SpeechWare FlexyMike FMK03 Connection Manual

Bluetooth transmitter under windows vista or windows 7
Hide thumbs Also See for FlexyMike FMK03:
1
2
3
4

Advertisement

Table of Contents

Connection of the FlexyMike Bluetooth Transmitter (FMK03)

1. BASIC OPERATING INSTRUCTIONS

Our models FMK03 (http://www.speechware.be/en/verArticulo.php?id=1671) --and FMK04-- feature a
couple of Light Emitting Diodes (LEDs), which lights up in Blue
the following meaning:
• • • •
B-LED
flashing twice quickly every 2 sec.: Power On and "Standby" (low consumption) mode
• • • •
B-LED
flashing once slowly every 2 sec.: "Link" (transmission) mode
• • • •
B-LED/R-LED
flashing alternatively: "Pairing" mode to establish a connection for the first time
• • • •
R-LED
flashes quickly (while using it): Low battery mode
• • • •
R-LED
lights on: Charging mode
• • • •
R-LED
flashes twice quickly and stops: Power Off mode.
2. INSTALLATION OF FULL DUPLEX BLUETOOTH TRANSMITTER (FMK03) UNDER
WINDOWS VISTA OR WINDOWS 7 (WITHOUT ANY THIRD PARTY SOFTWARE)
a) Put the FlexyMike Bluetooth Transmitter in "Pairing" mode (check above): press the On/Off
button for about 5 s. and until the
press the On/Off button, the Transmitter is Off.
b) Check for the Bluetooth icon of your Windows bar (in the bottom right hand corner of your screen):
If you cannot see it, then Bluetooth may be disabled. To enable it, select Start > Control Panel >
Wireless Assistant and press enable ("Allumer") Bluetooth in your computer:
under Windows Vista or Windows 7
(without any other third party software!)
B-LED/R-LED
(B-LED)
and Red
flash alternatively. Make sure that before you
(R-LED)
colour, with

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlexyMike FMK03 and is the answer not in the manual?

Questions and answers

Related Manuals for SpeechWare FlexyMike FMK03

Summary of Contents for SpeechWare FlexyMike FMK03

  • Page 1 Connection of the FlexyMike Bluetooth Transmitter (FMK03) under Windows Vista or Windows 7 (without any other third party software!) 1. BASIC OPERATING INSTRUCTIONS Our models FMK03 (http://www.speechware.be/en/verArticulo.php?id=1671) --and FMK04-- feature a couple of Light Emitting Diodes (LEDs), which lights up in Blue (B-LED) and Red...
  • Page 2 If you do not see a Bluetooth item in your Control Panel, it may need to be installed! c) Right-click on the aforementioned Bluetooth icon of your Windows bar, and select the option “Add peripheral” (“Ajouter un périphérique”): d) When the Bluetooth Transmitter (FMK03) is automatically detected by Windows Vista or 7, after a couple of minutes, it appears in this screen.
  • Page 3 f) Insert the pin number "1234" and press “Submit”: g) Click “Fermer” in the last window: Now, your FlexyMike Bluetooth microphone is ready to be used under Windows Vista or 7! 3. HOW TO CONNECT AGAIN THE FULL DUPLEX BLUETOOTH TRANSMITTER (FMK03) WHEN RESTARTING THE PC If you need to establish again the Bluetooth connection, after restarting the PC, follow the next steps: a) With the Bluetooth Transmitter switched On, right-click on the Bluetooth icon of Windows bar and...
  • Page 4 Double-click on the SpeechWare microphone icon: c) If there is no connection, in the next window, press “Connect” (“Connecter”) d) When the connexion is established again, the window will show it:...
