Grace SafeSide P-S10S21-M2RX Series Installation Manual

INSTALLATION
The Voltage Test Station is to be mounted onto the flat surface
of the enclosure with the same environmental rating. Installation
should be performed by a qualified technician and adhere to
applicable safety and regulatory codes.
MOUNTING DIMENSIONS
WEIGHT
UL TYPE
(OZ)
M2, M3, M4 13.2
OVERALL DIMENSIONS
UL TYPE F
6.50
M2, M3, M4
(165.0)
B
D
A
E
C
I
VTS OPERATION SAMPLE PROCEDURE
1) Verify the test instrument is calibrated and properly rated for
application.
2) Verify the test instrument to a known voltage source.
3) Verify there is voltage illumination on the voltage indicator.
4) Open the housing and insert the test instrument probes into the
test point and measure the voltage between phase to phase
and phase to ground to verify voltage presence.
5) Open Isolator.
6) Verify there is no LED illumination on the voltage indicator.
7) Re-insert the Test Instrument probes into the test point and
measure the voltage between phase to phase and phase to
ground to verify voltage absence.
Warning: Verify an electrical conductor has been de-energized using an adequately rated test instrument before working on it. Follow appropriate Energy Control (Lockout/Tagout) procedures as per
OSHA Subpart S.© Grace Engineered Products, Inc. All rights reserved. Specifications are subject to change with/without notice.
1515 East Kimberly Road • Davenport, IA • www.graceport.com • 1.800.280.9517
VOLTAGE TEST STATION
INCHES (MM)
A B
4.80 ± .010 3.15 ± .010 5.83 ± .004
(122.0 ± .2) (80.0 ± .2) (148.0 ± .1)
INCHES (MM)
G H
3.78 5.02
(96.0) (127.6) (40.7)
M
N
G
J
All installations:
1) Cut panel opening and mount Voltage Test Station assembly to
enclosure with gasket.
2) Connect low voltage interface wiring according to
documentation provided with R-3MT and R-3W Series
Installation Sheets.
C D
2.76 ± .004
.26 + .010
(70.0 ± .1)
(6.5 + .2)
I J K
1.60 0.43 8.52
(11.0) (216.4)
F
H
8) Re-verify test Instrument to a known voltage source.
9) Upon completion of work, close the housing on the test point,
close isolator, and verify proper operation of voltage indicator.
Note: The voltage accuracy of the test point is - 2% and test instrument will read
102 kΩ
L1
TEST POINT ASSEMBLY
small mV due to the high impedance circuit in the test point. 102 kΩ
WITH 102kΩ IMPEDANCE
L2
102 kΩ ON L1, L2, & L3
L3
AFFECTS VOLTAGE
READINGS ± 2%
MECHANICAL SPECIFICATIONS
Housing: Cast aluminum base
Latch: Type 304 Stainless Steel (1CR18NI19)
Cover: Polycarbonate, uV rated, V-O Flame rated
Insert Material: Acrylic UL94HB
INSTALLATION GUIDE
EØ
E207344
L MØ
.57 .45 0.20
(14.4) (11.5)
K
VOLTAGE TEST STATION
VOLTAGE
IF ILLUMINATED
L
NOTE:
NØ
.26 ± .004
(6.5 ± .1)
5.20
P-S10S21-M3RX
VOLTAGE
TEST POINTS
WARNING
ALWAYS
FOLLOW SAFETY
PROCEDURES
WHEN USING
THIS DEVICE
102 kΩ NOTE:
L1
TEST POINT ASSEMBLY
102 kΩ
L2 WITH 102kΩ IMPEDANCE
102 kΩ
ON L1, L2, & L3
L3
AFFECTS VOLTAGE
READINGS ± 2%
VTS-IG-EN 1607
