Page 2
Foreword If any problems occur during while using your Trio, please feel free to contact Mach Speed technical support at 580-272-0035, or sending an email to mssupport@machspeed.com. Thank you for your support and cooperation! Mach Speed Technologies bears no responsibility for any damage or...
Page 3
verify that your download service allows you to download files in MP3 format, or a non encrypted WMA format before loading files to the player. ● The playback times listed refer to the maximum playback times possible, using the best power savings. The actual playback time may differ as adjustments to screen brightness, power savings modes, volume, etc are made.
Page 4
Increase the separation between the equipment and the receiver Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Caution Do not use the player in exceptionally cold or hot, dusty, damp or dry environments.
Page 5
Appearance Basic Operations Powering on: Set the ON/OFF switch to the ON position, then press and hold the PLAY button for 5 seconds. Powering off: Press and hold the PLAY button for 5 seconds, until the player powers off. Once the device is powered off, set the ON/OFF switch to the OFF position.
Page 6
(Note: you must use Windows Media Player 10 or later to use this feature.) (Note: this player does not support DRM encrypted audio files, such as those downloaded from the Overdrive download service.) Open Windows Media Player and connect the MP3 player to a working USB port.
Page 7
Open the Windows Media Player Sync tab. Drag your music to the sync list (on the right of the screen) from the list on the left. Once you have selected the music you wish to add to the player, press “Start Sync”.
Page 8
Windows Media player will load the songs on to your MP3 player. Once all the songs you have added are synced to the unit, and Windows Media Player says that is safe to disconnect your MP3 player, disconnect the device.
NOTE- This method is also used to load your lyric or text files to the player. 1. Connect the MP3 player to a working USB port. 2. When the unit is connected to your computer, it will create a gray and green icon in the system tray (lower right hand corner of your desktop).
Page 10
4. Locate the drive created by the unit, generally just called Removable Disk, with a letter in Parenthesis. Drive letters vary depending on your system configuration. 5. Open the drive by either double left clicking on the drive itself, or by right clicking to open the option menu then left click on the desired drive.
Page 11
Paste. This will transfer the song on to your MP3 player. 8. Repeat step 7 for as many songs as you want to copy on to the unit. NOTE: MAC Computers When connected to your MAC computer, the device will act as a...
Page 12
Music Mode NOTE- This player supports audio files in MP3 or non encrypted W mats. If your files are not in these formats, they will not play. On the main menu, select “Music” using the Previous or Next buttons, and then press the Menu button to enter the Music mode. wh en you enter Music m ode, t...
Page 13
the Next or Previous access, then press Menu button to play. Press the VOL+ button to return to previous screen. ote: To set your repeat mode, play mode, or EQ mode, go to Setting, then Music m enu. Radio Mode NOTE- Before entering Radio mode, please insert your headphones, s they act as an antenna.
Page 14
Radio Mod e Submenu Press the Menu button to make a selection, or the VOL+ button to exit the menu. Manual- Sets the tuner to manual search. Press the Next or Previous buttons to browse through frequencies. y scans the available stations and saves any with a Auto-Automaticall strong signal as a preset.
Page 15
On the main menu, select “Record” using the Previous or Next buttons, and then press the Menu button to enter the Recording mode. In Reco rding mode, briefly press the Play button to begin recording, and when finished, briefl Briefly press the Menu button to save the current recording and begin a new one.
Page 16
Explorer Mode On the main menu, select “Explorer” using the Previous or Next buttons, and then press the Menu button to enter the Explorer mode. Press the Next or Previous buttons to select the file or folder you wish to access, then press Menu button to play.
Page 17
On the main menu, select “Settings” using the Previous or Next buttons, and then press the Menu button to enter the Settings mode. Use the Next or Previous buttons to select and item, and the Menu button to confirm. Briefly press the VOL+ button to return to the previous screen.
Page 18
Stereo Switch- flip bet FM Region-You can select your local region. Display Submenu Allows you to change display settings and power savings options. Backlight Time-This allows you to adjust the length (in seconds) that the screen will stay lit when not used. The smaller the time increment, the longer your player will last between charges.
Page 19
If at any point, you have questions about your player or expe rience an issue with your player, please feel free to contact our technicians at mssupport@machspeed.com or by phone at 580 272 0035.
