Summary of Contents for Hiwonder Qdee
- Page 3 (2)Using the GooglePlay store to search for the Qdee App. Qdee ASSEMBLY 1.Qdee Configuration Assembly (1) Install App on your Android phone. (2) Open App interface. Click install interface on the left. Enter into Qdee assembly tutorial.
- Page 4 (3) Follow the video instructions to assemble Qdee Starter shape first. (4) Complete Qdee Starter Configuration Assembly. 2.How To Do the Wiring (1) Take the motor wire to cross through the Qdee bottom, and insert it into the corresponding motor port on Qdee controller.
- Page 5 (2) Connect the line follower sensor to No.1 port on controller through using 4pin wire.（the excessive wire can cross through the bottom of controller, make sure that the looking is pleasing to eye）...
- Page 6 (3) Connect ultrasonic sensor to No.2 port on controller by using 4pin wire. (4) Install 6 AA batteries, plug the power line into the battery port on the back.
-
Page 7: Bluetooth Connection
Qdee GAMEPLAY TEST 1. Download Qdee Program (1) Using the USB cable to connect the micro:bit on Qdee and computer, there will be a micro:bit flash drive on the computer. (2) Copy“Qdee.hex”file into micro:bit flash drive, the downloading process will be finished until the indicator on micro:bit stops flashing 2. -
Page 8: Movement Control
PS: If the Bluetooth fails to connect, or the robot has no response while successfully connected. Turn off the Qdee App, restart Qdee power supply, try to connect again. 3. Movement Control (1) Click the middle icon on the App interface. - Page 9 Qdee movement and speed adjustment. (3) Colored Light Control Click colored light button，control different color on Qdee back.
- Page 10 Click the left extended bar on the control interface, choose light control mode. Enter into light control interface. Click the colored circle to show the corresponding color onQdee.
- Page 11 4. Gravity Game (1) Replace the original micro:bit hex file into“game.hex”file. (2) Return to control menu. Slide the icon to the left. Choose game icon. Lean to the left or right can both control Qdee movement. That’s how we achieve Tank Battle.
- Page 12 5. Application Obstacle-avoidance (1) Replace the original micro:bit hex file into“application.hex”file. (2) Using the carton or other box to build up a maze space.
- Page 13 Qdee will run the corresponding program to achieve the gameplay. (4) Put Qdee into the maze space. Qdee will detect the obstacle in front along the way. If there is, Qdee will avoid the obstacle intelligently and continue to move...
- Page 14 Line Follower (1) Assemble Qdee into line follower shape, enter assembly interface. We can simply remove the ultrasonic sensor and line follower sensor, and add the L-shape bracket.
- Page 15 (2) Noted: Make sure the LED light placed in the front while installing theline follower sensor, like the pictureshows. (3) Use a black tape to stick the S-shape or other shape on the table, make sure that the black line being smooth, as the picture shows.
- Page 16 (4) Place Qdee on the black line. Make sure the line follower sensor face to the black side. (5) Turn on Qdee switch, connect to Bluetooth. Enter into App control interface. Click the left extended bar, choose line following mode, then Qdee will follow the...
