INIM Electronics V100 Quick Start Manual

GENRAL DESCRIPTION
V100 is an analogue addressable optical
smoke detector based on Tyndall effect.
The innovative design of the baffle which the
air flow has to pass trough before enter in the
sampling chamber
immunity to environmental dust and a long
period between two consecutive cleaning of
the chamber. Each detector is equipped with a
Loop short circuit isolator.
The
status LED provides full
360° visibility. The LED can
signal an alarm condition
(red), a fault condition or
loop short circuit condition
(yellow). The led can also be
manually switched on from
control panel (green) for an
easy identification of the
detector.
equipped with an output for
remote signalling (FI100). Detector sensitivity
can be adjusted directly from control panel,
by means of a magnet the detector can be
inducted in alarm state for test pourpose.
The detector can be fitted in the following
mounting bases:
• VB100 (standard base)
• VDBS100 (deep base)
• BLR100 (relay base)
• VBS100 (siren base)
V100 detectors can be used with the control
panels:
• SMARTLoop
INIM Electronics
ANALOGUE ADDRESSABLE
OPTICAL SMOKE DETECTOR
guarantee an high
centrally positioned
Detectors are
V100 – Analogue addressable optical smoke detector
V100
• SMARTLight
Detector address (from 1 to 240) can be
selected:
• By means of VPU100 programmer
• Using the control panel self addressing
feature

MAIN FEATURES

• Approved according to EN54-7
Standard by BSI (N° KM96627)
• Approved accordin European
Construction Products Directive
(CPD) : 0086-CPD-504705
• Hi noise immunity
• Fast response
• 3 Colour led located in the detector
center
• Output for remote LED driving
• Available with DECOR option
(Wood, marble etc.)

INSTALLATION

The detector muonting base must be installed
on the ceiling by means of 2 fisher screws and
the
connected to its terminal
boards.
detector on its mounting
base
clockwise,
gentle pressure. The detector will slot into
position. Press gently and continue to rotate
clockwise a few degrees until the detector is
firmly attached to its mounting base
wires must be
Position the
and rotate it
applying
