Air cat 1055-TH Operating Instructions & Parts List

1/2" impact wrench

Download this manual

MODEL: 1055-TH

1/2" IMPACT WRENCH

Need help?

Do you have a question about the 1055-TH and is the answer not in the manual?

Page 1 MODEL: 1055-TH 1/2" IMPACT WRENCH...
Page 2: Air Supply
(in) (CFM) (in.) (in.) (in.) Setting (ft-lb) (in.) 1055-TH 9,000 1600 2.75 4.25 1/4 NPT Air Supply Tools of this class operate on a wide range of air pressure. It is recommended that air pressure of these tools measures 90 PSI at the tool while running free. Higher pressure and unclean air will shorten the tool’s life because of faster wear and may create a hazardous condition and void the warranty.
Page 3 MODEL: 1055-TH 1/2" IMPACT WRENCH Exploded View & Parts List Part Number Description Part Number Description Qty. 9328822 INLET BUSHING 9251210 HOUSING CAP 9328802E-1 EXHAUST DEFLECTOR 9251207 GASKET 9328803 VALVE SPRING BALL BEARING 9328804C VALVE STEM 9251206 REAR PLATE 9328835...
Page 4 AIRCAT and NITROCAT air tools are warranted to be free from defects in material and workmanship for 2 years from date of purchase. We will repair or replace; at our option any defective part or unit which proves to be defective in material or workmanship during this 2 year period.
