Shakmat Triple Steeple Quick Start Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
8HP Eurorack Module
Built & designed in E.U.
www.shakmat.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Triple Steeple and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shakmat Triple Steeple

Summary of Contents for Shakmat Triple Steeple

  • Page 1 8HP Eurorack Module Built & designed in E.U. www.shakmat.com...

  • Page 3: Installation

    Time potentiometer Outputs Shape LED Activity LED Assignable CV/ Level button Installation The Triple Steeple requires a standard 2x5 pin eurorack power cable. Make sure the red stripe on the cable matches the -12V side of the Triple Steeple power header.
  • Page 4 Time & Symmetry Rather than having a classic attack-decay approach, the Triple Steeple offers control of each envelope's timing and symmetry. The time parameter, set via the Time potentiometer and CV input [3], is the sum of the attack and decay time. Modifying the time parameter will change the attack and decay time by the same amount.
  • Page 5 03. Looped The envelope loops continuously. A rising edge at the input resets it. 04. Gated Loop The envelope loops continuously while a high gate signal is present at the input. It instantly returns to its minimum value when the gate signal disappears. 05.
  • Page 6 01. Symmetry The ACV input acts as a bipolar (-5v to +5v) control of the symmetry, added to the value of the channel's symmetry [A]. 02. Amplitude The ACV input acts as a positive unipolar (0v to 5v) control of the amplitude, which varies between 0v and the amplitude selected in the level menu (see below).
  • Page 7 Input Normalization Channels 2 and 3 receive the decay state of the previous channel when nothing is inserted into their gate inputs This normaliza- [2]. tion allows for different applications, as described in this manual's patch ideas section. In this example, you can see the channel 1’s decay state acting as a gate for channel 2 in gate mode: Channel 1 Channel 1...

  • Page 8: Patch Ideas

    Current State Storing It is possible to save the current modes, response type, levels, and ACV assignment by pressing and holding the ACV button for 2 seconds. All LEDs will blink to confirm the storage. Patch Ideas 1. Percussive envelopes: set 3 channels of decay with exponential response, enable accents, and start designing drum sounds! 2.
  • Page 9 5. ADSR style envelopes: use channel 2 in trigger mode and channel 3 in gate mode, then send the same gate signal in both inputs. Set channel 3 amplitude to a lower level than channel 2. Channel 2 settings will define the attack and decay, set channel 3 symmetry in order to have a longer attack time than channel 2.

  • Page 10: Specifications

    -5 to +5V Depth Gate inputs 21 mm 0 to +5V Current Draw CV outputs 40 mA @ +12V 0 to +8V 8 mA @ -12V Full cycle enveloppe timing 2.5 ms to 15 sec. Minimum attack-decay time 200 µSec www.shakmat.com...
