- Page 1 INDUSTRIAL FILTRATION SYSTEMS MODEL # GRS-0250-B-CC OPERATION AND MAINTENANCE MANUAL...
- Page 2 System Pump. Centrifugal Separator. General Assembly. Layout drawing. Sweeper Package. Electrical Schematic. Page 3 This document is proprietary. No disclosure, reproduction or use of any part thereof may be made without the expressed written permission of Ebbco Inc. or its subsidiaries.
- Page 3 The Garnet Removal System is tested in Ebbco's test department to ensure that it meets the specifications required by the customer. The Garnet Removal System is inspected and all test data documented prior to shipment.
- Page 4 2" Inlet size: 1/4" NPT Case material: Stainless/steel Wetted parts: Brass Page 5 This document is proprietary. No disclosure, reproduction or use of any part thereof may be made without the expressed written permission of Ebbco Inc. or its subsidiaries.
- Page 5 All carbon steel construction. 1 cubic yard capacity. 3" coupler on decant outlet. Page 6 This document is proprietary. No disclosure, reproduction or use of any part thereof may be made without the expressed written permission of Ebbco Inc. or its subsidiaries.
- Page 6 7. Close the suction and discharge valves. 8. Fill the catcher tank with water. 9. Position system next to waterjet machine as discussed with Ebbco Inc. Anchor system to floor as necessary. 10. Using the black suction hose and clamps provided in the installation kit, connect the suction barb on the catcher tank to the suction barb on the garnet removal system.
- Page 7 If pressure differential is too low or is too high, Warning call the Ebbco service department 1-800-991-4225 Page 8 This document is proprietary. No disclosure, reproduction or use of any part thereof may be made without the expressed written permission of Ebbco Inc. or its subsidiaries.
- Page 8 Monthly checking of garnet build up on the tank bottom is advised, using a stick tap on the tank bottom in various locations. Any garnet accumulation will show up on the stick and it can be easily removed. If there are any questions regarding this system please call the Ebbco Service Department at 1-800-991-4225 Page 9 This document is proprietary.
- Page 9 Remember that over greasing will cause the bearing to run hot, so grease bearings sparingly when it is necessary. Ebbco recommends the use of sri # 2 chevron ball bearing grease.
- Page 10 Check for any material that may be wedged between the eductor nozzle and the horn. Ebbco Inc can provide an experience service technician to service the tank sweeper package and inspect the complete system. Please call Ebbco for pricing and to schedule a service technician.
- Page 11 6. No transfer of solids/correct separator pressure/correct separator flow Check for blockage in purge area. Page 12 This document is proprietary. No disclosure, reproduction or use of any part thereof may be made without the expressed written permission of Ebbco Inc. or its subsidiaries.
- Page 12 Specific gravity of liquid different than Rust in bearings due to water getting into design motor Page 13 This document is proprietary. No disclosure, reproduction or use of any part thereof may be made without the expressed written permission of Ebbco Inc. or its subsidiaries.
- Page 13 3/8" poly eductor End of clean discharge 2-5 days in system tank. Page 14 This document is proprietary. No disclosure, reproduction or use of any part thereof may be made without the expressed written permission of Ebbco Inc. or its subsidiaries.
- Page 14 It is Ebbco's policy to ship and charge for replacement parts upon notification of a problem. Warranty will be determined upon inspection of said part after it is returned to Ebbco, freight pre-paid. A returned goods claim form will be sent with replacement part and must be returned with defective part.
- Page 15 MODEL PKG98 PRODUCT FEATURES THE HEAVY DUTY SUCTION STRAINER BASKET IS USED AS THE FRONT LINE PUMP PROTECTION. EBBCO INC SUCTION STRAINER BASKET HAS A RUGGED ONE PIECE CAST IRON BODY WITH A CAST IRON LID. BASKET MATERIAL AS STANDARD ON THE PKG-51 IS ABS AND STAINLESS STEEL GR303 ON THE PKG-98.
- Page 16 Specifications HEAVY DUTY SUCTION STRAINER BASKET MODEL # PKG98 & PKG51 PKG-51 PKG-98 RECOMMENDED 150 GPM MAX FLOW RATE 300 GPM MAX TEMP 180°F 180°F MAX PRESSURE LOSS INLET 2" NPT 3" NPT OUTLET SQ. FLANGE SQ. FLANGE MATERIALS OF CONSTRUCTION BODY CAST IRON...
- Page 33 SEVERE DUTY CENTRIFUGAL SEPARATOR MODEL # SDS SERIES SEPARATOR PRODUCT FEATURES THE EBBCO SDS CENTRIFUGAL SEPARATORS ARE DESIGNED TO REMOVE SOLIDS FROM LIQUIDS. EACH MODEL IS SIZED BASED UPON THE FLOW RATE. UPON TANGENTIAL ENTRY, THE LIQUID AND SOLIDS ARE DRAWN THROUGH INTERNAL SLOTS AND ACCELERATE INTO THE SEPARATION CHAMBER.
- Page 34 Specifications SEVERE DUTY CENTRIFUGAL SEPARATOR MODEL # SDS SERIES SEPARATOR MAX PRESSURE 150 psi PRESSURE LOSS RANGE 5-12 psi FLOW RANGE 45-1200 gpm MAX PARTICLE SIZE 3/8" MATL OF CON. CARBON STEEL (STAINLESS STEEL OPTIONAL) *CONSULT FACTORY FOR HIGHER FLOW RATES AND OPERATING PRESSURES CAUTION: FOR USE WITH A CENTRIFUGAL PUMP ONLY! DO NOT USE WITH A POSITIVE DISPLACEMENT PUMP.
- Page 35 BACTERIAL & ALGAE BT PREVENTING SOLIDS BUILD UP ABLE TO OPERATE AT LOW PRESSURES AND IN LOW SUBMERGANCE. EBBCO EDUCTORS MULTIPLY THE FLOW RATE BY A FACTOR OF FOUR 24” OR FIVE ENABLING THE USE OF A SMALLER PUMP TO REDUCE ENERGY COSTS.
- Page 36 Product Profile Abrasive Bag Hopper MODEL # GRS-ABH Description: The Ebbco one cu.yd. Abrasive Bag Hopper is designed to capture up to 4000 lb. of garnet. Spent garnet that is discharge from the centrifugal separator is collected into the Abrasive Bag Hopper.
- Page 41 *Note: Item numbers 4, 7, 9, and 10 must be followed and maintained or warranty is null and void. Failure to follow above instructions can lead to catastrophic failure of the Ebbco Garnet Removal System as well as poor performance. The Garnet Removal System has been installed and is operating correctly according to the service manual.
