URRACO 75 D ERVICE GUIDELINES 1.7.-1 General General maintenance schedules must be observed, otherwise, our warranty for your shredder will cease to apply. The first maintenance and any necessary repairs may only be executed by our service staff. Please refrain from executing any maintenance repair work yourself or assigning any third parties with such works, since otherwise our warranty will cease to apply.
Page 4
Thanks to their special training, the staff of LINDNER GmbH are able to provide first class technical assistance as well as all maintenance services and spare parts which you require.
URRACO 75 D ERVICE GUIDELINES 1.7.-2 Important Advice for Welding Work Before any welding work is carried out, the earth switch must be set to "off" and all electronic parts and components (remote control system, engine electronics) must be disconnected from the power supply). Turning out the battery disconnecting switch does not provide sufficient safety.
Page 6
URRACO 75 D ERVICE GUIDELINES Battery disconnecting switch Plug of the electronic engine control (ECM) LINDNER Service hotline: Managing director Mobile Shredder GmbH +49 (0) 36920 - 7269 - 600 Manuel Lindner Gerhard Buhl Industriestrasse 1A service@l-ms.de Walter Geiger D-99820 Hörselberg / Eisenach...
URRACO 75 D ERVICE GUIDELINES 1.7.-3 Filling Liquids Total filling capacity including filters as required Changing interval Fuel approx. 450 litres Diesel oil according to DIN 51601 as required Coolant1 approx. 55 litres coolant mix of distilled water and every 3000 hours...
Page 8
URRACO 75 D ERVICE GUIDELINES Engine oil 32 litres Select the lubricant viscosity according to the every 250 hours or ambient temperature: every 6 months ATTENTION: Required oil viscosity Mandatory! Diesel engine Ambient temperature After 100 – 200 multigrade oil min.
Page 9
URRACO 75 D ERVICE GUIDELINES Hydraulic approx. 120 litres Hydraulic oil according to DIN 51524 every 500 to 1000 part 2, select the viscosity class from the hours diagram according to the climatic or twice yearly conditions Purity class 18/13 according to ISO 4406 or better.
URRACO 75 D ERVICE GUIDELINES The oil change intervals for the gear and hydraulic oil can be extended subject to written approval of our Service Department if the results of an oil analysis (laboratory report) have been submitted. You can have the oil analysis...
Page 11
URRACO 75 D ERVICE GUIDELINES Filter Hydraulic Conveyor Cooler Gearbox Others elements system belt Daily Daily Daily Daily Daily Daily maintenance maintenance maintenance maintenance maintenance maintenance tasks to be tasks to be tasks to be tasks to be tasks to be...
Page 12
URRACO 75 D ERVICE GUIDELINES Filter Hydraulic Conveyor Cooler Gearbox Others elements system belt Daily Daily Daily Daily Daily Daily maintenance maintenance maintenance maintenance maintenance maintenance tasks to be tasks to be tasks to be tasks to be tasks to be...
URRACO 75 D ERVICE GUIDELINES 1.7.-5 Maintenance Intervals When servicing the drive engine, observe the separately enclosed operating and maintenance manual of the engine manufacturer! All maintenance work may only be executed by trained and instructed personnel. Before carrying out servicing work, you must always read the safety instructions.
Page 14
URRACO 75 D ERVICE GUIDELINES Filter Hydraulic Conveyor Cooler Gearbox Others elements system belt Check and Check oil Visual Check Check oil Check clean the level and check for coolant level and engine oil main air refill if damage level and...
Page 15
URRACO 75 D ERVICE GUIDELINES Filter Hydraulic Conveyor Cooler Gearbox Others elements system belt Check the Check oil Change oil Engine main air and filters of the main mainten- filter gearbox ance (in element accordanc and clean if e with the...
Page 16
URRACO 75 D ERVICE GUIDELINES Filter Hydraulic Conveyor Cooler Gearbox Others elements system belt Replace Check Check belt Change oil Functional suction preset tension of the main test of all filter. pressure and adjust gearbox safety settings. devices Replace necessary.
Page 17
URRACO 75 D ERVICE GUIDELINES Filter Hydraulic Conveyor Cooler Gearbox Others elements system belt Replace the main air filter element Filter Hydraulic Conveyor Cooler Gearbox Others elements system belt Check and clean the cooling system and change the coolant Filter...
URRACO 75 D ERVICE GUIDELINES 1.7.-6 Inspecting / Changing the Hydraulic Oil Filters A suction/return filter and a suction filter are installed in the shredder. The filter cartridges have to be replaced when the <Oil filter> indicator light lights up or at least every 500 operating hours.
URRACO 75 D ERVICE GUIDELINES Suction filter To replace the suction filter, proceed as follows: 1. Have the new filter(s) to hand. Filter cartridge type: see Appendix "Modules and spare parts". 2. Unscrew the old filters from the filter head.
URRACO 75 D ERVICE GUIDELINES 1.7.-8 Checking the Hydraulic Oil Level / Changing the Hydraulic Oil Maximum oil filling is only permissible with retracted hydraulic cylinders. Checking the oil level If the oil drops below the minimum level, the <Hydraulic oil level> indicator light lights up on the control panel.
Page 21
URRACO 75 D ERVICE GUIDELINES Changing the hydraulic oil Change the oil while the plant is at operating temperature (not later than 15 minutes after switching off the shredder). The hydraulic filter should be replaced when changing the hydraulic oil.
Page 22
URRACO 75 D ERVICE GUIDELINES Pump new oil into the hydraulic circuit using the hand-operated pump until hydraulic oil comes out of the measuring connection opening on the oil cooler and of the suction/return filter vent valve. Screw the measuring connection to the oil cooler and close the vent valve on the suction/return filter.
URRACO 75 D ERVICE GUIDELINES Never fill the hydraulic system directly via the cap of the hydraulic tank. Always use the upper hydraulic pipe for this purpose. Filling via the tank allows air to enter the hydraulic system which will cause damage to the components.
URRACO 75 D ERVICE GUIDELINES Oil drain plug Sight glass 1.7.-10 Checking / Changing Engine Oil and Filter Change the oil while the plant is at operating temperature (not later than 15 minutes after switching the shredder off ) Checking the engine oil level and changing the engine oil and the engine oil filter is to be performed in accordance with the drive engine operating and maintenance manual (enclosed separately).
URRACO 75 D ERVICE GUIDELINES 1.7.-11 Checking the Coolant Level / Changing the Coolant Only check the coolant level with the engine switched off and when engine and cooler are cold. At operating temperature, the coolant is hot and under pressure.
URRACO 75 D ERVICE GUIDELINES For draining the coolant, use the drain plug on the right hand engine side of the shredder. The coolant is pumped out by means of the hand-operated pump. Proceed as follows: Remove the protective cap form the drain socket.
Page 27
URRACO 75 D ERVICE GUIDELINES Procedure: Notes: (If only the main element is being changed, ignore points 3, 5 and 6) Loosen the snap locks and lift off the cap. Take out the main element Take out the safety element...
URRACO 75 D ERVICE GUIDELINES 1.7.-13 Maintaining the Water Sprinkler Filter (Option) A water sprinkler is installed in the shredder to bind the dust produced during shredding. The water filter is equipped with a pipe connection. The water jet pressure can be set using the hand wheel for setting the holding pressure. We recommend a pressure of between 2 and 3 bar for optimal sprinkling of the material to be shredded.
Page 29
URRACO 75 D ERVICE GUIDELINES Cleaning the water filter: The water filter sieve is to be cleaned by backwashing. It should be cleaned every two months (or at shorter intervals in case of heavy soiling). Procedure: 1. For backwashing, turn the rotating basket fully to the left.
URRACO 75 D ERVICE GUIDELINES 1.7.-14 Adjusting the Belt Tensioning and Alignment Do not tension or align the discharge conveyor belt unless it is switched off. Any adjustment work performed while the conveyor belt is running involves danger of death! Wear work gloves when carrying out repair work to reduce the risk of injuries.
Page 31
URRACO 75 D ERVICE GUIDELINES For tensioning, use the tensioning bolts located in the upper part of the conveyor belt. The conveyor belt must neither be too tight nor too loose. Please ensure that the axles of the belt are always running parallel, i.e. the...
Page 32
URRACO 75 D ERVICE GUIDELINES Adjusting the belt alignment The belt alignment is adjusted using the set screw on the return strand roller above the bending point. Before adjusting the belt alignment, check the belt tensioning and make sure that the axes of the drive roller, the bending points and the deflection roller are in parallel.
URRACO 75 D ERVICE GUIDELINES 1.7.-15 Assembly and Disassembly of the Discharge Conveyor Belt Rollers Wear work gloves when carrying out repair work to reduce the risk of injuries. Only use suitable and approved hoisting gear. Disassemble the discharge conveyor belt drive roller in the following order: Drive belt into lowest position.
Page 34
URRACO 75 D ERVICE GUIDELINES Conveyor belt drive hydraulic motor Shaft mounted bevel gear Cleated belt Fixing Holding screws Left hand drive roller head piece Drive roller Flange bearing drive roller Right hand drive roller head piece LINDNER Service hotline:...
URRACO 75 D ERVICE GUIDELINES 1.7.-16 Tilting Hopper 1 up Proceed as follows if maintenance and repair work has to be performed underneath the raised tilting hopper 1: 1. Set the key switch (Manual-0-Automatic) to "Manual". 2. Switch to "Prepare"...
URRACO 75 D ERVICE GUIDELINES 1.7.-17 Dismounting the Overbelt Magnet (Option) When you remove the overbelt magnet from the shredder, you have to fold out the discharge conveyor belt and proceed as follows: Discharge conveyor belt into lowest position. Remove hoses from the quick release. Attention, note the position of the hoses for re- installation of the hoses.
URRACO 75 D ERVICE GUIDELINES The hydraulic hoses must be free of pressure. Accordingly, the shredder has to be switched off before dismounting the overbelt magnet and be secured against restarting. Always proceed with utmost care when dismounting the hydraulic hoses due to high hydraulic oil temperatures.
Page 38
URRACO 75 D ERVICE GUIDELINES Procedure: Activity Result Notes Knife is broken off. Switch the shredder off and secure it against accidental restarting. Observe occupational health and safety regulations (protective goggles). No combustible material in the working area! Remove the shredding tools.
