T9068TEELH/T1068TEEL1/
T1068TEEL3/T1068TEELH

Advertisement

loading
Need help?

Need help?

Do you have a question about the T9068TEELH and is the answer not in the manual?

Questions and answers

Summary of Contents for LG T9068TEELH

  • Page 1 T9068TEELH/T1068TEEL1/ T1068TEEL3/T1068TEELH...
  • Page 2: Using Smart Diagnosis

    Using Smart Diagnosis...
  • Page 3 FUZZY (NORMAL), QUICK Wash, STRONG (JEANS), GENTLE (WOOL/SAREE) EXTRA RINSE , AIR DRY, ECO WASH, TUB CLEAN, AQUA RESERVE...
  • Page 10 dentification of Parts Body POWDER WATER SUPPLY DETERGENT BOX HOSE Make sure the water does not MAGIC FILTER leak. Clean regularly to stop linting on the clothes load. POWER PLUG SOFTENER If the supply cord is INLET damaged, it must be BLEACH replaced by the DISPENSER...
  • Page 11 Use nylon nets for long, DELICATE items. For laundry with long strings or long length , a net will prevent tangling during washing. Fasten zippers, hook, and strings to make sure that these items don't snag on other clothes. Nylon net is not supplied by LG.
  • Page 12 se of Water, Detergent, Bleach and Softener Using Water Amount of WATER LEVEL • This machine detects the quantity of laundry automatically, then set the WATER LEVEL and proper amount of Detergent. • When you select a wash program, the WATER LEVEL will be shown on the control panel.
  • Page 13: Water Level And Amount Of Detergent

    Water Level and Amount of Detergent Concentrated detergent: 20g per 30 liters of water.  Water Amount Amount Level of Water of laundry  Regular synthetic detergent: 30g per 30 liters of water. 82 l Less than When sensing water levels automatically, the amount of ...
  • Page 15 pecial Guide for Stain Removal WARNING Do not use or mix liquid chlorine bleach with other household chemicals such as toilet cleaners, rust removers, acid or products containing ammonia. These mixtures can produce dangerous fumes which can cause serious injury or death. To reduce the risk of fire or serious injury to persons or property, comply with the basic warnings listed below: Read and comply with all instructions on stain removal products.
  • Page 16 Use this feature based on soil/dirt level of the cloth. Select Soil Level for low, medium or high soil/dirt level respectively. • This feature cannot be selected for courses : Tub Clean, Wool, Air Dry. • This feature cannot be selected when only spin option is selected.
  • Page 17: Smart Diagnosis

    SMART DIAGNOSIS Function Display It marks the place to put the phone to receive signal when a problem occurs. (refer to page 38) follows : (refer to page 27) Program 1 : Normal ▶Gentle (Wool/Saree) ▶Quick Wash ▶ Strong (Jeans) ▶Normal. Program 2 : Pre Wash Normal▶...
  • Page 18 Use this program for washing normal clothes, this mode automatically selects the most appropriate conditions and completes the sequence in one operation. The built-in sensor detects the size of the load and ideal wash power & wash, rinse and spin times are set accordingly.
  • Page 19 Changes to water Temperature (HOT/COLD) and water level are possible during operation. (refer to page 18) prevent damage to laundry. It should always be high. Changes to water Temperature (HOT/COLD) and water level are possible during operation. (refer to page 18)
  • Page 20 Use this mode to wash normal clothes or thick and heavy clothes which are excessvely dirty. SOAK mode can be used with NORMAL or STRONG (JEANS) or AQUA RESERVE or ECO WASH or EXTRA Rinse program. SOAK will not work in GENTLE (WOOL/SAREE) and QUICK WASH, TUB CLEAN Program.
  • Page 21 CO Wash Use this program to save water consumption. Select the PROGRAM button to select ECO WASH program Add the laundry into the washing tub. Add the detergent & close the lid. ECO Wash is recommended program designed to minimize water consumption for normally soiled clothing. For water saving we recommend to use 5 to 8 Water level.
  • Page 22 irritant odour. damage to the tub. time, as it may rust the tub. Use this program once in every month.
  • Page 23 Press the POWER button to turn power on. Press Spin for 3 seconds to select Air Dry. Other function cannot be selected during Air Dry. Automatically set to 30 minutes upon selection. Press Spin button again to select duration (1hr 1:30hr 2hr 30min) To deselect Air Dry press power button.
  • Page 24 • Press the WASH button to • Press the RINSE button to When you want to only select the desired timing. select the desired no. of drain, press SPIN button. rinse cycles. • Press the RINSE button to Then press START/PAUSE select the desired no.
  • Page 25 DELAY START (RESERVATION) Wash is used to delay the nishing time of the operation. The hours to be delayed can be set by the user accordingly. The time on the display is the nishing time, not the start time. Select the program for laundry on the Control panel. This program will not work in GENTLE (WOOL/SAREE) and TUB CLEAN Program.
  • Page 26: How To Unlock

    Press and hold Rinse Button for 3 seconds. • The child lock is set, it will not be released automatically even if the cycle is terminated. • Thus, you should turn power on washing machine and then terminate the function by pushing "Rinse” button for 3 seconds.
  • Page 27: Wiring Diagram

    4. SERVICE INFORMATION 4-1. WIRING DIAGRAM WIRING DIAGRAM Model T9068TEELH T1068TEEL1 T1068TEEL3/ 1 1 2 1 2 3 4 5 6 6 5 4 3 1 2 4 1 2 3 T1068TEELH BL BK OR WH VL Capacity 8.0kg 9.0kg 9.0kg...
  • Page 29 4-4.
  • Page 35 P/N : EBR80600401...
  • Page 36 4-7-1 Inlet valve Error (IE) Symptom Check Point INLET VALVE ERROR 1.Check Electric Wiring. 2.Check Inlet valve’s Resistance. (IE) 3.Check Inlet valve clogged. 4. Voltage of the inlet valve’s connector. -. Valve running : 12Vdc ± 5% Jet Spray Hot valve Cold Valve Wiring Diagram Resistance...
  • Page 37 V DC Air Dry and Program button As per spec. (Refer previous page)
  • Page 38 4-7-2 Drain Error (OE) Symptom Check Point Drain Error 1.Is the Drain Hose Located properly? 2. Drain Hose is not lowered? (OE) 3. Drain Hose is folded or clogged due to freeze or dirts. 4. Bad drain motor part or White (WH5) 5&4 pin connected properly. Drain Motor Wiring Diagram Resistance...
  • Page 39 Put the hose Is the drain hose locate lower at gro d properly? und drain po Unclog and Drain hose is not folde clean drain d or clogged due to fre hose eze or dirt? Fix connect Drain motor connection ors properly.
  • Page 40: Pressure Sensor Error

    4-7-3 Pressure Sensor Error (PE) Symptom Check Point PRESSURE SENSOR 1.Check Electric Wiring. 2.Check Pressure sensor‘s Resistance. ERROR 3.Check Air chamber and Tube clogged. (PE) Pressure Sensor Wiring Diagram Resistance Pressure Main PWB [Ω] Sensor 21 ~ 23 BL4 (1 (1) (2) (4) ~4th ) (±...
  • Page 42 4-7-4 Unbalance Error (UE) Symptom Check Point Unbalance Error 1.Check Laundry in Inner tub is evenly distributed. 2. Check Machine is not tilted on floor. (UE) Try to fill laundr Is laundry in the inner t y uniformly in t ub filled evenly? he inner tub.
  • Page 43 4-7-5 Door Open Error (DE) Symptom Check Point Door Open Error 1.Check Laundry in Inner tub is evenly distributed. 2. Check Machine is not tilted on floor. (DE) Is Lid closed during inter Close the lid mittent spin or normal sp Is Lid closed while proc Closed the li essing reservation?
  • Page 44 4-7-6 Over Flow Error (FE) Symptom Check Point Over Flow Error 1. Check Inlet Valve for continuous water input without electrical power. (FE) 4-8-7 Auto Off Error (AE) Symptom Check Point Auto Off Error Problem is due to Auto off Relay is not working properly 2.
  • Page 58 A020 A030 A040 A010 A050 A051 A140 A110 A060 A166 A170 A168 A167 A169 A130 A001 A160 A163 A162 A161 A164 A150...
  • Page 59 F053 F052 F030 F050 F001 F051 F000 F008 F014 F013 F040 F014 F020...
  • Page 60 K000 K060 K012 K011 K021 K090 K030 K130 K040 K070 K022 K140 K071 K150 K200 K170 K053 K220 K160 K180 K210 K100 K181 K110 K120...
