CHEKVOLT
(R-3MT-VI)
®
INSTALLATION GUIDE & OPERATING INSTRUCTIONS
Non-Hazardous Locations
Indoor
Indoor/Outdoor
Ingress Protection
UL Type 12, 13
UL Type 4, 4X
IP66, IP69 per IEC 60529
Approvals
CSA C22.2 No. 94.2/ UL 50E
UL 61010-1 3rd Ed. with AMD 1
CAT III 1000V
CAT IV 600V
CE
UL/CSA 61010-2-030 2nd Ed.
EN 61010-2-030 2nd Ed.
For technical questions call 1-800-280-9517 and select Option 3 for Technical Support when prompted
Grace Technologies, Inc. • 1515 E Kimberly Road • Davenport, Iowa 52807
Phone: 1-800-280-9517 • Fax: (563)386-9639 • www.pesd.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the PESDs CHEKVOLT R-3MT-VI and is the answer not in the manual?

Questions and answers

Summary of Contents for Grace PESDs CHEKVOLT R-3MT-VI

  • Page 1 UL/CSA 61010-2-030 2nd Ed. EN 61010-2-030 2nd Ed. For technical questions call 1-800-280-9517 and select Option 3 for Technical Support when prompted Grace Technologies, Inc. • 1515 E Kimberly Road • Davenport, Iowa 52807 Phone: 1-800-280-9517 • Fax: (563)386-9639 • www.pesd.com...
  • Page 2: Specifications

    TYPICAL CONFIGURATION ChekVolt is a combination device used to verify the voltage presence using visual ® indication and absence through a metered test. THREE PHASE DELTA, 3W + GND ® SPECIFICATIONS AC Operational Test Point: AC Single or 3-Phase : 0 - 1000V @ 50/60/400Hz Voltage Range Voltage Indicator: AC Single...
  • Page 3 ® BE SURE POWER IS SHUT OFF PRIOR TO INSTALLING THIS DEVICE. CAUTION CAUTION • ALWAYS connect the GRN/YEL (GND) conductor to earth ground. • Location of device and internal hardware/wiring MUST allow free operation of ON/OFF disconnect mean. For indoor use only. •...
  • Page 4 INSTALLATION INSTRUCTIONS ® 1. Follow all Local, State, and National Electrical Codes when 5. Using the proper test equipment: the voltmeter should be rated installing this equipment. Overcurrent protection of the supply for Cat III/1000V and Cat IV/1000V. Test probes should be fully leads may be necessary if the device leads are either extended insulated with .080”...
  • Page 5 ® Indicator Flash Rates (L1, L2, L3, GND) Line-to-Line (VAC) <15 1000 Flashes/Sec (typical) Line-to-Line (VAC) <18 1000 Flashes/Sec (Typical) or Stored Energy (DC) <16 1000 Flashes/Sec (Typical)
  • Page 6: Maintenance

    OPERATION INSTRUCTIONS ® Equipment needed: Digital voltmeter with 1000V AC or 1000V BEFORE OPENING A PANEL, TURN POWER DC rated input minimum, 10M Ω input impedance and CAT III & OFF! SAFETY PROCEDURES STILL APPLY! IV. A pair of insulated test probes with .080” DIA. points. Before working on an electrical conductor, verify zero electrical energy with proper voltage testing instrument and the proper procedure as per Directions: Before and after each test, determine the voltmeter...
  • Page 7 MEASUREMENT CATEGORY ® The categories take into account the total continuous energy available at the given point of circuit, and the occurrence of impulse voltages. The energy can be limited by circuit breakers or fuses, and the impulse voltages by the nominal level of voltage. Maximum rated voltage of this device is 1000V AC or DC.
  • Page 8 ® Included in R-3MT-VI-KIT: ChekVolt with Cap Horizontal Label* Flange Label* ® (R-3MT-VI-LF) (R-3MT-VI & R-3MT-CAP) (R-3MT-VI-LH) *Both the Horizonal and Flange labels are included in your kit. Use the appropraite label per your installation requirements. Custom labels are available upon request. Please call 1-800-280-9517 or visit www.pesd.com...
  • Page 9: Typical Configuration

    per NFPA 70E 120.1(5), 120.2 (F)(2)(f)(1-6), OSHA 1910.333(b)(2)(iv)(B)." AVANT D'OUVRIR UN PANNEAU ÉLECTRIQUE, COUPER L'ALIMENTATION! LES PROCÉDURES DE SÉCURITÉ S'APPLIQUENT TOUJOURS! Avant d'effectuer des travaux sur un conducteur électrique, vérifier que le courant est coupé à l'aide d'un instrument de mesure de tension approprié...
  • Page 10 Figure 3 ® ®...
  • Page 11 Figure 4 ® Figure 5 ® Fig. 3 Fig. 4...
  • Page 12 SS-R3MTVI-IG-EN 2211...
