OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions carefully.
This will simplify installation and ensure that the product is
installed correctly and safely. Leave these instructions near the
product after installation for future reference.
EN ENGLISH
T8585NDKVH
MFL70761333
Rev.01_011620
T9069NDKV
Copyright © 2019-2020 LG Electronics Inc. All Rights Reserved
www.lg.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LG T8585NDKVH
Summary of Contents for LG T8585NDKVH
- Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. EN ENGLISH T8585NDKVH T9069NDKV www.lg.com MFL70761333 Rev.01_011620 Copyright © 2019-2020 LG Electronics Inc. All Rights Reserved...
-
Page 2: Table Of Contents
TABLE OF CONTENTS This manual may contain images or content that may be different from the model you purchased. This manual is subject to revision by the manufacturer. SAFETY INSTRUCTIONS ..............3 IMPORTANT SAFETY INSTRUCTIONS ............3 INSTALLATION ................8 Parts and Specifications..................8 Installation Place Requirements................9 Connecting the Water Inlet Hose ..............10 Installing the Drain Hose ................. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk. - Page 4 - Areas for communal use in blocks of flats or in launderettes • The inlet water pressure must be between 30 and 800 kPa. • The maximum capacity in some cycles for dry clothes to be washed T9069NDKV T8585NDKVH 9 kg 8 kg Installation •...
- Page 5 • Do not modify the power plug provided with the appliance. If it does not fit the power outlet, have a proper outlet installed by a qualified electrician. • This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.
- Page 6 • Make sure that drainage is working properly. If water is not drained properly, your floor may get flooded. • If, during spinning, opening the door does not stop the drum within about 10 seconds, immediately discontinue operating the appliance and contact your dealer or LG Electronics service centre.
- Page 7 • Never unplug the appliance by pulling on the power cable. Always grip the power plug firmly and pull straight out from the outlet socket. • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
-
Page 8: Installation
INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View Accessories * This feature is only available on some models. * This feature is only available on some models. Cold Water Inlet Hose Drain Hose Tie Strap*... -
Page 9: Installation Place Requirements
Specifications Model T8585NDKVH T9069NDKV Power Supply 230 V~, 50 Hz Dimension 540 mm X 540 mm X 850 mm (Width X Depth X Height) Product Weight Approx. 30 kg Installation Place WARNING Requirements • This appliance must only be used for domestic... -
Page 10: Connecting The Water Inlet Hose
Screw the hose connector onto the water supply by inexperienced persons may cause injury tap. or serious malfunctioning. Contact the LG Electronics service centre. • The power plug must be plugged into an appropriate outlet socket that is installed and grounded/earthed in accordance with all local codes and ordinances. -
Page 11: Installing The Drain Hose
NOTE • After completing connection, if water leaks from the hose, repeat the same steps. Use the most conventional type of tap for the water supply. In case that the tap is square or too big, remove the guide plate before inserting the tap into the adaptor. -
Page 12: Levelling The Appliance
• The outlet of the drain hose should not be • Turn the adjustable feet clockwise to raise submerged in water. or turn the adjustable feet counterclockwise to lower from front-to-back, side-to-side and corner-to-corner. • Make sure the drain hose is not kinked. NOTE •... -
Page 13: Operation
OPERATION Operation Overview NOTE • The Auto Restart function allows the cycle to restart by itself in case of power failure. It Using the Appliance resumes from the stage where it stopped. Before the first wash, select the Normal programme and add a half amount of detergent. Preparing Laundry Start the appliance without laundry. - Page 14 Checking the Fabric Care Label • Wash delicates (stockings, underwired bras) in a wash net. This will tell you about the fabric content of your • Close zippers, hooks and strings to make sure clothes and how it should be washed. that these items do not snag other clothes.
-
Page 15: Adding Detergents, Softeners And Bleaches
Adding Detergents, CAUTION Softeners and Bleaches • Using liquid detergent without diluting, or leaving laundry for a long time after pouring diluted liquid detergent into the drum might Detergent Dosage cause the clothes to be damaged, bleached, discoloured. • Detergent should be selected according to fabric type, colour, soil level and washing temperature and should be used according to NOTE... - Page 16 Adding Fabric Softeners Adding Liquid Bleaches • Softener should be used according to the • Before starting the appliance, pour the softener manufacturer’s instructions. measured amount of bleach directly into the bleach dispenser a. Avoid splashing or • Pour the measured amount of fabric softener overfilling.
-
Page 17: Control Panel
Control Panel Control Panel Features POWER Button • Press the POWER button to turn on or off the appliance. • The appliance automatically turns off once a certain time has passed after the wash has completed. START/PAUSE Button • Press the START/PAUSE button to start or pause a wash cycle. •... -
Page 18: Washing Programme
• The display shows the settings, remaining estimated time, options, and status messages. When the appliance is turned on, the default settings in the display will light up. : When a programme is selected, the default time for that programme is displayed. The time can •... -
Page 19: Extra Options And Functions
Quick Wash • Put bedclothes into a laundry net and then soak and sink them in water so that they are Use this programme to wash lightly soiled clothes less likely to float. If the items float during the for a short time. wash or spin, it may damage the appliance and the clothes. - Page 20 NOTE • When water level is automatically detected, it may differ depending on the amount of laundry • Once this function is set, all buttons are locked even though the same water level is indicated except the POWER button. on the control panel. •...
-
Page 21: Smart Functions
• If the data transfer is poor due to poor call Use this function if you need an accurate diagnosis quality, you may not receive the best diagnosis by an LG Electronics customer information centre service. when the appliance malfunctions or fails. Use this function only to contact the service representative, not during normal operation. -
Page 22: Maintenance
MAINTENANCE Cleaning the Appliance WARNING Periodically • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, Tub Clean electric shock, or death. This function is a special to help to clean the inside •... - Page 23 Cleaning the Water Inlet Filter • If the mesh hole of the lint filter is clogged, foreign objects in the laundry may not be Water inlet filter collects lime or any small objects filtered. that may be in water supplied to the appliance. •...
-
Page 24: Troubleshooting
You can remedy most of the problems by yourself, consequently save time and money, since you do not need to call LG Electronics service centre. The following table should assist you by troubleshooting. - Page 25 Symptoms Possible Cause & Solution Water overfills due to the faulty water valve. • Close the water taps, unplug the appliance, and call for service. OVERFLOW ERROR The water level sensor is not working correctly. PRESSURE SENSOR • Close the water taps, unplug the appliance, and call for service. ERROR A motor error has occurred.
- Page 26 Memo...
- Page 27 Memo...
