RTC time. test condition：first, to know the IP address of the data center, search the "IP address query" directly on the Baidu, and then to determine the monitoring port of the...
  • Page 29 AD2066L IP Mode m User Manual communication. Multicenter mode: Data transmission terminal can support data communication with five centers at the same time. In this mode, data transmission terminal will try to establish connections with multiple data centers and carry out data communication when it is online.
  • Page 30 AD2066L IP Mode m User Manual 3.4.1.3 Remote Server Data transmission terminal mode of operation: Each center can be configured into a variety of protocol modes.: Central Agreement: NONE: has no protocol. TCP: TCP protocol is used for data communication.
  • Page 31 AD2066L IP Mode m User Manual 5001, the AT command is: AT+NETADDR3=166.111.8.238 AT+NETPORT3=5001 source port: You can configure a fixed source port number The AT command to configure the source port number is: AT+NETOURPORTn=xxx n is 1~5，corresponding to center 1-5.
  • Page 32 AD2066L IP Mode m User Manual AT+NETHEARTPKTn=xxx n is 1~5，corresponding to center 1-5. xxx:User-defined heartbeat package. The binary starts with a "-". For example, configure a central one-defined heartbeat packet to be abcdef: AT+NETHEARTPKT1=abcdef For example, to configure center one, the custom heartbeat package is 0xab, 0x12,...

  • Page 33: Basic Parameters

    AD2066L IP Mode m User Manual The device will use DNS1 to resolve the IP address corresponding to the central domain name. If DNS1 fails to resolve, DNS2 will be used to resolve the IP address corresponding to the central domain name.
  • Page 34 AD2066L IP Mode m User Manual User and password Dail center cmnet Empty *99***1# uninet Empty card #777 3gnet Empty *99# Empty card #777 APN Dial-up Center Number: Wireless Network Call Center Number. The corresponding AT command to configure APN dial-up center number is: AT+PPPNO=xxxx xxxx：Actual Call Center Number...
  • Page 35 AD2066L IP Mode m User Manual Authentication configuration: device CHAP authentication methods for PPP encryption. The AT command corresponding to the configuration authentication is: AT+PPPAUTH=xxx xxx: Authentication mode, or the serial number corresponding to authentication mode ANY Authentication mode is automatically selected by the protocol...
  • Page 36 AD2066L IP Mode m User Manual 115200 Baud rate 115200 128000 Baud rate 128000 256000 Baud rate 256000 For example, to configure a baud rate of 115200: AT+CTRLBAUD=11520 AT+CTRLBAUD=C Serial port one data bit: set the data bit of serial port one.
  • Page 37 AD2066L IP Mode m User Manual number corresponding to the actual flow control mode.。 0 XX Represents software flow control. 1 HW Represents hardware flow control 2 NONE Represents NONE flow control Serial port one message frame interval: sets the message frame interval of serial port 1 (per second).
  • Page 38 AD2066L IP Mode m User Manual 56000 Baud rate 56000 57600 Baud rate 57600 115200 Baud rate 115200 128000 Baud rate 128000 256000 Baud rate 256000 For example, to configure a baud rate of 115200: AT+DATABAUD=11520 AT+DATABAUD=C Serial port two data bit: set the data bit of serial port one.
  • Page 39 AD2066L IP Mode m User Manual AT+DATAFLOW=xxx XXX represents the actual flow control mode, or the serial number corresponding to the actual flow control mode.。 0 XX Represents software flow control. 1 HW Represents hardware flow control 2 NONE Represents NONE flow control Serial port two message frame interval: sets the message frame interval of serial port 1 (per second).
  • Page 40 AD2066L IP Mode m User Manual AT+LINKKEEPMODE =xxx xxx: The specific mode of retention, or the serial number corresponding to the mode of retention. 0 NONE No holding mode. ICMP the device sends an ICMP query message to the holding server, and if the device can receive the ICMP response message returned by the holding server, the device indicates that the network is normal, otherwise, the network is abnormal.
  • Page 41 AD2066L IP Mode m User Manual 3.4.2.4 PPP retention PPP layer heartbeat interval: maintains the operating interval (per second) of the connection function, which is used to maintain the connection measured by the network and to maintain the stability of the connection.

  • Page 42: Advanced Parameter

    AD2066L IP Mode m User Manual Maximum number of failures for Tcpkeepal:If the device does not receive the response message, the device will start counting the number of tcp keepalive failures, and if the response message has not been received within the maximum number of failures of the Tcp keepalive, the link connection is abnormal and the device will re- establish the connection with the center.
  • Page 43 AD2066L IP Mode m User Manual Polycentric reconnection times polycentric connection fails waiting for restart time: When all centers fail to connect, and the number of reconnections reaches the set polycentric maximum number of reconnections attempted, the device waits for that time to end before restarting.
  • Page 44 AD2066L IP Mode m User Manual cache Heartbeat timeout times: The AT command to configure the heartbeat timeout times is: AT+NETPROHEARTCNT =xxx xxx：Heartbeat timeout 3.4.3.2 serial port activate Data activation means sending specific data to the serial port of the data transmission terminal to establish or dismantle the data communication link.
  • Page 45 AD2066L IP Mode m User Manual For example, to configure the packet as abcdef: AT+ACTNETSMSDOWN=abcdef For example, to configure the packet as 0x12,0x34,0x56 AT+ACTNETSMSDOWN=-123456 3.4.3.3 Telephone activation Telephone activation mode, through the telephone call digital terminal, so that it establishes the data communication link.
  • Page 46 AD2066L IP Mode m User Manual Enable SMS activation SMS activation line: establish a communication link for the digital terminal by sending specific SMS messages to the digital terminal. The AT command configured is: AT+ACTNETSMSUP=xxx xxx：User-defined activation of SMS content. Binary starts with '-'.

  • Page 47: Sms

    AD2066L IP Mode m User Manual The AT command corresponding to the detection times of the configuration module is: AT+MOFAILCOUNT=xxx xxx: Module detection times, 0 means this function is not enabled Maximum number of module restarts: when the number of module restarts reaches the maximum number of module restarts, the device restarts.

  • Page 48: Io Configuration

    AD2066L IP Mode m User Manual 3.4.4.2 SMS backup When the digital terminal receives the serial port data, if the network connection fails at this time, the serial port data will be sent to the corresponding mobile phone number as SMS content (called SMS backup function).

  • Page 49: Locate The Configuration

    AD2066L IP Mode m User Manual model.When the IO port is set to output mode, you can specify the IO port output is high level or low level of output. Set the operation mode of the IO: Configuration IO mouth working mode of the AT command as follows:...
  • Page 50 AD2066L IP Mode m User Manual 3.4.6.2 Device ID Device ID: used to add an ID to the tail of the local GPS data The AT instruction to configure the location ID is: AT+GPSID=xxxx xxxx :The ID number at the end of the local GPS data 3.4.6.3 data interval...
  • Page 51 AD2066L IP Mode m User Manual AT+GPSPRO x:Represents the actual protocol to be selected Server address: the IP address or domain name of the server. The AT command to configure the server address is: AT+GPSADDR=xxx xxx Is the domain name or IP address of the server Server port number: server port number, recommended to be set above 1024.
  • Page 52 AD2066L IP Mode m User Manual FGSV Data not sent FGSV Data sent AT+GPSFGLL=x FGLL Data not sent FGLL Data sent 3.4.6.7 NTRIP Server configuration Server address: the IP address or domain name of the server. The AT command to configure the NTRIP server address is:...

  • Page 53: Other Configuration

    AD2066L IP Mode m User Manual UART GGA Data from serial port GGA Data from longitude and latitude GGA Data from GPS net LOCAL GGA Data from local Longitude configuration: manually enter the current longitude of the device. Longitude: east longitude is positive and west longitude is negative, ranging from -180 °...
  • Page 54 AD2066L IP Mode m User Manual 3.4.7.2 Debug level Debugging information level: the debugging information level is used for software debugging of the device or for simple information prompts.DTU equipment has 6 different debugging levels, corresponding to different debugging information.

  • Page 55: Working State Switch

    AD2066L IP Mode m User Manual and service center number) data transfer function. AT command of data transmission port is: AT+SERIFXDATA=x x：The actual interface to be configured, or the configuration interface sequence number. CTRL Enable only the control port for data transmission...

  • Page 56: Chapter 4 Boot Operation Command

    AD2066L IP Mode m User Manual Chapter 4 BOOT Operation Command 4.1 Operation Command The device will output "Input ALT" when 32 C (capitals) are input immediately after the device is powered on, and then input ALT device will enter command mode.Then, you can enter different operation commands according to different requirements.
