Amplifier Input Connections
AMPLIFIER
CAR STEREO
(SOURCE UNIT)
Phase Switch
Remote/Power Antenna
Turn-On Wire
RCA Input
REQUIRED INSTALLATION
TOOLS:
Power Drill
Utility Knife
Adjustable Wrench
•
Crimpers
•
Screw Driver
For installation options go to mtx.com
Part #: NDM229
Advertisement
Related Manuals for MTX Thunder 1501D
Summary of Contents for MTX Thunder 1501D
- Page 1 Amplifier Input Connections AMPLIFIER CAR STEREO (SOURCE UNIT) Phase Switch Remote/Power Antenna Turn-On Wire RCA Input REQUIRED INSTALLATION TOOLS: Power Drill Utility Knife Adjustable Wrench • Crimpers • Screw Driver For installation options go to mtx.com Part #: NDM229...
- Page 2 Amplifier Output Connections AMPLIFIER Grommet Minimum Wire Size: Power: 1/0 AWG. Ground: 1/0 AWG. Disconnect Battery Negative (-) Cable Prior to Installing Amplifier For installation options go to mtx.com...
