Summary of Contents for Pfeiffer TTV 001
- Page 1 TTV 001 Air drier Operating Instructions...
-
Page 2: Table Of Contents
Table of contents Table of contents About this manual ..........3 1.1 Validity. -
Page 3: About This Manual
Up-to-date operating instructions can also be downloaded from www.pfeiffer-vacu- um.com. 1.2 Conventions The safety instructions in Pfeiffer Vacuum operating manuals are the result of risk eval- Safety instructions uations and hazard analyses and are oriented on international certification standards as specified by UL, CSA, ANSI Z-535, SEMI S1, ISO 3864 and DIN 4844. -
Page 4: Safety
Do not modify or alter the unit yourself. 2.2 Proper use ● The air drier TTV 001 serves for drying air during the venting of Pfeiffer Vacuum tur- bopumps. 2.3 Improper use Improper use will cause all claims for liability and warranties to be forfeited. Improper use is deemed to be all use for purposes deviating from those mentioned above, especially: ●... -
Page 5: Product Description
Product description 4 Product description 4.1 Product identification To correctly identify the product when communicating with Pfeiffer Vacuum, always have the information from the rating plate available. 4.2 Function The air drier TTV 001 for venting of turbopumps ● dries air securely, when venting the turbopumps ●... -
Page 6: Maintenance
Fig. 2: Changing the zeolite filling Dismantle the air drier TTV 001 by unscrewing the knurled screws 11. Unscrew the upper heagon nut 12 and remove flat seal 8. Hold together glass cylinder 7 and the lower flange 1. -
Page 7: Service
● Fast replacement with exchange products in mint condition ● Advice on the most cost-efficient and quickest solution Detailed information, addresses and forms at: www.pfeiffer-vacuum.com (Service). Service orders All service orders are carried out exclusively according to our repair conditions for vacu-... -
Page 8: Spare Parts
Knurled screw 5.8-A2B, M6x16 N 3160 177 5P Replacement filling for approx. 320 cm PM 006 786 -T TTV 001 Please also specify model number of the the rating plate when ordering accessories or spare parts. 9 Accessories Designation Order number... -
Page 9: Technical Data
Technical data 11 Technical data Parameter TTV 001 Capacity for zeolite, approximately 320 cm Weight with zeolite filling 0.85 kg 11.1 Dimensions... - Page 10 Pfeiffer Vacuum stands for innovative and custom Leading. Dependable. Customer Friendly vacuum solutions worldwide. For German engineering art, competent advice and reliable services. Ever since the invention of the turbopump, we´ve been setting standards in our industry. And this claim to leadership will continue to drive us in the future.
