Summary of Contents for MOOKA BL-69
-
Page 6: Safety Precautions
10. Please use the original packaging foam or other anti-shock material when relocating the projector. 11. Please contact the MOOKA customer support team if you encounter any problem with the projector. 12. This mini projector is covered by the MOOKA 12-month warranty. -
Page 7: Remote Control
m support@mookashops.com REMOTE CONTROL 1. Power On/Off © 2. Pause/Play 3.Zoom 4.Mute 5.Flip 6. Up/ Down/ Left/ Right ® C• 7.Confirm ,c,t) a.Return 9. Menu 10.Source 11.VOL- 12.VOL+ Caution 1. Do not submerge the remote control in water. 2. Do not expose the remote control to the outdoors, liquid, moisture, excessive heat, or fire. -
Page 8: Projector Overview
support@mookashops.com PROJECTOR OVERVIEW @- -- - - - - · ON/OFF 'r:, ----- -· • - - - - - . U p / Dow n/ Left/ Rig h t Enter/Play/Pause ----- -· Menu Source HDMI Audio output USB1USB2 Keystone Power Supply Projection lens IR remote sensor -06-... - Page 9 support@mookashops.com 1. Connecting the projector to power a. Plug the power cord to the projector. (( ( ) )) b. The power indicator on the projector lights up after the power cord has been connected. -07 -...
- Page 10 support@mookashops.com 2. Power ON/OFF Press the "C)" button on the projector or on the remote control to power on. @-- ------ --· ON/OFF...
- Page 11 support@mookashops.com 3.Multimedia boot screen The multimedia screen will be displayed in 10-20 seconds after you press the power button. 4. Focus & keystone correction a. If the image is displayed as a trapezoid shape, turn the keystone correction knob on the upper back side of the projector until the projected image becomes rectangular to correct the keystoning issue.
- Page 12 � support@mookashops.com b. Make sure the projector is horizontal to the projector screen and rotate the focus ring to sharpen the projected image. lcr:r:::: KEYSTONE D11 1 1 1 1 11 1 111111 1 1 1 1 1 D FOCUS -10-...
-
Page 13: Optical Adjustments
m support@mookashops.com Optical adjustments The projector corrects the image deformation by the optical keystone correction. See the example below: However, this projector does not have a horizontal keystone correction function. The projector must be placed horizontally to the projection screen. If you encounter the problem as shown above, it is probably because the projector has not been placed horizontally to the projection screen, or the projection screen is not vertically positioned. - Page 14 � support@mookashops.com Connections o oo □□ ,-----------------------' i::::::: :::::-,. � a a ) __ : - · - \ ---------------- ----------------- ,,.. J � Type-c Lightning Micro USB,: ___________________ ___________________ , -12-...
- Page 15 m support@mookashops.com 1. Playing media files from a USB Drive a. Insert a USB storage device into a USB port. Q O O B c:::::i HDM I llS82 USB 1 b. Pick USB at the Signal Sources menu. Input Source HDMl1 Screen Mirroring 0 0K...
- Page 16 � support@mookashops.com Supported multimedia file formats and types Audio file MP3/WMA/OGG/ AAC/MA4/Fl.AC/ APE/WAV Picture file JPEG/BMP/PNG MPEGl. MPEG2, FLV. MPEG4, RM. AVI /RMVB, Multimedia Video file MOV, MKV, DIVX, FVOB M-JPEG (only unspported 640*480) Text file c. Choose the content you need to display: Video/ music/ photo/ text.
- Page 17 m support@mookashops.com 2. AV video connection Use a 3-in-1 AV cable to connect to the projector as shown below. Once connected, pick AV at the Signal Sources menu. Input Source HDMl1 Screen Mirroring �-- 9[J)Jml"-: �: Supports NTSC/PAL. ,---------------------- -15-...
- Page 18 m support@mookashops.com 3. HDMI connection Use the HDMI slot to connect computers and HDMI compatible devices. Once connected, pick HDMl1 at the Signal Sources menu. Input Source HDMl1 Screen Mirroring ---□ Ill, ... Supported resolutions: 576P,480P, 720P, 1080P,640x480,800x600, 1024x768, 1280x1024, 1280x720, 1440x900, 1366x768, 1920x1080, 1280x800, 1440x960,680x1050 -16-...
- Page 19 support@mookashops.com 4. 3.5mm audio connection Use a 3.5mm audio jack to connect headphones/speakers. Note: Dolby sound is not supported. -17-...
-
Page 20: Menu Settings
m support@mookashops.com Menu settings 1. Remote control user guide Press the" "key to enter the main menu, then press the '◄ / ►" key to enter each sub-menu. Press the·"' / key to select the sub-menu, then adjust the parameters as i..' required, and press the "OK"... - Page 21 support@mookashops.com b. Sound sub-menu: ■ ■ Available adjustments: Sound Mode/ Balance/ Auto Volume/ Volume/Bluetooth SOUN() Sound Moo,, S1anaar Balance Auto Volume Bluetooll Aulo Turn on/ off Bluetooth When the Bluetooth is turned on, search for nearby Bluetooth speakers or earphones to pair the device. Press the "OK"...
-
Page 22: Screen Mirroring
m support@mookashops.com e. Input Source sub-menu: Available adjustments: AV/HOM! 1/Screen Mirroring/VGA/USB Input Source HDM11 Screen Mirroring 001( Screen Mirroring 1. Select Screen Mirroring in the Input Source list 2. Press the OK key to enter the interface 3. Pick the appropriate variant (Figure 1) Figure 1 -20-... - Page 23 3. Launch the Multi-screen / Wireless Display/ Screen Mirroring / Smart View/ Cast function (Figure 1) 4. Select "M00KA-XXXX" (Figure 2) Cast MOOKA-**** Wireless<:isplay Figure 1 Figure 2 This projector supports the Miracast co-screen protocol; if you use Chromecast or other co-screen protocol devices.
- Page 25 2. Select iOS Screen Mirroring function; 3. Tum on Wi-Fi on your iOS device and search for the network name of the projector (for example MOOKA-FAE208); 4. Pick it and enter the password: 12345678. Your iOS device will connect to the projector automatically.
- Page 26 1. Turn on the projector, select Screen Mirroring as the input source to enter the Screen Mirroring interface for iOS; 2. Open the 'Settings', connect your iOS device to the "MOOKA-FAE208" Wi-Fi (pwd: 12345678); 3. Open the http:/ /192.168.49.1 webpage with the browser on your mobile device.
- Page 27 4. Your WiFi router will be displayed on the Screen Mirroring interface for iOS after a successful connection; 5. Open the 'Settings', connect your iOS device to the same WiFi router; 6. Turn on Screen Mirroring on your iOS device, find the projector (MOOKA-FAE208) for pairing. Projection screen mode setting 1.
- Page 28 m support@mookashops.com Method 4: Wired connection 1. Select iOS Screen Mirroring function; 2. Connect your iOS device to the projector OUT5V port via the original USB cable. 3. Confirm the screen mirroring: when the "Trust this Computer?" window appears, tap ''Turst" to start screen mirroring. Trust This Computer? Your settings and data will be accessible from this computer when...
-
Page 29: Projector Installation
m support@mookashops.com PROJECTOR INSTALLATION Installation Method The projector can be hanged on the ceiling with special hanger frame, and placed on the stable desk to project the image according to the operating environment and requirements. Check the below images to decide on the best location for the screen: 6�... -
Page 30: Technical Specifications
m support@mookashops.com 200" Throw distance and screen size For reference only. Throw distance and screen size may vary due to different configurations. Technical Specifications Color Imaging LTPS LCD 16.7kk Reproduction Technology Resolution 1920*1080 Keystone Manual Correction ± 15 • Highest Resolution 1920*1080 Power Voltage 100V-240V 50/60Hz...
