Access & Power Integration
Altronix/Lenel-S2 (S2 Security Platform) Kits
Models Include:
T3SSK7528
28 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove3 enclosure with
TSS3 Altronix/Lenel-S2 (S2 Security Platform) backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) AL1012ULXB - Power Supply/Charger
- Three (3) ACM8 - Fused Access Power Controllers
- One (1) ACM4 - Fused Access Power Controller
- Two (2) PD16W - Fused Power Distribution Module
- One (1) RSB2* - Rocker Switch Bracket with
Two (2) Rocker Switches (Not evaluated by UL)
All components of this Trove kit are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. T3SSLK_110822
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T3SSK7528D
28 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove3 enclosure with
TSS3 Altronix/Lenel-S2 (S2 Security Platform) backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) AL1012ULXB - Power Supply/Charger
- Three (3) ACM8CB - PTC Access Power Controllers
- One (1) ACM4CB - PTC Access Power Controller
- Two (2) PD16WCB - PTC Power Distribution Module
- One (1) RSB2* - Rocker Switch Bracket with
Two (2) Rocker Switches (Not evaluated by UL)
