Chart 5-1 Continued
STATION RINGER TEST - KEY SEQUENCES
16 Dial Pad key #
17 Feature key 1
18 Feature key 2
19 Feature key 3
20 Feature key 4
21 Feature key 5
22 Feature key 6
23 Feature key 7
24 Feature key 8
25 Feature key 9
26 Feature key 10
27 RELEASE key
28 HOLD key
29 Vol. UP
30 Vol. DOWN
31 Handset OFF-HOOK
32 Handset ON-HOOK
33 HOLD key
34 HOLD key
35 Vol. UP
36 Vol. DOWN
37 HOLD key
All LCDs OFF
LCD 1 ON
LCD 2 ON
LCD 3 ON
LCD 4 ON
LCD 5 ON
LCD 6 ON
LCD 7 ON
LCD 8 ON
LCD 9 ON
LCD 10 ON
LCDs 2 & 8 ON
Dial Tone. LCD 1 through
5 ON
Volume Up
Volume Down
Dial Tone from Handset.
All LCD flash
Dial tone switches to
Handsfree speaker. LCD
12 ON. LCD 1 through 10
wink.
1 second of BUZZ (Alert
B), and LCD 6 through 10
ON, all other LCD
indicators OFF.
RINGING
Volume UP
Volume DOWN
-
PRACTICE 297-2011-202
Soft Reset
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, LCD ON
Soft Reset, Turn on Tip/Ring to
Speaker, LCD ON
None (Test Voice Volume
Control)
None (Test Voice Volume
Control)
Turn off Tip/Ring to Speaker,
Turn on Handset, LCD Indicators
Flash
Turn on Tip/Ring to Speaker,
Turn off Handset, LCD
Indicators Wink
Turn On/Off Alert B, LCD ON.
None (Ring tone from CO)
None (Test Ring Volume Control)
None (Test Ring Volume Control)
Hard Reset (test completed)
Page 5-3
