- Page 1 OPERATION AND MAINTENANCE MANUAL MY5-EP0212L MY5-EP0319L MY5-EP0212LF MY5-EP0317LF MY5-EP0212P MY5-EP0319P MY5-EP0212PF MY5-EP0317PF Ver. 4.0 DC-TYPE Automatic Non-Carbon-Brush with Counter Series SAING EI CORP. https://www.mytorqtools.com. Y2F032Q-16E-001...
- Page 2 NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. is not responsible for customer modification of tools for applications on which was not consulted. SAING EI SAING EI WARNING Important safety information enclosed. Read all these instructions before placing tool in service or operation this tool and save these instructions.
-
Page 3: Important Safety Rules
Important Safety Rules WARNING! Read all instructions Failure to follow all instructions listed below may result in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 4 d) Store idle power tools out of reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. Do not let visitors touch the tool or extension cord. All visitors should be kept away from work area. e) Maintain power tools.
-
Page 5: Grounding Instructions
WARNING！ DO NOT OPERATE THIS TOOL WITHOUT PROTECTIVE EARTH CONNECTED Grounding Instructions 1、This tool should be grounded while in use to protect the operator from electric shock. NOTICE! To ensure the grounding result, the grounding conductor of the power cord must be well connected with the grounding terminal of power facility. This tool is equipped with grounding conductors. - Page 6 Operations Cautions 1) Before changing bits from MY5-EP Series screwdriver, make sure the Forward / Reverse switch stays at the “OFF “position The screwdriver must be unplugged. 2) To avoid damaging the housing of screwdriver, do not allow chemicals get in touch with housing of screwdriver. Ex.: Acetone, benzene, thinner, trichloroethylene ketone, and other similar chemicals.
-
Page 7: Description Of Operation
CAUTION ● Do not drop or abuse the tool. ● Whenever a tool is not being used, position the Power Switch to the “OFF” position and unplug the power cord. Description of Operation Attaching / detaching bit and bit type Push up the holder clamp by fingertip, and it will be unlocked. - Page 8 CAUTION 1. The use of other than genuine SAING EI replacement parts may Result in decreased tool performance and increased maintenance and may invalidate all warranties. 2. All repairs and maintenance of this tool and its word must be performed by an authorized service center. 3.
-
Page 9: Specifications
Specifications MODEL ( MY5-) EP0212L EP0319L EP0212P EP0319P EP0212LF EP0317LF EP0212PF EP0317PF Input voltage(DC) DC 24V OR 32V Power Consumption (kgf.cm) 1.5-12 3-19 2-12 3-19 1.5-12 3-17 2-12 3-17 Torque (Lbf.in) 1.33-10.44 2.57-16.46 1.77-10.44 2.57-16.46 1.33-10.44 2.57-14.78 1.77-10.44 2.57-14.78 (N.m) 0.15-1.18 0.29-1.86 0.2-1.18... -
Page 10: Panel Specifications
Panel Specifications Name Function Three-Color To Show operating is OK, N.G or in the mode condition. Light Panel To show set value, set screws number and other value Push five seconds: to disable COUNTING FUNCTION Power Switch CLEAR Push three seconds: CLEAR SELECT Key Push three seconds: Enter the system Up Key... - Page 11 ※SELECT (P+UP Enter into Menu) Sr Key Function Set up Time Factory default Description Buzz Time/ Light Name and Value settings OKALL display mode _Y: Small loop；N: Big loop Y or N ※Auto learning mode “Ln” (S+P Enter into Menu) SL=SC=At=RC=SP=Ht=P Key Function Set up Time Factory default...
- Page 12 ※MY5-EP PCB has three kinds of signal, OKALL、NG、OK and is an open collector type. ※Output users need input voltage to drive the buzzer, the input voltage can’t be over DC24V 10mA. ※There is a new judgment which is the screwdriver will judge a N.G.in the case of there is a start signal and it is OFF before Lt. ※If operator controls these functions from PLC close short circuit will take 500ms at least.
- Page 13 ※LED light flash in simulate-learning.( means under simulate- learning condition), push P key to record value after simulating -learning. ) ※Has no use of screwdrivers: UP and push P key can set up waiting time. If three seconds are set, but no starting signal after set time, it will buzz. ※Push R key to restore to factory settings.
- Page 14 Torque Adjustment Operation To adjust the torque on these screwdrivers. Proceed as follows : 1. Determine the torque output of the tool by checking a tightened Fastener with a torque wrench. 2. Increase or decrease the torque by rotating the Spring Adjusting Ring. Rotating the Ring clockwise to a higher number on the torque Scale increase torque output while rotating the Ring counterclockwise to a lower number decreases the torque output.
