SC100
HARDWARE MANUAL
• SC100
Serial Device Server
05 / 2022
MIKRODEV_HM_SC100_EN
v1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC100 and is the answer not in the manual?

Questions and answers

Summary of Contents for MIKRODEV SC100

  • Page 1 SC100 HARDWARE MANUAL • SC100 Serial Device Server 05 / 2022 MIKRODEV_HM_SC100_EN v1.2...
  • Page 2: Table Of Contents

    CONTENTS FIGURES LIST ..........................2 Preface ............................3 About Mikrodev..........................4 WARNING! ............................5 SC100 GENERAL INFORMATION ................ 6 GC2 Board Type Physical Interfaces ............. 6 General Device Spesifications ..............7 INSTALLATION INFORMATION................8 Rail Installation ..................8 CONNECTION DIAGRAMS ................10 Supply Connection ..................10...
  • Page 3: Figures List

    Figure 1 GC2 Board Type Connector and Physical Interfaces ........6 Figure 2 Mounting Information ................8 Figure 3 Demountage ..................... 9 Figure 4 Power Connection Diagram ................10 Figure 5 RS485 Input Connection Diagram ..............11 Figure 6 RS232 Input Connection Diagram ..............12 SC100 SERIES – HARDWARE MANUAL...
  • Page 4: Preface

    Preface Mikrodev SC100 Serial Device Server, the devices on RS232 and RS485 lines are connected networks transparently. provides two-way transparent communication. The SC100 series converters are optionally connected to the TCP protocol via GPRS, Ethernet, Wi-Fi, RF networks. In this document, you can find information about the hardware specifications of Mikrodev SC100 series devices.
  • Page 5: About Mikrodev

    MIKRODEV is one of the few companies in the world that has its own designed IEC 61131-3 compliant library for its programmable logic control devices. In addition, the open, flexible, programmable SCADA solution developed by MIKRODEV is also available to customers.
  • Page 6: Warning

    ✓ Make sure that the environment in which your device is being used is free of moisture, electric shock, vibration and dust. ✓ Pay attention to the supply voltage and the connections of the product. Mikrodev is not responsible for any issues due to power failure since there is no auxiliary supply (UPS) on the device.
  • Page 7: Sc100 General Information

    Power LED USB Configuration Port System LED RS485 Connections Remote Connection LED Serial Port GND Connection GSM or Wi-Fi Antenna Connection RS232 Connections SIM Card Slot Device Power (V+) Connection Ethernet Port Device Power (V-) Connection SC100 SERIES – HARDWARE MANUAL...
  • Page 8: General Device Spesifications

    1 Port RS232 1 Port Quad-Band 850/900/1800/1900 GSM / GPRS* MHz or LTE Wireless Communication Wi-Fi* IEEE 802.11 b/g/n 868 MHz USB Port 1 Port, Mini USB Type B Configuration Over TCP Eth/Wi-Fi/GSM/RF *Optional Selection SC100 SERIES – HARDWARE MANUAL...
  • Page 9: Installation Information

    First, the upper part of the device is mounted on the DIN rail. Then, with the help of the springs behind the device, when a lightly force is applied to the lower part, the device locates into the DIN rail easily and the montage is completed. Figure 2 Mounting Information SC100 SERIES – HARDWARE MANUAL...
  • Page 10 DIN Rail Demountage To demount the device, firstly it is pulled from the bottom using flexibility of the spring, the device is removed from the DIN Rail and the demounting is completed. Figure 3 Demountage SC100 SERIES – HARDWARE MANUAL...
  • Page 11: Connection Diagrams

    CONNECTION DIAGRAMS 3.1 Supply Connection Board Type: Supply: 9-36 VDC, Protected Power: <13 W Figure 4 Power Connection Diagram SC100 SERIES – HARDWARE MANUAL...
  • Page 12: Rs485 Serial Port

    ESD Protection, 8 KV Direct, 25 kV Air Discharge Maximum Slave Counts: Limited to Hardware Communication Distance: 1000 m Data Bits: Stop Bits: Parity: None-Even-Odd Baudrate: 300 bps to 200 kbps Figure 5 RS485 Input Connection Diagram SC100 SERIES – HARDWARE MANUAL...
  • Page 13: Rs232 Serial Port

    3.3 RS232 Serial Port Board Type: RS232 Port Count: 1 Port Communication Distance: 10 m Data Bits: Stop Bits: Parity: None-Even-Odd Baudrate: 300 bps to 200 kbps Figure 6 RS232 Input Connection Diagram SC100 SERIES – HARDWARE MANUAL...
