Summary of Contents for Air cat 1680-A
- Page 1 MODEL: 1680-A /1680-A-6 (ext) 3/4" IMPACT WRENCH...
- Page 2 (ft-lb) @90 Size (RPM) (in.) (in.) Minute (lbs.) (in) (CFM) NPT/BSP (in.) 1680-A 4,500 1600 12.5 1680-6-A 4,500 3/4 X 6 1600 14.8 14.8 Air Supply Tools of this class operate on a wide range of air pressure. It is recommended that air pressure of these tools measures 90 PSI at the tool while running free. Higher pressure and unclean air will shorten the tool’s life because of faster wear and may create a hazardous condition and void the warranty.
- Page 3 MODEL: 1680-A /1680-A-6 (ext) 3/4" IMPACT WRENCH Exploded View & Parts List Part Number Description Part Number Description Qty. 9283401-CAT Hammer Housing 9263402 9638047 Grease Fitting 9263401 3/8" Inlet Bushing 9M822 Screw 9283421-CAT Grip Sleeve 9283404 Bushing 9R14 Ball Bearing...
- Page 4 Maintenance 0ther factors outside the tool may cause loss of power or erratic action. Reduced compressor output, excessive drain оп the air line, moisture or restriction in air pipes or the use of hose connections of improper size or poor condition may reduce air supply. Grit or gum deposits in the tool may cut power and may Ье corrected Ьу...
