Installation INSTRUCTIONS
LED WASHER
LED WASHER MOOD LIGHTS
LHT0251 Horizontal
LHT0252 Vertical
Thank you for purchasing this SIMX LED Washer. This luminaire is suitable for sheltered outdoor use
and requires a 220V-240V AC power supply. Please read this manual thoroughly before installation
and retain for future reference.

TECHNICAL SPECIFICATIONS

Model LHT0251
Shape Horizontal
Luminous Flux 180 lm
Rated Load 3.5W
Power supply
LED type
Operating temp
Light Output
Classification
IP Rating
Impact Resistance
Construction

IMPORTANT

This product is suitable for use only with a supply voltage of 220-240V AC 50/60Hz.
All electrical work must be carried out in accordance with local and national electrical codes as
applicable. We strongly recommend that this light fitting is installed by a registered electrician.
Always switch power off prior to installation. A means of mains power isolation must be installed on the
circuit for the purpose of safe access for any internal cleaning, recalibration, or maintenance.
This light fitting is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety. Young children
should be supervised to ensure that they do not play with the appliance.
Any changes or modifications made or attempted to this product, without the prior written approval of
the manufacturer, will void any and all stated warranties.

BEFORE YOU START

This light fitting is rated to IP54 and suitable for permanent outdoor use in sheltered locations. Ensure the
desired location does not exceed this rating. Switch off the power supply before commencing electrical work.
We strongly recommend this light fitting is installed by a registered electrician.
LHT0252
Vertical
50 lm
1.0W
SMD3014, 4000K
-10°C to + 40°C
Non-dimmable
ABS + Polycarbonate UV stabilised, stainless steel screws
LHT0253 Square
LHT0254 Round
LHT0253 LHT0254
Square Round
80 lm 100 lm
1.6W 2.0W
220-240V AC
Class II
IP54
IK09
