Alotcer AD2000-G User Manual

Support 2g/3g/4g data transfer unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AD2000 IP Modem User Manual
Support 2G/3G/4G Data Transfer Unit
Tel:+86 592-6195619 Fax:+86 592-6195620
Web:en.alotcer.com
Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
AD2000 IP Modem Specification
Xiamen Alotcer Communication Technology Co., Ltd.
Tel:+86 592-6195619
Fax:+86 592-6195620
Web:en.alotcer.com
E-mail:anne@alotcer.com
Add:NO.146-148, 2nd XingBei Road, JiMei District,
XiaMen,China.
E-mail:anne@alotcer.com
Page 1 of 43

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AD2000-G and is the answer not in the manual?

Questions and answers

Related Manuals for Alotcer AD2000-G

Summary of Contents for Alotcer AD2000-G

  • Page 1 AD2000 IP Modem Specification AD2000 IP Modem User Manual Support 2G/3G/4G Data Transfer Unit Xiamen Alotcer Communication Technology Co., Ltd. Tel:+86 592-6195619 Fax:+86 592-6195620 Web:en.alotcer.com E-mail:anne@alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen,China. Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 1 of 43 Web:en.alotcer.com...
  • Page 2 AD2000 IP Modem Specification Applicable Models： Product Type Model Product Name AD2000-G GPRS IP MODEM AD2000-C CDMA IP MODEM AD2000-W WCDMA IP MODEM AD2000-E EVDO IP MODEM AD2000-D TDD/FDD-LTE IP MODEM Standard AD2000-GP GPS+GPRS IP MODEM AD2000-CP GPS+CDMA IP MODEM...

  • Page 3: Table Of Contents

    3.6 Configuration........................21 3.6.1 Server Settings..................... 21 3.6.2 IP MODEM Settings.....................25 3.6.3 Serial........................31 3.6.4 Keep Alive......................33 3.6.5 Advanced....................... 33 3.6.6 SMS........................39 Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 3 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 4: Chapter 1 Brief Introduction Of Product

    It has been widely used on M2M fields, such as intelligent transportation, smart grid, industrial automation, telemetry, finance, POS, water supply, environment protection, post, weather, and so on. Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 4 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 5: Product Feature

    Low power consumption design, support multi-sleep and trigger Design modes Housing: iron, providing IP30 protection Power range: DC 5~35V High Support hardware and software WDT Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 5 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 6 Support link disconnection when timeout Security Support dynamic domain name(DDNS) and IP access to data center Design with standard TCP/IP protocol stack Support APN/VPDN Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 6 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 7: Block Diagram

    1 RS232 port and 1 RS485(or RS422) port, 15KV ESD protection Interface Serial Data bits: 5, 6 ,7, 8 Stop bits: 1, 1.5(optional), 2 Parity: none, even, odd, space, mark Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 7 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 8 Network Support CHAP/PAP Authentication Authentication TCP Heartbeat Monitor the server connection 50-channle Receiver Type GPS L1（1575.42MHz）C/A code (optional) SBAS: WAAS,EGNOS,MSAS,GAGAN Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 8 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 9 Power Power range DC 5~35V Power Communication <100mA (@12VDC) supply Current Standby <20mA（@12VDC） Current <10mA（@12VDC） Sleep current Dimensions 91x59x23mm Physical Weight 175g Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 9 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 10: Ordering Information

    2.1 General The IP MODEM should be installed correctly to make it work properly. Warning: Forbid to install the IP MODEM when powered! Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 10 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 11: Encasement List

    Manual CD Optional Certification card Maintenance card GPS Antenna Optional 2.3 Installation and Cable Connection Dimension (The fixing piece is detachable): (Unit:mm) Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 11 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 12 Cellular antenna (Standard) GPS antenna (Optional) Screw the SMA male pin of the cellular antenna to the female SMA interface of the modem Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 12 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 13 DB9 Interface Signal Definition Pin Number Signal Name Default Function Extensible Function RS232 DCD/UART RX RS232 RX RS232 TX RS232 DTR/UART TX RS232 GND Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 13 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 14 RS485 cathode RS232 RI/RS422 T+ Installation of cable: RS232 cable（standard） Ip Modem adopts industrial DB9 Female interface. The cables as is following. Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 14 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 15: Power

    Data is communicating No data Online IP MODEM has logged on network IP MODEM hasn’t logged on network Effective GPS No Effective GPS Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 15 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 16: Chapter 3 Configuration

    There are two ways to configure the IP MODEM: Configuration software tool: All the settings are configured by the configure tool running on PC. Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 16 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 17: Run The Configure Tool: Ar_Ipmodemconfigtool.exe

    Prompt message: Please open the serial port first with the correct parameters, then switch the device on. Start worker... Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 17 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 18: Re-Power Ip Modem

    After Re-power IP MODEM, configure tool will enter configure state. At the same time, the software will load current settings. It’s ready to configure. Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 18 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 19 AD2000 IP Modem Specification Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 19 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 20: Guide

    Backup center:When the main server network is blocked, the device will connect to the backup center. Recommend to leave the backup IP and Port for blank. Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 20 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 21: Configuration

    If the Server Number is 1, IP MODEM work in Main and Backup method. When “Server Number” is greater than 1, IP MODEM works in Multi Data Service Center Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 21 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 22 AT command for Main IP: AT+IPAD=xxx xxx is the IP or domain. AT command for Main Port: AT+PORT=xxx xxx is the Port Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 22 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 23 “Data Center Number” as 3, Main Center, 2nd Center, 3rd Center work as these three servers. AT Command of server 2~5IP or domain: Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 23 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 24 AT Command of server 2~5 port: AT+PORTn=xxx n is 1~4 for server 2 to 5 xxx is port value Example: Set IP address of center 3 as www.alotcer.com, and port 5001, the AT command is as following: AT+IPAD2=www.alotcer.com AT+PORT2=5001 Main and Backup DNS When the Internet access uses domain name, It’s necessary to set DNS server resolving...

  • Page 25: Ip Modem Settings

    APRO: Heartbeat packet with TCP protocol, Data transmission with TCP protocol, heartbeat packet and application data transmission are in the same TCP connection. Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 25 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 26 ZPTCP: TCP protocol for data package, there is a specific format to read and send. AT command: AT+MODE=xxxx xxxx: one of the above workmode Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 26 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 27 When one of the configured data center lost connection, IP MODEM will try to reconnect after the configured reconnection interval. AT Command: AT+MCONTIME=xxx xxx : reconnect time interval (unit is second) Device ID Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 27 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 28 Custom Register String This item is only valid when the WorkMode is TCP-CUSTOM. It’s the defined register Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 28 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 29 If the working mode is TCP recommended to set 60 seconds, and if the UDP is recommended set 31 seconds. AT Command: AT+POLLTIME=xxx xxx: Heartbeat packet time interval Reconnection Time, Reconnection Interval Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 29 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 30 Debug information is used to debug software when there is software problem. 0 --- no debug information output 1 --- simple prompt information output 2 --- detail debug information output Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 30 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 31: Serial

    --- 19200 bps 38400 --- 38400 bps 56000 --- 56000 bps 57600 --- 57600 bps 115200 --- 115200 bps 230400 --- 230400 bps Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 31 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 32 IP MODEM will send the serial data to the center when two bytes transmit time interval larger than this item value. AT Command: AT+BYTEINT=xxx xxx: bytes interval time value（millisecond） Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 32 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 33: Keep Alive

    For maintain connections between network measurements and maintain stability of connections AT Command: AT+ECHOENABLE=xxx xxx: 1 is Enable，0 is disable LCP ECHO Interval AT Command: AT+ECHOINT=xxx xxx: interval 3.6.5 Advanced Network Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 33 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 34 AT+PASSWORD=xxx xxx: password AT Command of Dail Center: AT+CENT=xxx xxx: Dail center number of ISP SMS Center Your local SMS center number Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 34 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 35 IP MODEM can be Activated online ready for data transmission. There are total five methods to make IP MODEM online: AUTO: IP MODEM always keeps online Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 35 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 36 IP MODEM will keeps in idle state until it receives the Activation SMS. Then it will connect to the center. AT Command: Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 36 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 37 When device is activated online, whether to auto get online when network recover. AT Command of data trigger off password: AT+ISTRIGMODE=xxx xxx : value. 0 is Disable/1 is Enable Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 37 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 38 AT+STRAIGHT=x x:0 or 1 Length of TCP The maximum transmission unit of TCP packet AT Command: AT+TCPMTU=xxx xxx : the MTU value Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 38 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.

  • Page 39: Sms

    0x00-0xff, this method is especially suitable for the use of SMS to transmit data to monitor industrial control, industrial control equipment. AT command: Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 39 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 40 Command: Corresponding AT command removes the AT+, and the remaining command is the command for the SMS configuration parameter. Multiple commands are separated by semicolons. For example: <123456;IPAD=120.42.46.98;PORT=5007> Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 40 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 41 Interval: To configure the GPS transport interval. AT command: AT+GPSINT=x x is interval to transport gps data. Server IP: To configure the GPS Transport server IP. AT command: Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 41 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 42 Reboot: To reboot the IP Modem when config mode, and it will switch to Commun mode. Manual: To Config mode when commun mode. Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 42 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
  • Page 43 “Config”, last Click “Manual”. The modem is still in communication mode and the config mode could be keep 1 minute if no configuration is done. Tel:+86 592-6195619 Fax:+86 592-6195620 E-mail:anne@alotcer.com Page 43 of 43 Web:en.alotcer.com Add:NO.146-148, 2nd XingBei Road, JiMei District, XiaMen, China.
