1N15-001 Pirate Blasta User Manual V3 0704
Pirate Blasta
User Manual
Note
This unit includes sound effects provided by the following
company:
http://www.freesfx.co.uk
©Tornado International Ltd. 2003
-1-
Confidential

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pirate Blasta and is the answer not in the manual?

Questions and answers

Related Manuals for Tornado Pirate Blasta

Summary of Contents for Tornado Pirate Blasta

  • Page 1 1N15-001 Pirate Blasta User Manual V3 0704 Pirate Blasta User Manual Note This unit includes sound effects provided by the following company: http://www.freesfx.co.uk ©Tornado International Ltd. 2003 Confidential...
  • Page 2 1N15-001 Pirate Blasta User Manual V3 0704 Your Serial Number is: Please quote this number when ordering parts or seeking telephone assistance. Company Information. Telephone Technical Help +44(0)121-773-1827 Ask for Technical Help Parts & Accessories +44(0)121-773-1827 Ask for the Parts Dept...
  • Page 3 Important – Please Read This! This manual is provided in good faith and is believed to be accurate. Because Tornado International have no control over the manner in which the product is used, users should satisfy themselves that any information or instruction contained in this manual is appropriate for the conditions under which the product is being installed and operated.
  • Page 4 1N15-001 Pirate Blasta User Manual V3 0704 Warning! The following information regarding the control of legionella is provided for your guidance. However information regarding the bacteria, its health risks and effective control changes over time. The user should ascertain that they are using the latest information and control techniques and that the method of control they choose is suitable for the equipment and location of its use.
  • Page 5 1N15-001 Pirate Blasta User Manual V3 0704 If the two conditions above are met then the final criteria to enable infection is droplet size. The droplets produced by the equipment’s operation have to be small enough to be inhaled by people.
  • Page 6 1N15-001 Pirate Blasta User Manual V3 0704 Caution! In all cases guidance should be obtained from the chemical manufacturer and their instructions followed carefully. Undiluted chemicals may cause harm to people and the Aqua Blasta. It is vital to train all relevant personnel in the correct use of any chemical.
  • Page 7 1N15-001 Pirate Blasta User Manual V3 0704 2.08 Control Electronics The control electronics is mounted in the door of the pump house. All of the game settings can be viewed or changed from the electronics LDC display. A comprehensive list of cash and game data can also be displayed.

  • Page 8: Change Code

    1N15-001 Pirate Blasta User Manual V3 0704 1/10 of a minute is equal to 6 seconds, i.e. a setting of 1.6 minutes will mean the game will last for 1 minute and 36 seconds. Press: Mode ► Attract Delay 5.0 Minutes The bottom line shows the amount of time the game must remain unused before the attract mode cycle is run.

  • Page 9: Enter Code

    1N15-001 Pirate Blasta User Manual V3 0704 game will vend as soon as the vend price is reached and any additional credit will be retained against the next game on the same playing position. Any retained credit is lost if power is removed from the game.
  • Page 10 1N15-001 Pirate Blasta User Manual V3 0704 If you have entered an incorrect code the display will briefly show CODE INVALID on the bottom line. The display will then revert to the opening screen in this section. Restart this procedure from the beginning (2.08.03) being careful to enter the correct code.
  • Page 11 1N15-001 Pirate Blasta User Manual V3 0704 PLAY TIME MINUTES Press & hold: Mode ► button until the display shows: PLAY TIME ▲ 1.5 MINUTES ▼ The ▲ &▼ arrows and the previously set value will be flashing to indicate that you may alter the play time up or down using the Up or Down buttons.

  • Page 12: Enter New Code

    1N15-001 Pirate Blasta User Manual V3 0704 Tip! The attract mode may be turned off by selecting “OFF” on this screen. Press: Mode ► ATTRACT DELAY MINUTES The new value is stored and displayed on the bottom line of the display.
  • Page 13 1N15-001 Pirate Blasta User Manual V3 0704 Press: Mode ► ENTER CODE ▲ # ►#◄ # # ▼ The 1 digit is stored and the arrows move to the next marker. Enter the second code digit as before. Repeat until the four digits have been entered. When you press Mode ►...
  • Page 14 1N15-001 Pirate Blasta User Manual V3 0704 The ▲ &▼ arrows and the code 1 digit marker (#) will be flashing to indicate that you may enter the 1 digit of the EXSISTING code number by using the Up or Down buttons.
  • Page 15 1N15-001 Pirate Blasta User Manual V3 0704 CONFIRM CODE ▲ ►#◄ # # # ▼ Re-enter the SAME new code using the same procedure as above. When you press Mode ► after the last digit the display will briefly change to:...
  • Page 16 1N15-001 Pirate Blasta User Manual V3 0704 AQUABLASTA V1.0 TORNADO INT. LTD Press: Mode ► 1&2 £00005.00 3&4 £00008.00 The display will show the cash meter by console. The meter is accumulative. To calculate the period’s takings, the meter reading from the previous period should be subtracted from the reading for the current period.
  • Page 17 1N15-001 Pirate Blasta User Manual V3 0704 GAMES 1&2 000100 3&4 000101 Press & hold: Mode ► button until the display toggles to the cash meter screen. Tip! In any of the meter displays you have the choice of either cash or game information.
  • Page 18 1N15-001 Pirate Blasta User Manual V3 0704 GAMES 1&2 000100 3&4 000101 Press & hold: Mode ► button until the display toggles to the cash meter screen. Tip! In any of the meter displays you have the choice of either cash or game information.
  • Page 19 1N15-001 Pirate Blasta User Manual V3 0704 Press: Mode ► GAMES 1&2 000100 3&4 000101 The display will show the games meter by console. The meter is accumulative. To calculate the period’s games (and therefore cash), the meter reading from the previous period should be subtracted from the reading for the current period.
  • Page 20 1N15-001 Pirate Blasta User Manual V3 0704 1&2 £00005.00 3&4 £00008.00 Press & hold: Mode ► button until the display toggles to the games meter screen. Tip! In any of the meter displays you have the choice of either cash or game information.
  • Page 21 1N15-001 Pirate Blasta User Manual V3 0704 1&2 £00005.00 3&4 £00008.00 Press & hold: Mode ► button until the display toggles to the games meter screen. Tip! In any of the meter displays you have the choice of either cash or game information.
  • Page 22 1N15-001 Pirate Blasta User Manual V3 0704 Press and hold the Up button until a constant stream of water is sprayed from all of the guns. Press: Mode ► to leave this function. ©Tornado International Ltd. 2003 -22- Confidential...
