CMC-TC Master
DK 7320.000
Installation and Operating Instructions
- Last update: 10 January 2006 -
All rights related to this technical documentation are reserved for us. Without our previous consent it must neither be reproduced nor made
available for third parties. Nor must it be put to any other misuse by the receiver or third parties. Any violation of the above obliges the
violating party to pay compensation and may lead to penal action.
FRIEDHELM L O H GROUP
R i t t a l GmbH & Co. KG
Auf dem Stützelberg
D – 3 5 7 4 5 H e r b o r n
Germany
Email: Info@rittal.de
http://www.cmc-tc.com
Service Tel. : (+49) - (0)2772 / 505 - 0
Service Fax : (+49) - (0)2772 / 505 - 2319
TCP/IP, SNMP
Index [xx]
A29669 11 IT 74
Advertisement
Table of Contents
Related Manuals for Rittal CMC-TC Master
Summary of Contents for Rittal CMC-TC Master
- Page 1 Service Tel. : (+49) - (0)2772 / 505 - 0 Service Fax : (+49) - (0)2772 / 505 - 2319 TCP/IP, SNMP CMC-TC Master DK 7320.000 Installation and Operating Instructions - Last update: 10 January 2006 - All rights related to this technical documentation are reserved for us. Without our previous consent it must neither be reproduced nor made available for third parties.
-
Page 2: Table Of Contents
8. Maintenance ......................12 9. Cleaning ......................... 12 Disposal ......................12 A 1 Scope of supply/ Accessories – CMC-TC Master ...... 13 B 1 Technical data – CMC-TC Master ............14 Functional diagram - Central application in the network ....15 Functional diagram –... - Page 3 Logging in to the CMC-TC Master .................30 Structure of the HTML pages ...................31 Tab – Trap ..........................32 Trap list of CMC-TC Master ......................... 32 Setting severity of a trap message ..................... 33 Tab – Overview ........................34 Tab – Status ........................35 Tab –...
-
Page 4: Introduction
The data collected and prepared can then be called over the 10/100 BaseT connection or directly over a KVM console (Keyboard-Video- Mouse console). The RITTAL SSC console is suited to this purpose. In addition, the Master can be connected to a KVM switch. -
Page 5: Safety Instructions
Original accessories and accessories authorized by the manufacturer ensure safety. The use of other parts may make void the liability for consequences resulting from this. Repair work at the unit may be done only by RITTAL or by authorized personnel. -
Page 6: Service And Service Address
2. Service and Service Address If you have any questions concerning technical or other issues related to our product range RITTAL will of course support you. You may contact us by e-mail or via the address or phone and fax numbers indicated below. -
Page 7: Cmc-Tc Master
The SNMP functionality is also platform- independent and must support the SNMP V1.0 network management protocol. In addition, the CMC-TC Master supports the Standard-MIB II. The private MIB is part of the scope of supply; see CD Rom (CMC-TC-Master.MIB). -
Page 8: Design
3.2 Design The Master is delivered in a 482.6 mm (19”) aluminum enclosure. The Master is based on an embedded Linux PC with integrated 10-fold hub. For future further development of the Master, several interfaces such as PCMCIA, serial, infrared and sound interfaces are preconfigured. -
Page 9: Functions
3.3 Functions The functions of the RITTAL CMC-TC Master are focused on the management of up to 10 Processing Units and of the components connected to these, such as sensors, access controls, and climate control components. These functions are administered and controlled by means of the protocols listed below: •... -
Page 10: Assembly
4. Assembly The Rittal CMC-TC Master is mounted in the 482.6 mm (19”) level of a 482.6 mm (19”) rack. Attention must be paid to maintaining the allowed ambient temperature and humidity ranges, as well as the IP protection category as required for the specific application. The appropriate information is given in Appendix B Technical data. -
Page 11: Start-Up
• Prior to working on the RITTAL CMC-TC this must be made voltage-free and secured against reclosing. Furthermore, the absence of electrical power must be checked. • Cable clamping and protection is made by means of commercial cable ties at the casing or enclosure used. -
Page 12: Fault Messages
9. Cleaning In case of dirtiness, the CMC-TC Master can be wiped clean using a slightly moist cloth. The use of aggressive substances or acids for cleaning will cause damage or destruction of the unit and is absolutely prohibited. -
Page 13: A 1 Scope Of Supply/ Accessories - Cmc-Tc Master
Processing Unit (DK 7320.100) Note: The RITTAL CMC-TC Master can be operated using terminal programs, as e.g. Hyperterminal and TELNET by SW Tera Term (see Appendix G 2 Display and operation by terminal program), and also TFTP (is part of commercial operating systems) or a commercial browser. -
Page 14: B 1 Technical Data - Cmc-Tc Master
B 1 Technical data – CMC-TC Master DK 7320.000 Technical specifications Enclosure Aluminium Height 1 U, approx. 4.45 cm Width 482.6 mm (19“), 447 mm Depth approx. 200 mm Weight approx. 0.35 kg without packaging Potential equalization by enclosure earthing connection at the rear... -
Page 15: C 1 Functional Diagram - Central Application In The Network
C 1 Functional diagram – DK 7320.000 Central application in the network Central Network Management System (NMS) TCP / IP, SNMP, TFTP, Telnet über Tera Term, SSH, HTTP... -
Page 16: C 2 Functional Diagram - Local Operation Via Console
C 2 Functional diagram – Local operation via console DK 7320.000 Via the console connection it is possible to use a keyboard, mouse and monitor directly at the RITTAL CMC-TC Master. Optionally it is possible to install a keyboard-monitor-mouse switch in between. (Keyboard: PS/2,... -
Page 17: C 3 Functional Diagram - Operation By Network And Console
Operation by network and console Via the console connection it is possible to use a keyboard, mouse and monitor directly at the RITTAL CMC-TC Master. Optionally it is possible to install a keyboard-monitor-mouse switch (SSC series) in between. (Keyboard: PS/2, Mouse: PS/2 and Monitor:... -
Page 18: D 1 Installation Instructions - Master
D 1 Installation instructions – Master DK 7320.000... -
Page 19: E 1 Electrical Connection: Cmc-Tc Master
E 1 Electrical connection: CMC-TC master DK 7320.000 Note: Prior to making the electrical connection of the RITTAL CMC-TC Master it is indispensable to observe the notes in Chapter 4.2 Electrical components. 1. Connection Network connection The network connection is made by means of network cable... - Page 20 6. WebCam connection using USB cable The connection cable of the RITTAL WebCam is plugged in directly in a vacant USB port of the RITTAL CMC- TC Master. Up to 2 Rittal WebCams are supported. Maximum admissible cable length: 5 m.
-
Page 21: E 2 Configuration Via Serial Interface Rs 232
E 2 Configuration via serial interface RS 232 DK 7320.000 The serial data transmission to the RITTAL CMC-TC Master is made via the RS 232 interface, which is provided as RJ 11 front socket. The programming cable (see Appendix A1 Scope of supply/Accessories) connects the front socket RJ 11 and a vacant available Com-Port of the Notebook or PC. -
Page 22: E 3 Setting Up Of The Cmc-Tc Processing Units For Operation With The Master
E 3 Setting up of the CMC-TC Processing Units DK 7320.000 for operation with the Master Before the first startup, several settings must be made at the connected Processing Units which are described below. These settings should be made for each Hyperterminal and serial cable 7200.221. - Page 23 E 3 Setting up of the CMC-TC Processing Units DK 7320.000 for operation with the Master If any other IP addresses are registered, the CMC-TC Master will not be able to find or administer the connected Processing Unit or connected Processing Units with the incorrect entries.
-
Page 24: F 1 Check List - Commencing Operation Of Cmc-Tc Master
4. Connect alarm relay. 5. Plug in IEC connection cable / earthing of rear panel. Configuration of CMC-TC Master at commencement of operation: (see Appendix E Configuration of serial interface RS 232) Start terminal program, e.g. Hyperterminal – Part of MS Windows 1. -
Page 25: G 1 Display And Operating Elements Enclosure
G 1 Display and operating elements enclosure DK 7320.000 Item Description Function Description Start of boot procedure Reset key Microphone connection Interface will be supported in future Speaker connection Interface will be supported in future LED Alarm Display …Operating voltage light on: is on light off:... -
Page 26: H 1 Display And Operation By Terminal Program
192.168.30.100 or system). e.g. 130.0.2.246 <Start> <Programs> <Accessories> <Communications> <HyperTerminal> <open assigned name, e.g. RITTAL CMC> Query of Master Logins: Query of Master Logins: 1. username: cmc (Work's default setting) 2. password: cmc (Work's default setting) 1. username: cmc (Work's default setting) 2. - Page 27 H 1 Display and operation by terminal program DK 7320.000 The settable software functions are listed in Appendix J 1 Software functions and summarily described. Further information is shown when the corresponding menu items are called. Selected software functions from the list are described in more detail here: IP address of receiver of trap messages Item: 5 / Menu item 1.2 When using the management software, based on protocol SNMP, the IP...
-
Page 28: I 1 Operation Of Cmc-Tc Master By Browser
Operation of CMC-TC master by browser DK 7320.000 1. Start standard browser, as normal. 2. Enter IP Address of RITTAL CMC-TC Master below field Address, e.g. http://192.168.30.100 (work's default setting) 3. The following page informs you that the login-page and the following pages are transmitted encrypted by SSL. -
Page 29: Explanation Info Window - Certification Information
Operation of CMC-TC master by browser DK 7320.000 Explanation info window – Certification information Safety instructions Note ... Observe also the notes made The certificate used has not been verified by a Certificate on left! Authority. This was not done because the monitoring system is... -
Page 30: Logging In To The Cmc-Tc Master
For this purpose you set up under Admin -> User management a new administrator (log in as administrator to create users) and deleted the default users (admin and rittal). The exact procedure for changing the user settings is described under I 1 -> Tab Admin -> User management. -
Page 31: Structure Of The Html Pages
Operation of CMC-TC master by browser DK 7320.000 Structure of the HTML pages Note: At this point only the structure of the page layout is explained. The pages will be explained subsequently. Display Virtual tabs: RITTAL Logo and product description... -
Page 32: Tab - Trap
Operation of CMC-TC master by browser DK 7320.000 Tab – Trap Trap list of CMC-TC Master Display of arriving trap - Trap messages can be assigned certain severities that messages: sorted according ... are displayed by different colors, in the last column of the - to date and time –... -
Page 33: Setting Severity Of A Trap Message
Operation of CMC-TC master by browser DK 7320.000 Tab – Trap Setting severity of a trap message It is possible to reset the counter of the traps to 0 again and to current time via the Reset button. The display of the traps remains unaffected. -
Page 34: Tab - Overview
DK 7320.000 Tab – Overview Overview of the PUs connected to the CMC-TC master The overview page can be styled by the administrator (see tab: Admin -> Overview page setup) with a background graphic. In this way the status of the connected Processing Units can be acquired at once and at the same time assigned to the corresponding location. -
Page 35: Tab - Status
Operation of CMC-TC master by browser DK 7320.000 Tab – Status Status display of selected CMC-TC PU Display: Note: The display mode of the Status tab corresponds - Name of CMC-TC Processor Unit almost to the corresponding browser interface of the - Description of the location Processing Unit. -
Page 36: Tab - Setup
Operation of CMC-TC master by browser DK 7320.000 Tab – Setup Setup page of the selected CMC-TC sensor unit and its CMC-TC PU Under Setup you can configure the sensor unit you select under Status. For instance, in the Status tab you can change the names of the PU and connected sensor units. Here you can also change the access codes for the number code locks and the warning and alarm thresholds of the sensors. -
Page 37: Changing Access Codes Of The Selected Pu Online
Operation of CMC-TC master by browser DK 7320.000 Tab – Setup Changing access codes of the selected PU online General: The access codes of the connected number code locks are changed centrally by Edit access codes online/offline. In the online version the codes can be changed in the web browser, in the offline version you must download, change and again upload a text file via the input prompt. -
Page 38: Tab - Setup
Operation of CMC-TC master by browser DK 7320.000 Tab – Setup Changing access codes of the selected PU online Open the text editor used on your computer and store the empty text file under the name “accesscodes.txt”. Clicking on the Setup tab opens the window shown below again. -
Page 39: Tab - Setup
Operation of CMC-TC master by browser Tab – Setup Changing access codes of the selected PU online (initial startup) Search for the file “accesscodes.txt” on your computer. Mark the file and click on Open. Enter the FTP name and password for the PU: (factory setting for PU II: FTP Name: “admin”... -
Page 40: Tab - Setup
Operation of CMC-TC master by browser DK 7320.000 Tab – Setup Changing access codes of the selected PU online Clicking on the link “Add access code number” opens the following window. Here you now enter the 4-digit access code and place the appropriate checkmarks for the doors. -
Page 41: Changing Access Codes Of The Selected Pu Online
Operation of CMC-TC master by browse DK 7320.000 Tab – Setup Changing access codes of the selected PU online The codes now specified and the door assignments are displayed in a table like the one shown below. You can set additional codes and door variations by clicking on the link “Add access codes numbers”. You must now load the codes on the Master. -
Page 42: Tab - Setup
Operation of CMC-TC master by browser DK 7320.000 Tab – Setup Changing access codes of the selected PU offline (initial startup) General: The access codes of the connected number code locks are changed centrally by Edit access codes online/offline. In the online version the codes can be changed in the web browser, in the offline version you must download, change and again upload a text file via the input prompt. -
Page 43: Tab - Setup
Operation of CMC-TC master by browser DK 7320.000 Tab – Setup Changing access codes of the selected PU offline (initial startup) Create a text file with the text editor of your PC. The file contents must be structured as shown below. After making the required entries, save this file with the file name "accesscodes.txt". -
Page 44: Tab - Setup
DK 7320.000 Tab – Setup Changing access codes of the selected PU offline (initial startup) Return to the CMC-TC master and click on the "Setup" tab. Now click on the link “Edit access codes offline”. Search for the file “accesscodes.txt” on your computer. Mark the file and click on Open. -
Page 45: Tab - Setup
Operation of CMC-TC master by browser DK 7320.000 Tab – Setup Changing access codes of the selected PU offline If the access codes are entered on the PU, select the PU on which the codes are to be changed. The next steps describe how to download the access codes. -
Page 46: Tab - Images
Operation of CMC-TC master by browser DK 7320.000 Tab – Images Displaying the Webcam photos stored in the master The Webcam photos stored by the master device can be displayed in this tab. You can configure the Webcams under Admin -> Webcam settings. -
Page 47: Download Or Delete The Webcam Photos Saved In The Master
Operation of CMC-TC master by browser DK 7320.000 Tab – Images Download or delete the Webcam photos saved in the master This deletes the images in the above selected period. You can download the images from the selected period as TAR archive from the master via Download images archive. -
Page 48: Tab - Alarms
Operation of CMC-TC master by browser DK 7320.000 Tab – Alarms Definition of alarm conditions You can define in the Alarms tab how state changes at the sensor units should be processed by the master device. A condition is created for each state to be dealt with or a combination of these states. - Page 49 Operation of CMC-TC master by browser DK 7320.000 Tab – Alarms Definition of alarm conditions The type of notification is defined in this window. With combined alarm conditions, the occurred state can be described in the trap list with the name.
-
Page 50: Tab - Admin
Bedienung CMC-TC Master über Browser DK 7320.000 Tab – Admin General: Overview of administration page General: This tab is accessible only for users with administrator rights. Administrators can make general settings that cannot be changed by users who only have write/read authorization, such as changing IP addresses, creating and deleting users or loading firmware updates. -
Page 51: General Setup
Operation of CMC-TC master by browser DK 7320.000 Tab – Admin General setup Setting: - Date - Time The time can also be polled from an NTP server. In this case, you only need to enter the IP address of the server. -
Page 52: User Management
Operation of CMC-TC master by browser DK 7320.000 Tab – Admin User management Setting of the access authorization for max. 100 users can be made only by a user with administrator rights. Note: Leave the password fields of the other users empty, as they could be altered after confirming 'Change'. - Page 53 Procedure for deleting a user: The check mark after Delete User is set after the user to be deleted and deletion is confirmed with Change. Recommendation: Change the default setting for safety reasons. For further details see I 1 -> Logging in to the CMC-TC Master In the "User login settings"...
-
Page 54: Alarm Notification Receiver
Operation of CMC-TC master by browser DK 7320.000 Tab – Admin Alarm notification receiver Predefined alarms can be sent to the trap, email and popup addresses stated here. The setting of which alarms to whom and in which form they are sent can be made in the Alarms tab. -
Page 55: Remote Shutdown Settings
Operation of CMC-TC master by browser DK 7320.000 Tab – Admin Remote shutdown settings You can create various configurations with this dialog for shutting down the server or PC through the master. You can select these shutdown settings in the alarm configuration in the last window under "Alarm actions". -
Page 56: General Information On The Shutdown Of Computers
[password] | sudo –S /sbin/shutdown –c To enable access from the CMC-TC master device to the system to be shut down, the fingerprint of the relevant Linux computer exchanged at the log-in must be known to the master device. -
Page 57: Alarm Actions
Operation of CMC-TC master by browser DK 7320.000 Tab – Admin Alarm actions Alarm actions that can be incorporated in alarm conditions in the Alarms tab can be created here. Individual alarm actions can be deactivated or activated again with disable and enable. - Page 58 Operation of CMC-TC master by browser DK 7320.000 Tab – Admin Webcam settings Period duration in which the Webcam selection. None, the first Activating or deactivating images should be stored. webcam that is recognized or both. storage of the images of The settings to be made apply for both the webcam.
-
Page 59: Webcam Settings
3. After the transfer has been completed the packed file “images.tar” can be deleted from the hard disk of the CMC-TC Master. There is no further security check. 4. The saved images (regularly saved images or alarm images) can be deleted. -
Page 60: Logfile Management
Operation of CMC-TC master by browser DK 7320.000 Tab – Admin Logfile management The logfile is a text file in which all traps are listed. In addition alarms can be recorded in the logfile if this was selected in the alarm configuration. The logfile is not deleted on switching off or restart of the master. -
Page 61: Update Connected Device
Operation of CMC-TC master by browser DK 7320.000 Tab – Admin Update connected device Function to update the connected PUs. To ensure that no conflicts can arise with the master, PU I must have at least firmware version 1.21. If the version number of PU I is greater than or equal to V1.23 or that of PU II greater than or equal to V2.15, the status "no"... -
Page 62: Firmware Update
Operation of CMC-TC master by browser DK 7320.000 Tab – Admin Firmware update Download the firmware update from the Internet and unpack it into a separate directory. First step: Activating TFTP server on the master device: Set check mark and confirm with Change TFTP-Server settings. -
Page 63: J 1 Software Functions
Accept updated values 2 Branching to Telnet menu of Processing Units Table Factory settings for user name and passwords Username Password Encryption Hyperterminal Tera Term Browser – User rittal rittal 128 Bit (SSL) Browser – Administrator admin admin 128 Bit (SSL) -
Page 64: K 1 Fault Messages Master Unit
Power supply unit not connected or Connected power supply unit, see Appendix E 1 Electrical connection: unit cable damaged “off” voltage CMC-TC master unit, or replace unit cable. ☺ 2 LED Processing Processing unit No Processing Unit connected Connect Processing unit, see Appendix E 3 Preparation of the CMC-TC Unit “off”...
