1N00-510 Genesis Boat User Manual v3 05/19 Introduction Thank you for purchasing this quality product from Tornado International Ltd. It will give you many years of trouble free service and if used in a suitable site will provide consistent pro ts.
Page 5
Any shortage should be noti ed to Tornado International Ltd. in writing (letter, fax or e-mail) as soon as possible and in any event not later than 5 days after receipt.
Page 6
5. Lay out the 24V PSU cable and check that it is long enough to reach from the master console to the PSU. Note! The PSU cable must not be lengthened without consulting Tornado International Ltd. Tip! The master console can be identi ed by an additional door to the right of the coin acceptor door. It is usual- ly numbers 3/4 or 5/6.
Page 7
1N00-510 Genesis Boat User Manual v3 05/19 1.03 Consoles The consoles are usually mounted on a fence or low wall. The lip (See Dia 3) at the top of the console serves to locate the console on the top of the wall or fence and assists in the mounting process. The lip may be removed if required by marking a line along the top of the console and cutting along the line with a hacksaw.
Page 8
1N00-510 Genesis Boat User Manual v3 05/19 Caution! Whenever possible use the predrilled mounting holes in the rear of the console (See Dia 2). If this is not possible, alternative holes may be drilled in the back of the console only after checking that there are no items or electronics inside the console in the area to be drilled.
Page 9
1N00-510 Genesis Boat User Manual v3 05/19 1.05 Chargers Dia 1 - The charger case Air vents Mains input Charge indicators Dia 2 - Case mounting slots Air vents Mounting slots Batteries The chargers must be mounted on a wall using the slots in the rear of the case (see Dia 2). Draw a 325mm horizontal line on the wall on which you want to mount the charger case and drill a hole at each end.
Page 10
1N00-510 Genesis Boat User Manual v3 05/19 1.06 Routing the console cables Dia 1 – The transmitter motherboard showing the master console connection sockets (Inside the access door of the master console) Each console has a grey cable coiled inside the console on the side nearest the master console. Each of these has to be routed out of the console and into the master console.
Page 11
PSU to the consoles. Note! The PSU cable must not be lengthened without consulting Tornado International Ltd. 1. Route the cable from the PSU to the master console. 2. Plug the PSU cable into the 24V socket in the master console. (See 1.06 Dia 1) 3.
Page 12
1N00-510 Genesis Boat User Manual v3 05/19 1. Locate the loop wire and leaving 3m excess, attach the wire to the enclosure wall at a convenient point below the master console. The loop wire may be run on the outside of the enclosure wall or on the inside.
Page 13
1N00-510 Genesis Boat User Manual v3 05/19 1.09 The models: The models should be handled with care. They are designed to be as robust as possible within the constraints of their size. Most boats use the standard catch system. The alternative catch system is used on 80cm riverboats, 60cm pirate ships and 140cm power cruisers.
Page 14
2. Check the lights on the loop output board. There should be a solid green light to indicate that the loop is tuned. (See 1.06 Dia 1). Customers with previous experience of Tornado equipment will be familiar with “tuning the loop”. This is now not required as a manual operation and is carried out automatically. If a solid green light is not shown please contact Tornado service department for assistance.
Page 15
1N00-510 Genesis Boat User Manual v3 05/19 Dia 2 - Boat hull with battery tted Battery 9. Insert a battery into each boat. (See Dia 2) . Caution! Lift the rear of the model as the battery is slid into position to allow the propellers to rotate.
1N00-510 Genesis Boat User Manual v3 05/19 2.00 Operating procedures To ensure this product remains in good working order these instructions should be followed daily. 2.01 Opening instructions 1. Remove the console covers; visually check the consoles for any damage.
Page 17
1N00-510 Genesis Boat User Manual v3 05/19 3.00 Detailed overview of the system 3.01 Consoles Dia 1 - Console Credit button Driving controls Credit display Access door (Master console only - pictured) Coin acceptor door The consoles are made from glass bre with a blockboard reinforcing for the back wall. Regular application of a quality polish will reduce the harmful e ects of sunlight.
Page 18
1N00-510 Genesis Boat User Manual v3 05/19 The master console can be identi ed by the provision of an additional door to the right of the coin acceptor door. It is usually console number 5/6. This door allows access to the transmitter motherboard.
Page 19
Microcoin electronic coin acceptors are tted to the unit. These can be reprogrammed and can accept multiple coins and or tokens. Please contact the service department for details. There are no user service- able parts in the coin acceptors. They should be returned to Tornado for service. Dia 1 - Credit display & credit button 3.03 Credit display...
Page 20
1N00-510 Genesis Boat User Manual v3 05/19 Credit dispay main screen Dia 1 - Main screen Coins accepted Vend value Credits available odd Credits available even Coin total odd Coin total even Coins accepted: The coins accepted by the electronic multimech can be displayed on the credit display main screen for customer information.
Page 21
1N00-510 Genesis Boat User Manual v3 05/19 QL credit display Dia 2 - Front Credit display main screen Menu control labels Dia 3 - Rear Display contrast control Microcontroller External socket interface Enter button Down button Up button Menu control buttons: The menu control buttons are located at the rear of the credit display (see Dia 3).
Page 22
1N00-510 Genesis Boat User Manual v3 05/19 Multimech interface board Dia 4 - Interface board Electronic multimech even Electronic multimech odd Free go even button Counter button Free go odd button Free go odd / even: The operator may increase the credits available by pressing the free go buttons (see Dia 4). For every press of the button 1 credit is incremented on the corresponding counter.
Page 23
1N00-510 Genesis Boat User Manual v3 05/19 Adjusting coin vend price The coin vend price is the value of 1 credit in currency and will give the customer 1 play. When a coin vend price is selected it will be displayed on the main credit display screen informing the customer of the value of 1 credit.
Page 24
1N00-510 Genesis Boat User Manual v3 05/19 Adjusting token vend The token vend is the value of 1 credit in tokens and will give the customer 1 play. When a token vend price is selected it will be displayed on the main credit display screen informing the customer of the value of 1 credit.
Page 25
1N00-510 Genesis Boat User Manual v3 05/19 Adjusting swipe vend The swipe vend is the value of 1 credit in card swipes and will give the customer 1 play. When swipe vend is selected it will be displayed on the main credit display screen informing the customer of the value of 1 credit.
Page 26
1N00-510 Genesis Boat User Manual v3 05/19 Adjusting currency The currency symbol used by the credit display can be changed to suit the country of use. Changing the currency symbol does not change any of the vend price settings. Press the ENTER button on the credit display to access the MAIN MENU screen on the display.
Page 27
1N00-510 Genesis Boat User Manual v3 05/19 Adjusting coins displayed The coins accepted by the credit display can be displayed on the main credit display screen. These settings do not adjust the multimech con guration and may need to be independently programmed.
Page 28
1N00-510 Genesis Boat User Manual v3 05/19 Adjusting decimal point Not all currencies have a decimal point and may need it to be disabled. Press the ENTER button on the credit display to access the MAIN MENU screen on the display.
Page 29
Press the ENTER button on the credit display to access the MAIN MENU screen on the display. Using the UP & DOWN buttons on the credit display select the TORNADO menu. When the TORNADO menu has been selected press the ENTER button to take you to the next menu screen.
Page 31
1N00-510 Genesis Boat User Manual v3 05/19 3.04 Cash box Dia 1 - Box front Dia 2 - Box rear Dia 3 - Locking Handle Padlock provision Coin exit Coin entry The cash box is mounted in the centre of the console behind the coin acceptor door. There is provision to t your own padlock for added security.
Page 32
1N00-510 Genesis Boat User Manual v3 05/19 3.05 Console motherboard Connection to credit display Dia 1 - Console motherboard Credit display interface board Connection to driving controls - (odd side) Connection to driving controls End of game sounder (even side)
Page 33
1N00-510 Genesis Boat User Manual v3 05/19 3.06 Slave timer The slave timer (see 3.05 Dia 1) is mounted on the console motherboard. Each slave timer serves two play- ing positions. It is essentially two timers in one case. The slave timer performs the following functions;...
Page 34
1N00-510 Genesis Boat User Manual v3 05/19 3.08 Transmitter motherboard Dia 1 - Transmitter motherboard Dia 2 - Transmitter motherboard with case The transmitter motherboard is housed in the master console behind a plastic cover. It is accessed by open- ing the door under the driving controls and removing the cover through the coin acceptor door.
Page 35
Note! If you operate more than one type of Tornado equipment, you may have transmitters for the other equip- ment which look very similar. All items supplied in the spares pack should only be used with the equipment for which they were supplied.
Page 36
The power is distributed to the rest of the system via the console cables. 3.15 Diagnostic socket This is provided for the use of Tornado service engineers. Do not connect to this socket. 3.16 Accessory socket This is provided for the attachment of Tornado accessories. Instructions will be provided with the accessory.
Page 37
Warning! Disconnect the mains supply before removing the cover. Warning! Only use the power supply supplied by Tornado for this equipment. Using another PSU can cause personal injury or damage to the equipment. Caution! Always replace the power supply fuses with one of identical type and rating.
Page 38
1N00-510 Genesis Boat User Manual v3 05/19 3.19 Battery charger Dia 1 - Charger case Air vents Mains input Charge indicators Dia 2 - Charger module rear Fuses - 2A quick blow glass Air vents Batteries The battery charger consists of an outer case to which up to six charger modules can be tted. The case houses the modules, distributes power to them and holds the batteries during the charge cycle.
Page 39
1N00-510 Genesis Boat User Manual v3 05/19 Dia 3 - Awaiting a battery Dia 4 - Charging Dia 5 - Fully charged Each module has four LEDs to indicate the level of charge in the connected battery. One red light indicates no charge, and each subsequent red light is equal to 25% of charge.
Page 40
1N00-510 Genesis Boat User Manual v3 05/19 3.20 Batteries Dia 1 - Battery Contacts Vents The batteries are of the sealed lead acid type. Please read the following information before use. Warning! Risk of re. The batteries are capable of producing very high currents for a considerable time. Never place the batteries in a position which might allow the terminals to be shorted by a conducting material.
Page 41
Charging It is vital to use a quality charger. The Tornado charger supplied with your unit has been tested by the battery manufacturer and is approved by them for use with the dry- t batteries supplied. Do not charge the batteries with any other charger and do not use the Tornado chargers on other batteries.
Page 42
1N00-510 Genesis Boat User Manual v3 05/19 When tting and removing the batteries handle them with care. Avoid dropping them into the model or onto the oor. Dropping the battery will cause the plates to deform with the result that some cells will become useless.
Page 43
1N00-510 Genesis Boat User Manual v3 05/19 3.21 Model catch systems Boats have di erent catch systems depending on the model, as shown below; Dia 1 - Dia 2 - Alternative catch Standard catch Thumbscrew hole Locating tab Thumbscrew hole...
Page 44
1N00-510 Genesis Boat User Manual v3 05/19 3.22 The models Drive motors Dia 1 - Boat Receiver Battery Battery contact assembly Dia 2 - Boat side view Receiver clip Propellers The model boats are built from glass bre. The tops are produced from UV stabilised PVC. Regular applica- tion of a quality polish will reduce the harmful e ects of sunlight.
Page 45
1N00-510 Genesis Boat User Manual v3 05/19 Dia 5 - Oil application The propeller shafts are made of stainless steel and are supported by only one bearing. It is at the bottom of the shaft immediately in front of the propeller. The motor serves as the upper bearing. The bottom bear- ing is lubricated by the application of a small drop of light machine oil introduced through the motor cup at weekly intervals.
Page 46
To comply with the terms of the guarantee any part or assembly which requires repair or replacement must be returned to Tornado International Ltd. without being opened or disassembled. The guarantee period is 1 year from the date of shipment.
1N00-510 Genesis Boat User Manual v3 05/19 4.00 Periodic service 4.01 Daily Follow the procedures in section 2.00 “Operating procedures”. 4.02 Weekly Inspect the propeller shafts. Check that the propellers rotate freely and that there are no signs of the propellers hitting any obstruction in the water.
Page 48
1N00-510 Genesis Boat User Manual v3 05/19 4.05 To remove from service 1. Follow the “Operating procedures – closing instructions”. 2. In all cases perform all weekly and monthly maintenance checks. 3. Perform the annual maintenance check if appropriate. 4. It is preferable to dismount the consoles for prolonged storage. If this is not possible t the console covers making sure that they will not be dislodged by wind.
Page 49
TOMS. This is true if you are going to fault nd yourself and even more important if you are going to telephone Tornado for assistance. In nine cases out of ten, give us concise and full symptoms and we will accurately diagnose the problem.
Page 50
If the good model reacts normally whilst the suspect model does not, the fault is in the model. Technical help is available from Tornado International Ltd. during our o ce hours. PLEASE HAVE AN ACCURATE AND COMPREHENSIVE LIST OF SYMPTOMS WHEN YOU CALL.
