- Page 1 LG Code Zero SVC Manual Caution : Please read the safety cautions of this booklet before checking theproduct. Buyer Model Name : A9****** Factory Model Name : VS97****** P.No MFL68043138...
-
Page 2: Table Of Contents
Content ■ Product features ......................3 ■ Parts and names ......................4-5 ■ Cleaner features .......................6 ■ Check these out before use ..................7 ■ Cautions for general usage ................8-12 ■ Technical descriptions of parts ................13 ■ How to use ......................14-20 ■... -
Page 3: Product Features
Rechargeable Lithium Battery Rated DC 25.55 V , 1900 mAh Number of 7 ea. battery cells LG Chem (Battery pack manufactured by Peopleworks) Manufactured LG Chem (Battery pack manufactured by TWS TECHNOLOGY (GUANGZHOU) LIMITED) 1) The result is average of suction power with ASTM-F558 standard tested by individual test lab. Individually measured data would be differ- ent with the test result. -
Page 4: Parts And Names
Parts and names Standing type Wall-mount type 1 Product body 5 Charging station pipe 9 Adaptor 2 Extension pipe 6 Combination tool and crevice tool 10 Battery holder 3 Multi-surface Power Drive Nozzle® 7 Detachable stand for nozzle and 4 Charging station mop pads 8 Charging station support Body parts... - Page 5 Parts and names Please note that these parts come with their corresponding models only. • Hard Dirt Tool Mattress Tool Flexible CreviceTool Multi Angle Tool Flexible Hose Extension Battery Hard Floor Power Drive Bedding Power Punch Mop Nozzle Accessory bag Nozzle®...
-
Page 6: Cleaner Features
Cleaner features 1. T he product boasts of powerful suction that can be adjusted per purpose and site. The integrated inverter motor ensures consistent suction and you can adjust the suction strength depending on where you are cleaning. 2. A nti tangle power nozzle For cleaning ultrafine particles 3. D ual lithium batteries Two long-life dual lithium batteries eliminates the need for chargingin the middle of cleaning. -
Page 7: Check These Out Before Use
Environmental conditions such as temperature and humidity • may cause static to accumulate on the product. Please contact the customer service department of LG Electronics if the problem persists. Any foreign object on the inlet port or extension pipe will •... -
Page 8: Cautions For General Usage
2. Children should be supervised to ensure that they do not play with the ap- pliance. 3. If the supply cord is damaged, it must be replaced by an LG Electronics Ser- vice Agent in order to avoid a potential hazard. - Page 9 Stop using the product and contact the customer ser- • If the Station mounting is performed on an unsuitable vice department of LG Electronics if the power cord wall it may cause injury and damage the property or prod- or power plug is damaged or the holes of the power outlet socket are loose.
- Page 10 • It may result in product malfunction or fire. No one other than a qualified technician/service en- gineer from LG Electronics may disassemble, repair or Do not attempt to clean up a liquid substance (water, modify the product. beverage), odorous substances (candy, chocolate, pet excrement, etc.), metallic objects (such as blade,...
- Page 11 LG Electronics. • Failure to do so may cause electric shock or fire. Do not wash the dust bin with water.
- Page 12 Cautions for general usage CAUTION Proper usage Do not apply impact to the product or drop it from a Do not clean the same spot repeatedly for an height. extended period of time. • It may damage the product and/or result in injury. •...
-
Page 13: Technical Descriptions Of Parts
Technical descriptions of parts Model Item S97********* Category Integrated motor Power DC 25.55V Power consumption 400 W (MAX : 450 W) R. P. M 115000 R.P.M Lifecycle More than 205 hours -13-... -
Page 14: How To Use
How to use Installing the floor standing Put the anchoring block on the back of the charging station and anchor the charging station with the charging station screw. Make sure to fully tighten the screw. • Place the charging station support on the floor and Wall anchoring block assemble the charging station pipe, the Detachable stand for nozzle and mop pads and the charging... - Page 15 How to use Installing the wall-mount station CAUTION Avoid dropping the product and parts when taking them • Connect the power adapter to the port on the back of out of the package. It may damage the product and/or the charging station and plug the power cord into the cause personal injury.
- Page 16 How to use Storage of the combination tool and Storage of the Mop Nozzle crevice tool Storing mop nozzles on the Detachable stand for nozzle and mop pads helps in finding and using the mop nozzle. Keep the combination tool and crevice tool on the charging Mount the mop nozzle to the nozzle cradle.
- Page 17 Environmental conditions such as temperature and • humidity may cause static to accumulate on the product. Please contact the customer service department of LG Electronics if the problem persists. Any foreign object on the inlet port or extension pipe will •...
- Page 18 How to use Charging the Product Insert the battery into the auxiliary charging station. Put the product on the charging station. The battery indicator will start to flash and charging • will proceed in 3 steps. Charging indicator of the auxiliary battery Please note Make sure that the power adapter is connected to both...
- Page 19 How to use Using the nozzles Crevice Tool It is suitable for cleaning dust in a corner or a narrow Please note that the following applies to the • space. corresponding models: The nozzle can be attached to the product body or •...
- Page 20 How to use Flexible Crevice Tool Multi Angle Tool Since its length can be adjusted and it can be bent, it is Since it can be adjusted to various angles and the brush is used for cleaning dust inside the vehicle or narrow spaces in soft, it is used to clean the console in the vehicle or on top furniture where bending is necessary.
- Page 21 How to use Mop Nozzle How to install the mop Wet the mop pad with water before use. It is suitable for cleaning dust and mop cleaning at the same time. Please note The mop pads will only rotate at one speed regardless of what power setting the Vacuum is set to.
- Page 22 How to use For dry mop cleaning Please note When using a mop, clean using straight lines and diagonal • Empty the water in the water tank. lines. Attach the dry mop pad to the mop attachment plate at the bottom of the mop nozzle. Set the Water Adjustment button to STOP.
- Page 23 How to use Cleaning the the Dustbin WARNING Never wash the product's body with water. Water may • Remove the battery from the unit before cleaning the reach the motor and cause electric shock or fire. dustbin. Do not apply force or any impact to the dust bin parts or •...
- Page 24 How to use Clean the exhaust filter by brushing the dust off or by WARNING washing it in running water. Never wash the product's body with water as it may reach • To maintain cleaning performance, remove the dust • the motor and result in electric shock or fire.
- Page 25 How to use Cleaning the Power Drive Floor/ CAUTION Carpet Nozzle Avoid getting your finger stuck in any gaps when • reassembling. Please clean the floor and carpet nozzles as follows: Do not wash the rotating brush and the nozzle with water. •...
- Page 26 How to use Cleaning of the Mop Nozzle Drying the water tank Open the 2 caps on the side of the water tank and shake Clean the mop nozzle as below. the water tank to remove the remaining water. Separate the nozzle from the product and turn the Drying thoroughly for over 24 hours in a well-ventilated nozzle over.
-
Page 27: Disassembly, Assembly And Repairing Of Main Parts
Disassembly, assembly and repairing of main parts Cautions for disassembling ▶ Make sure to remove the batteries before disassembling the product. 1. Most parts are screwed in or inserted mutually. Please refer to theexploded diagram to disassemble the product in the correctsequence. 2. - Page 28 Disassembly, assembly and repairing of main parts 2. Replacing main PCB (2) Remove the button with (3) Disassemble Screw in the (1) Disassemble the handy a knife or a sharp object. button. part from the product Use a thick pieceof paper body.
- Page 29 Disassembly, assembly and repairing of main parts 3. How to replace motor assembly (1) Disassemble the deco- (3) Remove the screws on the (2) Pull the pipe part with a hand. bottom of the pipe. ration part with a flat headed screwdriver.
- Page 30 Disassembly, assembly and repairing of main parts 4. Disassembling the inlet roller(floor inlet) (2) Push the left bump up (3) Use a long phillips (1) Remove the inlet lever and remove the roller to screwdriver to remove the with a coin. the left.
- Page 31 Disassembly, assembly and repairing of main parts 5. How to disassemble the inlet motor(floor inlet) (2) Remove the cover of the (3) Remove 4 screws in the (1) Disassemble the inlet right bump with a hand. red circle. roller (Refer to how to disassemble the in- letroller in details) (4) Remove the cover below...
- Page 32 Disassembly, assembly and repairing of main parts 6. Remove the PCB of Mop Nozzle (1) Remove 4 screws after detach (2) Remove 12 screws (3) Remove the top cover the mop Pads Screw (Left side) : • Counterclockwise Screw (Right side) : Clockwise •...
- Page 33 Disassembly, assembly and repairing of main parts 7.How to disassemble the pump (mop nozzle) (1) Disassemble the mop nozzle. (3) Remove the pump connected (2) Remove the harness to the tube. connectors connected to the Replace the pump. pump (4) Reassemble in the reverse sequence -33-...
- Page 34 Disassembly, assembly and repairing of main parts 8.How to assemble the mop nozzle (1) Assemble the harness (2) Attach the tape(30mm) to the connectors to PCB of motor . suction pipe. (check the red box) (3) Turn the suction pipe to the (4) Assemble the cover after (5) Be careful not to scratch.
- Page 35 Disassembly, assembly and repairing of main parts 9. Removing charging station PCB (2) Remove the screw from (3) Remove the base cover (1) Loosen the 3 screws the groove in the red circle. after removing the screw. from the base. (4) Inside of the charging (5) Remove the terminals of (6) Remove the bump inside...
- Page 36 Disassembly, assembly and repairing of main parts 10. Disassembling handy decoration assay (2) Apply the same method (3) Hold and pull the (1) Use a flat headed to other parts to open the decoration assay with a screwdriver to insert hand.
-
Page 37: Cautions And What To Check For Repairing
Cautions and what to check for repairing 1. Make sure to remove the batteries first and unplug the chargingstation when checking or repairing the product. 2. Make sure that no metallic object gets in contact with the chargingterminal when checking the current of the circuit. 3. -
Page 38: Circuit Diagram
Circuit diagram • Station PCB -38-... - Page 39 Circuit diagram Main PCB ( Mop Nozzle ) • Motor PCB ( Mop Nozzle) • -39-...
- Page 40 Circuit diagram • Main PCB(Power) -40-...
- Page 41 Circuit diagram • Micom -41-...
- Page 42 Circuit diagram • Inverter -42-...
-
Page 43: Symptoms Of Malfunctions And Measures
Symptoms of malfunctions and measures Symptoms of Inspection result Cause Measures malfunction Pressing the Product is Make sure Bad connection Pressing the power button malfunctioning that all parts power button does not start are connected Product is not does not start the motor of the correctly. - Page 44 Symptoms of malfunctions and measures Symptoms of Inspection Cause Measures malfunction Remove the foreign object. Impeller has a foreign object on it. Rotation is slow. Battery charges too slowly. Charge the battery. Set the suction button at Suction button is set at Suction is too "Turbo"...
-
Page 45: Cleaning Functions And Error Modes
Cleaning functions and error modes Symptoms Causes How to check Measures No power engaged Main PCB is defective. Check if the main PCB has 5V Replace the main PCB. (Pressing the power button and 12V power. Replace the battery if the does not lead to anyfunction) Check if the battery has charging station has no Battery is defective. -
Page 46: Exploded Diagram
Exploded diagram A9****** ◎ Flufy Nozzle Assembly AGB01 MCK001 MCK6101 MCR401 AHR701 AEM747 AGM001 EAU301 MCR501 -46-... - Page 47 Exploded diagram A9****** ◎ Mop Nozzle (Nozzle Assembly, Mop) AGB404 AJL002 MBL801 AGM901 ACQ101 ABA401 MGQ001 ABA501 EBR601 AAN001 MFV701 MFV801 AGU901 MEA101 FAB601 FAB602 -47-...
- Page 48 Exploded diagram A9****** ◎ Handle Assembly ADQ901 ACQ401 ADQ001 EBR101 EBZ501 MEA201 ABQ401 MCR601 EAU703 MBG101 MGJ101 MEK701 AED601 MGE801 MCK201 ACW201 MEZ108 MCK101 ABN001 AGU501 ADV701 MCR801 MJM801 MFC801 -48-...
- Page 49 Exploded diagram A9****** ◎ Base Assembly Body EBR801 AAN701 -49-...
- Page 50 Exploded diagram A9****** ◎ Base Assembly, Lower AAN801 -50-...
- Page 51 Exploded diagram A9****** ◎ Accessories AEJ701 ABC901 AGB401 ABCAD1 ABCAD3 AGBNU1 ABCAD2 AEMAC1 MEG001 MEG101 AEJ501 AGF401 AAA201 AAA202 AAA601 -51-...
- Page 52 Exploded diagram A9****** EAC201 EBZ001 EAY401 AGR201 AGR301 -52-...
- Page 53 Exploded diagram A9****** ◎ Power Punch Nozzle AGB403 -53-...
- Page 54 Exploded diagram A9****** ◎ Carpet Nozzle AGB402 AHR702 AGM002 EAD902 -54-...
- Page 55 Exploded diagram A9****** ◎ Power Drive Mini Nozzle AGB405 -55-...
