  • Page 1 S h r e d d i n g S y s t e m s LINDNER Shredder Type URRACO 75 D Date 2013.11.29 © Copyright LINDNER Mobile Shredder GmbH 2012-2013...

  • Page 2: Table Of Contents

    URRACO 75 D PERATION OF THE HREDDER 1.5.-1 Operation of the Shredder................ - 3 - 1.5.-2 Functions of the Shredder ................ - 4 - 1.5.-3 Operating Elements on the Operating Panel..........- 6 - 1.5.-4 Indicators on the Operating Panel............- 6 - 1.5.-4...

  • Page 3: Operation Of The Shredder

    HREDDER 1.5.-1 Operation of the Shredder The LINDNER Shredder can be used in the operating modes "Auto" and "Manual". In the "Auto" mode, the shredding tools and discharge conveyor belt are controlled automatically. The shredder is operated by means of: the switches and buttons at the operating panel and on the remote control of the remote control system.

  • Page 4: Functions Of The Shredder

    URRACO 75 D PERATION OF THE HREDDER 1.5.-2 Functions of the Shredder Available when the key switch (Manual-0-Automatic) is set to Button / Description "Automatic" "Manual" Swing button The delivery conveyor is folded in or out Conveyor belt b b b b Fold in and out Jog mode.
  • Page 5 URRACO 75 D PERATION OF THE HREDDER Available when the key switch (Manual-0-Automatic) is set to Button / Description "Automatic" "Manual" Swing button Automatic off Ends the automatic mode. b b b b The shredding tools are rotating in the reverse direction.

  • Page 6: Operating Elements On The Operating Panel

    URRACO 75 D PERATION OF THE HREDDER 1.5.-3 Operating Elements on the Operating Panel The functions of the operating elements on the operating panel are described in the above table. Buttons, switches, swing buttons Manual-0-Automatic Indicator light Operating panel Indicator light fault...

  • Page 7: Indicators On The Operating Panel

    URRACO 75 D PERATION OF THE HREDDER 1.5.-4 Indicators on the Operating Panel > > – – LINDNER Service hotline: Managing director Mobile Shredder GmbH +49 (0) 36920 - 7269 - 600 Manuel Lindner Gerhard Buhl Industriestrasse 1A service@l-ms.de Walter Geiger D-99820 Hörselberg / Eisenach...
  • Page 8 URRACO 75 D PERATION OF THE HREDDER > – > – > – > – LINDNER Service hotline: Managing director Mobile Shredder GmbH +49 (0) 36920 - 7269 - 600 Manuel Lindner Gerhard Buhl Industriestrasse 1A service@l-ms.de Walter Geiger D-99820 Hörselberg / Eisenach...
  • Page 9 URRACO 75 D PERATION OF THE HREDDER > – > – > > – > > – LINDNER Service hotline: Managing director Mobile Shredder GmbH +49 (0) 36920 - 7269 - 600 Manuel Lindner Gerhard Buhl Industriestrasse 1A service@l-ms.de Walter Geiger D-99820 Hörselberg / Eisenach...
  • Page 10 URRACO 75 D PERATION OF THE HREDDER > > > > > > – – > > > – > > > – LINDNER Service hotline: Managing director Mobile Shredder GmbH +49 (0) 36920 - 7269 - 600 Manuel Lindner...
  • Page 11 URRACO 75 D PERATION OF THE HREDDER > – > – > > – > > – LINDNER Service hotline: Managing director Mobile Shredder GmbH +49 (0) 36920 - 7269 - 600 Manuel Lindner Gerhard Buhl Industriestrasse 1A service@l-ms.de Walter Geiger D-99820 Hörselberg / Eisenach...
  • Page 12 URRACO 75 D PERATION OF THE HREDDER > > > – > > > – > > > – > > > – LINDNER Service hotline: Managing director Mobile Shredder GmbH +49 (0) 36920 - 7269 - 600 Manuel Lindner...
  • Page 13 URRACO 75 D PERATION OF THE HREDDER LINDNER Service hotline: Managing director Mobile Shredder GmbH +49 (0) 36920 - 7269 - 600 Manuel Lindner Gerhard Buhl Industriestrasse 1A service@l-ms.de Walter Geiger D-99820 Hörselberg / Eisenach Page - 13 - of - 33 -...
  • Page 14 URRACO 75 D PERATION OF THE HREDDER Description Lights up if ... Possible reason(s) Action(s) one of the (Emergency stop) The shredder will switch off Emergency stop buttons has been pushed. completely. Remove danger. Restart the shredder. Fault an error in the system can be...
  • Page 15 URRACO 75 D PERATION OF THE HREDDER Description Lights up if ... Possible reason(s) Action(s) Conveyor belt the conveyor belt is Too much material on The shredding tools will be pressure switch overloaded. the conveyor belt. switched off. The shredding tools will be switched on again Material jammed.

  • Page 16: Radio Remote Control

    URRACO 75 D PERATION OF THE HREDDER 1.5.-5 Radio Remote Control The remote control system consists of the actual remote control (transmitter of the remote control) and the receiver which is installed on the backside of the operating panel. Switch off the remote control immediately when a fault occurs. Switch the transmitter off using the (Emergency stop) button.
  • Page 17 URRACO 75 D PERATION OF THE HREDDER Switching on the remote control During normal operation, the shredder is controlled exclusively by means of the remote control. To switch on the remote control, proceed as follows: Prerequisites: The drive engine is switched on (see -Starting the engine).
  • Page 18 URRACO 75 D PERATION OF THE HREDDER Test the following functions: All functions must be executed If all functions are executed correctly! correctly, shredding can be "Automatic on" started. Leave the danger area immediately! "Automatic off" Should a malfunction occur, "Hopper 1 up"...
  • Page 19 URRACO 75 D PERATION OF THE HREDDER The remote control must never be left unattended while it is switched on. The remote control may never be switched on or operated unless work is to be taken up. Improper use may lead to dangerous situations.
  • Page 20 URRACO 75 D PERATION OF THE HREDDER Only recharge the battery if the red status indicator on the transmitter lights up. By doing so, you will increase the service life of your battery. For further information, please refer to the enclosed operating instructions of your remote control system.
  • Page 21 URRACO 75 D PERATION OF THE HREDDER Activity Result Notes Remove the (Manual-0- Automatic) and (Start) keys and keep them in a safe place. Turn out battery disconnecting switch and keep it. Connect the charger, which is After 4 hours, the battery is fully included in the scope of charged.
  • Page 22 URRACO 75 D PERATION OF THE HREDDER If the battery is completely empty, the charging process will take approx. 4 hours. Charge the backup battery in the supplied charger station, so that you always have a fully charged battery available for working.

  • Page 23: Preparation Prior To Switching On

    Always observe the safety instructions given. The first maintenance and all repair work that may be required may only be performed by the Service Department of LINDNER GmbH. During the warranty period, the engine may only be serviced by personnel of the engine manufacturer or its authorised representatives.

  • Page 24: Commissioning Of The Shredder

    URRACO 75 D PERATION OF THE HREDDER 1.5.-7 Commissioning of the Shredder Before starting up, ensure that there are no persons in the danger area!Press one of the Emergency stop buttons on the shredder or on the transmitter of the...
  • Page 25 URRACO 75 D PERATION OF THE HREDDER Press the key switch Plant The engine starts. Do not actuate the key on the operating panel switch for longer than 30 and turn it to the right. seconds, then wait for at least 2 minutes.

  • Page 26: Automatic Mode

    URRACO 75 D PERATION OF THE HREDDER 1.5.-8 Automatic Mode Standing within the danger area is strictly forbidden during operation, especially in the vicinity of the feed hopper! When the material is grasped by the tools, the material may bounce up in the hopper.
  • Page 27 URRACO 75 D PERATION OF THE HREDDER Action(s) Result Notes The functions on the remote in1. control system can now be executed. Leave the danger area immediately! The icon "Switch off Press button (automatic on) on Automatic mode is active.

  • Page 28: Manual Mode

    URRACO 75 D PERATION OF THE HREDDER 1.5.-9 Manual Mode The shredder may only be operated in manual mode in order to carry out preparing, maintenance and repair work. For this purpose, the switch (Manual-0-Automatic) must be set to "Manual" while the drive engine is running.

  • Page 29: 10 Switching Off Machine

    URRACO 75 D PERATION OF THE HREDDER 1.5.-10 Switching off Machine Action(s) Result Notes No more material is fed for shredding. The shredder works in automatic or manual mode. Observe the instructions in the engine manufacturer's manual. Prevent unauthorised restarting after the machine has been switched off.

  • Page 30: 11 Pressure Sensors

    URRACO 75 D PERATION OF THE HREDDER For safety reasons, the battery disconnecting switch should always be turned out as long as the shredder is not operated! 1.5.-11 Pressure sensors The pressure sensors indicate that the pressure in the hydraulic system exceeds a set value.
  • Page 31 - Pressing the icon opens a window where the value can be entered. The min. and max. value is also displayed. Always first consult the LINDNER Service Department before modifying the basic settings of the pressure sensor. Furthermore, the LINDNER Service Department will be able to recommend or make settings suiting your specific operating conditions.

  • Page 32: 12 Control Of The Shredding Tool Speed

    Value 100 % of the shredding tool speed is set in the data block by the manufacturer. During the commissioning of the shredder, the Service engineers of LINDNER GmbH can adjust the times set by the manufacturer to suit the actual application conditions.

  • Page 33: 13 Tongue / Wheel Axle

    URRACO 75 D PERATION OF THE HREDDER 1.5.-13 Tongue / Wheel axle The tongue makes it possible to reposition the machine via the wheel axle. The wheel axle is not approved for use on public roads and is only installed for repositioning onto the workstation.
