AP CDH Manual

Manual for Hand Held Carbon
Dioxide and Temperature Monitor
Accessories
CO View TM Real-Time Graphing Software & Calibration
2
This Software allows the CDH to log directly to a Windows
compatible PC and graph concentrations in real time.
Includes graphing software and RS232 connection cable.
All data is stored in a txt.file, which is easily opened by other
programs.
CO View also provides and interface that allows the user to
TM
2
perform a zero and span calibration on the sensor.
Hobo Datalogger Kit CO
®
2
This kit includes a tiny data-logger that can record CO
concentrations from the CDH and also measures temperature
and relative humidity.
The data-logger can be easily attached to the CDH using the
provide Velcro strip.
TM
The data-logger can store over 7900 data points and can
sample at a user adjustable time interval.
Also provided with Boxcar software provides basic launch,
data readout. graphing and export capabilities.
Introduction
The CDH is an easy-to-use hand-held CO
monitor.
The unit provides stable, highly accurate readings due to our
patented dual beam NDIR technology.
Equipped with a 0-4 V output, the unit is perfect for long-term
monitoring/recording.
The unit features a large, easy-to-read display with a push-
button interface which al-lows for easy calibration, quick
adjustments for altitude correction, and simple toggling
between °C and °F temperature readings.
A new feature of the sensor now includes the ability to
calculate and display the cfm/person ventilation rate in a
space based on the inside/outside CO
-Temp &RH
/Temperature
2
concentration.
2
Features
1. Lightweight
2. Display
3. Soft Touch
4. Up/Down
Button
5. Mode Button
6. Power
7. Enter
8. Calibration
Port
9. Calibration
Activation
Switch
10. Voltage
Output
2
11. Built-in
Kickstand
12. Power
Connection
13. Battery
Compartment
14. Battery Cover
14
Automatikprodukter
CDH
Made of ABS Plastic.
This durable, lightweight plastic adds
protection while weighing less than one
pound.
The large display allows for CO
Temperature readings at a glance.
The display also allows for adjustments
to mode settings using the push button
interface.
Attractive, gives comfort and extra
durability.
Used to increase or decrease values
while the edit mode.
Toggles between menu options.
Turns the power on and off.
When toggling between menu options,
the Enter button will select desired menu
option for editing (e.g. Altitude settings).
After changes have been made, the
Enter key will also confirm settings and
return to the main menu.
Used for gas connection during
calibration or for providing a flow through
sample to the sensor.
Located in the battery compartment, this
switch is used for activating the
calibration process for CO
The sensor is equipped with an output
for datalogging. (see accessories).
For continuous monitoring.
The built-in kickstand simply swings out
from the base to support the monitor in
an upright position.
For connecting the supplied 6V power
adapter.
4 AA Batteries are required for portable
operation.
1
13
12
9
10
7
8
5
6
11
Jan.08
